Check the operation of the VNT actuator (DC motor) [Hino-DX]
Select
Engine
Has DTC P226C been detected?
Replace the turbocharger.
Perform "After-inspection work" of INFOR-
MATION section.
ENGINE CONTROL SYSTEM (J08E)
1. Connect the VNT controller and VNT actuator connector.
2. Set the starter switch to the "ON" position.
3. Erase the trouble history.
4. Set the starter switch to the "LOCK" position.
5. Set the starter switch to the "ON" position again.
6. Select [Engine] and check if P226C has been detected in [Fault
Information].
SAPH16F010300842
HINT
Turn the starter switch OFF and ON verifies the wiping operation
of the VNT actuator (DC motor).
YES NO
Procedure completed.
Perform "After-inspection work" of INFOR-
MATION section.
4–1093
