Tasks at a glance
•
(Required.)
•
(Optional.)
•
(Optional.)
•
(Optional.)
•
(Optional.)
•
(Optional.)
•
(Optional.)
•
(Optional.)
(Optional.) Configuring EAIS
Typically, a port blocked by the spanning tree feature cannot receive or send CFD messages except
in the following cases:
•
The port is configured as an outward-facing MEP.
•
The port is configured as a MIP or inward-facing MEP, which can still receive and send CFD
messages except CCM messages.
For more information about the spanning tree feature, see Layer 2—LAN Switching Configuration
Guide.

Configuring basic CFD settings

Enabling CFD

Step
1. Enter system view.
2. Enable CFD.

Configuring Ethernet service instances

Before configuring the MEPs and MIPs, you must first configure Ethernet service instances. An
Ethernet service instance is a set of service access points (SAPs), and belongs to an MA in an MD.
The MD and MA define the level attribute and VLAN attribute of the messages handled by the MPs in
an Ethernet service instance. The MPs of the MA that carries no VLAN attribute do not belong to any
VLAN.
To configure an Ethernet service instance with the MD name:
Step
1. Enter system view.
2. Create an MD.
3. Create an Ethernet service
instance.
Configuring CC
Configuring LB
Configuring LT
Configuring AIS
Configuring LM
Configuring one-way DM
Configuring two-way DM
Configuring TST
Command
system-view
cfd enable
Command
system-view
cfd md md-name [ index
index-value ] level level-value
cfd service-instance instance-id
ma-id { icc-based ma-name |
integer ma-num | string
ma-name | vlan-based [ vlan-id ] }
[ ma-index index-value ] md
md-name [ vlan vlan-id ]
6
Remarks
N/A
By default, CFD is disabled.
Remarks
N/A
By default, no MDs exist.
By default, no Ethernet service
instance exists.
