3

Getting started

3.1 Install

Insert the installation CD into the PC's CD ROM (or DVD ROM)
1
drive
• The installation program will start automatically
Follow instructions on the screen
2
Note
If for some reason the installation does not start automatically :
1 Click on Windows START and then RUN
2 Type explorer and navigate to the CD ROM (or DVD ROM)
drive
3 Double-click on Setup.exe
Tip
By default, the language of your operating system will be choosen, but
you have 10 seconds if you want to select another one.
Click on the required language
3
• The next screen will be displayed automatically
4 Click on the picture of the SNB5600 Wireless Router
• The next screen will be displayed automatically
Getting started

3.2 Connect

Connect the supplied power adapter to the 9V DC port
1
Connect the power adapter to the electricity supply socket
2
• Power light will turn on
If your computer is already connected via Ethernet, then disconnect
3
this cable from your computer
Connect this Ethernet cable to the WAN port on the SNB5600
4
• WAN light will turn on
Take the Ethernet cable provided in the box
5
5
