Mobicool FR40 AC/DC Operating Manual

Compressor cooler
Hide thumbs Also See for FR40 AC/DC:
Table of Contents

Advertisement

Quick Links

Compressor Cooler
EN
Operating manual. . . . . . . . . . . . . . . . . . . . .4
Kompressor-Kühlbox
DE
Bedienungsanleitung . . . . . . . . . . . . . . . . .18
Glacière à compression
FR
Notice d'utilisation . . . . . . . . . . . . . . . . . . .33
Nevera por compresor
ES
Instrucciones de uso . . . . . . . . . . . . . . . . .48
Frigorifero a compressore
IT
Istruzioni per l'uso . . . . . . . . . . . . . . . . . . .63
Compressorkoelbox
NL
Gebruiksaanwijzing . . . . . . . . . . . . . . . . . .78
Kompressor-køleboks
DA
Betjeningsvejledning . . . . . . . . . . . . . . . . .92
Kylbox med kompressor
SV
Bruksanvisning . . . . . . . . . . . . . . . . . . . . .106
Kjøleboks med kompressor
NO
Bruksanvisning . . . . . . . . . . . . . . . . . . . . .120
Kompressori-kylmälaatikko
FI
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . .134
Geleira com compressor
PT
Manual de instruções
Компрессорный холодильник
RU
Инструкция по эксплуатации . . . . . . . . .163
Przenośna lodówka kompresorowa
PL
Instrukcja obsługi . . . . . . . . . . . . . . . . . . .179
Kompresorový chladicí box
CS
Návod k obsluze. . . . . . . . . . . . . . . . . . . .194
Chladiaci box s kompresorom
SK
Návod na obsluhu . . . . . . . . . . . . . . . . . .208
Kompresszor hűtőláda
HU
Használati utasítás
FR40
AC/DC
. . . . . . . . . . . . . . . . .148
. . . . . . . . . . . . . . . . . . .222

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR40 AC/DC and is the answer not in the manual?

Questions and answers

Related Manuals for Mobicool FR40 AC/DC

Summary of Contents for Mobicool FR40 AC/DC

  • Page 1 FR40 AC/DC Compressor Cooler Operating manual.....4 Kompressor-Kühlbox Bedienungsanleitung ....18 Glacière à...
  • Page 2 FR40 AC/DC POWER ° DOWN – ERROR 100-240V~AC 12/24V...
  • Page 3 FR40 AC/DC...

  • Page 4: Table Of Contents

    FR40 AC/DC Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it.

  • Page 5: Explanation Of Symbols

    FR40 AC/DC Explanation of symbols Explanation of symbols WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product.
  • Page 6 Safety instructions FR40 AC/DC  This device can be used by children aged 8 years or over, as well as by persons with diminished physical, sensory or mental capacities or a lack of experience and/or knowledge, providing they are supervised or have been taught how to use the device safely and are aware of the resulting risks.

  • Page 7: Operating The Device Safely

    FR40 AC/DC Scope of delivery  The cooling device contains inflammable cyclopentane in the insulation. The gases in the insulation material require special disposal procedures. Deliver the device at the end of its life- cycle to an appropriate recycling. Operating the device safely CAUTION! ...

  • Page 8: Intended Use

    Intended use FR40 AC/DC Intended use The compressor cooler is suitable for cooling and freezing foods. The compressor cooler is also suitable for use on boats. The compressor cooler is designed to be operated from a DC power supply socket of a vehicle, boat or caravan or from an AC mains.

  • Page 9: Operating And Display Elements

    FR40 AC/DC Function description Operating and display elements Latch for lid: fig. 1 1, page 2 Operating panel (fig. 2, page 2) Item Description Explanation Switches the cooling device on or off when the button is pressed for between one and two seconds...

  • Page 10: Operation

    Operation FR40 AC/DC Operation Before initial use NOTE Before starting your new cooling device for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the chapter “Cleaning and mainte- nance”...

  • Page 11: Connecting The Cooling Device

    FR40 AC/DC Operation Connecting the cooling device The cooling device can be operated with DC or AC voltage. NOTICE! Danger of damage! Disconnect the cooling device and other consumer units from the vehicle battery before you connect the vehicle battery to a quick charging device.

  • Page 12: Using The Cooling Device

    Operation FR40 AC/DC In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and “MED” (see the following table). Battery monitor mode HIGH 10.1 V 11.4 V 11.8 V Switch-off voltage at 12 V 11.1 V 12.2 V 12.6 V...

  • Page 13: Latching The Cooling Device Lid

    FR40 AC/DC Operation ➤ Connect the cooling device, see chapter “Connecting the cooling device” on page 11. NOTICE! Danger from excessively low temperature! Ensure that only those objects are placed in the cooling device that are intended to be cooled at the selected temperature.

  • Page 14: Switching Off The Cooling Device

    Operation FR40 AC/DC Switching off the cooling device ➤ Empty the cooling device. ➤ Switch the cooling device off. ➤ Pull out the connection cable. If you do not want to use the cooling device for a longer period of time: ➤...

  • Page 15: Cleaning And Maintenance

    FR40 AC/DC Cleaning and maintenance Cleaning and maintenance WARNING! Always disconnect the device from the power supply before you clean and service it. NOTICE! Risk of damage  Never clean the cooler under running water or in dish water.  Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the cooler.

  • Page 16: Troubleshooting

    Troubleshooting FR40 AC/DC Troubleshooting Fault Possible cause Suggested remedy The cooling device There is no voltage The ignition must be switched on in most does not function, present in the DC power vehicles to apply current to the DC power “POWER”...

  • Page 17: Technical Data

    FR40 AC/DC Technical data Technical data FR40 AC/DC Item no.: 9105330192 Connection voltage: 12/24 Vg 100 – 240 Vw, 50/60 Hz Power consumption: 4 A (12 Vg) 2 A (24 Vg) 1.0 – 0.4 A (100 – 240 Vw) Cooling capacity: +10 °C to –10 °C (+50 °F to +14 °F)
  • Page 18 www.mobicool.com...
