INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
General Information: These instructions
are intended as a general guide and do not
supersede national or local codes in any
way. Authorities having jurisdiction should
be consulted before installation.
Installation and provision for combustion
and ventilation air must conform to the Na-
tional Fuel Gas Code, ANSI Z223.1, or CAN/
CGA-B149.1, Natural Gas Installation Code.

INSTALLATION INSTRUCTIONS

AND OWNER'S MANUAL
WARNING
DOUBLE BURNER
(REQUIRES VENTED DECORATIVE LOG SET)
FOR INSTALLATION IN
SOLID-FUEL BURNING FIREPLACES
MANUAL MODELS
BXL(18,24,30,36)MTN-1
CONGRATULATIONS on the purchase of your
new DOUBLE GAS BURNER! Your Decorative
Gas Burner is designed and intended for instal-
lation in an approved, existing, fully vented,
wood-burning fireplace, with a gas hook-up.
IMPORTANT! Read these instructions care-
fully before installing or operating this gas
appliance. These instructions should be left
with the homeowner for future reference.
This log set is to be installed only in a sol-
id-fuel burning fireplace with a working flue
constructed of non-combustible material.
The vent damper must also have a damper
clamp attached to it to keep the damper from
accidentally closing during operation.
If not installed, operated and maintained in
accordance with the manufacturer's instruc-
tions, this product could expose you to sub-
stances in fuel or from fuel combustion which
can cause death or serious illness.
This appliance must be installed only in a sol-
id-fuel burning fireplace with a working flue
and construction of noncombustible materi-
als. This unit is NOT for use with solid fuel.
Solid fuels shall NOT be burned in a fireplace
where a decorative appliance is installed.
WARNING
WARNING
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BXL18MTN-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Empire Comfort Systems BXL18MTN-1

  • Page 1: Installation Instructions

    INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL DOUBLE BURNER INSTALLER: Leave this manual with the appliance. (REQUIRES VENTED DECORATIVE LOG SET) CONSUMER: FOR INSTALLATION IN SOLID-FUEL BURNING FIREPLACES Retain this manual for future reference. MANUAL MODELS BXL(18,24,30,36)MTN-1 WARNING FIRE OR EXPLOSION HAZARD CONGRATULATIONS on the purchase of your If the information in this manual is not new DOUBLE GAS BURNER! Your Decorative...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE Carton Contents & Hardware Pack....................3 Important Safety Information ....................3 - 4 General Information ........................5 Fireplace Preparation ........................5 Before Fully Installing the Appliance .....................6 Introduction ...........................6 Product Specifications ........................7 Gas Supply ...........................8 Installation..........................9 - 10 Final Set Up ..........................11 Pilot and Main Burner Flame Characteristics ................12 Cleaning &...
  • Page 3: Carton Contents & Hardware Pack

    CARTON CONTENTS & HARDWARE PACK CARTON CONTENTS Items not shown to scale. Quantity Index Number Description Supplied Double Burner Assembly Damper Clamp Street Elbow, 1/2 X 3/8 Flexline Rockwool Mix Decorative Rock Black Sand See Parts Lists on page 14 for ordering replacement parts. Do not order batteries, bolts, screws, washers or nuts.
  • Page 4 IMPORTANT SAFETY INFORMATION • During manufacturing, fabricating and shipping, various DO NOT ATTEMPT TO DISCONNECT THE GAS OR ANY GAS components of this appliance are treated with certain oils, FITTING WHILE THIS APPLIANCE IS IN OPERATION. films or bonding agents. These bonding agents are not NEVER leave the decorative gas log set unattended while in harmful but may produce annoying smoke and smells as operation.
  • Page 5: General Information

    GENERAL INFORMATION High Altitude Installation Qualified Installing Agency When installing this unit at an elevation above 2000 feet (in the Installation and replacement of gas piping, gas utilization equipment United States) it may be necessary to decrease the input rating by or accessories and repair and servicing of equipment shall be per- changing the existing burner orifice to a smaller size.
  • Page 6: Before Fully Installing The Appliance

    BEFORE FULLY INSTALLING THE APPLIANCE You must secure the gas burner to the fireplace floor. If not, the Proper installation of the grate is essential to prevent any entire unit may move when you adjust the controls. Movement movement of the gas logs and controls during operation. of unit may cause shifting of the gas logs which leads to sooting and improper burning.
  • Page 7: Product Specifications

    PRODUCT SPECIFICATIONS NATURAL GAS MINIMUM FIREPLACE DIMENSIONS MASONRY BUILT FIREPLACES Millivolt Match Light Chimney Height Minimum of 10 Feet Max. 10.5” 10.5” Gas inlet pressure Rear Front Minimum Depth Height Min. 7.0” 7.0” Width Width Vent in Set Size Sq. Inches BTUH Model Gas Type...
  • Page 8: Gas Supply

    GAS SUPPLY Check all local codes for requirements, especially for the size and The use of the following gas connectors is recommended: type of gas supply line required. — ANSI Z21.24 Appliance Connectors of Corrugated Metal Tubing and Fittings Recommended Gas Pipe Diameter —...
  • Page 9: Installation

    INSTALLATION NOTICE: Installation can be made easier if two or more people SET UP AND ASSEMBLY cooperate in locating and installing the unit. Your Decorative Gas Log Hearth Kit comes ready for gas assem- bly connection particular for use in your area. LOCATING THE UNIT This appliance must be installed only in a solid-fuel burning IMPORTANT...
  • Page 10: Installation

    INSTALLATION INSTALLING THE APPLIANCE INTO A FIREPLACE Place the Burner Pan into the fireplace. The unit should be centered from both side to side and front to back in the fire- place. The unit is shipped ready for right side gas connection only.
  • Page 11: Final Set Up

    FINAL SET UP WARNING CAUTION Failure to position the parts in accordance with all includ- DO NOT place glowing embers, sand, rockwool mix, or ed pictures, diagrams and drawings, or failure to use only lava rock (cinders) in the area of the safety pilot assembly. parts specifically approved with this appliance may result in property damage or personal injury.
  • Page 12: Pilot And Main Burner Flame Characteristics

    PILOT AND MAIN BURNER FLAME CHARACTERISTICS If pilot flame pattern is incorrect • See Troubleshooting, page 13 Main Burner Flame Pattern The main burner flame will be completely yellow. Main Burner Flame Ignition and Extinction When the main burner is ignited it will take a few seconds for the full flame pattern to develop.
  • Page 13: Maintenance & Service

    MAINTENANCE & SERVICE The Decorative Gas Log Set should be thoroughly inspected on a SOOTING regular basis at least once a year by a qualified installer. Some sooting of your log set is normal, adding to the appearance At the beginning of each season, the system should be checked of burned wood.
  • Page 14: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST PART NO INDEX NO DESCRIPTION BXL18 BXL24 BXL30 BXL36 R12024 R12025 R12026 R12027 Double Burner Assembly R12047 R12047 R12224 R12224 Orifice R12055 R12055 R12055 R12055 Orifice Holder R2809 R2809 R2809 R2809 Damper Clamp R12083 R12083 R12083 R12083 Flexline...
  • Page 15: Master Parts Distributor List

    This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing F.
  • Page 16: Warranty

    WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual.
  • Page 17: Appliance Service History

    APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 35644-2-0617 Page 17...
  • Page 18 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 18 35644-2-0617...
  • Page 19 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 35644-2-0617 Page 19...
  • Page 20 Empire Comfort Systems Inc. Belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com...
