- Page 1 Challenger & Oregon Car Seats User Guide IMPORTANT Please retain this User Guide for future reference Conforms to EXTREME HAZARD: Parents should not under any circumstances ECE R44.03 use this child restraint on a passenger seat equipped with an airbag.
- Page 2 Safety warnings English • Spanish • PLEASE READ THOROUGHLY BEFORE COMMENCING INSTALLATION AS AN INCORRECT INSTALLATION COULD BE DANGEROUS. • DO NOT USE THIS CHILD SEAT IN PASSENGER SEATS EQUIPPED WITH AIRBAGS. • This child seat can be installed in either a forward or rearward facing position. Do not use on side facing or rear facing seats.
- Page 3 This seat is also classified as Group 1 for children weighing 9kg to 18kg (9 months - 4 years approx.) - in a forward facing position.Do not use forward facing before your child's weight exceeds 9 kg SHOULDER STRAPS SHOULDER PADS BODY PAD (on Challenger only) (on Challenger only) BUCKLE PAD BUCKLE (on Challenger only)
-
Page 4: Legal Requirements
The type of approved seat belt you must have DO NOT USE THIS CHILD SEAT IN PASSENGER SEATS EQUIPPED WITH AIRBAGS Your Mothercare child seat can only be installed with this seat belt configuration. A lap and diagonal seat belt in the front or rear passenger seats of a car. - Page 5 The harness Doing up the harness Place the left hand harness connector behind the right hand one, they should slot together neatly. Push the harness ends into the hole in the buckle at the top of the crotch strap. You will hear and feel a ‘CLICK’ when it is secure. Check by attempting to remove the connectors by pulling the webbing above and below the buckle.
- Page 6 BOTTOM of the child seat. Re-fit the blue plastic clip. Repeat the process for the other shoulder strap. Fitting the body pad (on Challenger only) Refer to 2 and 3 above for guidelines on adjusting each shoulder strap. Only remove one strap at a time, leave the other shoulder strap in place as a reference.
- Page 7 Fitting your child seat into your car WARNING: Do not use this child seat in passenger seats fitted with airbags. Do not use on rear-facing or side-facing vehicle seats. If the seat recline angle is changed after installation, the seat belt must be re-tightened and the red ‘lock-off’...
- Page 8 Fitting your child seat into your car Tighten the diagonal section of the seat belt by pulling it in the direction shown. Your car seat should now be fixed securely. Make sure it is. Check that there are no kinks or twists in the car seat belt. From 9kg to 18kg - forward facing - using a 3 point seat belt Place the child’s car seat on the passenger seat with a 3 point seat belt.
- Page 9 Reclining your child seat In a forward facing position your baby seat can be reclined in a choice of five positions to make it comfortable for your child. To do this, lift and then pull the lever under the seat forward. This releases the lock, enabling the seat shell to recline or move back to the upright position.
-
Page 10: Final Checklist
Do not put your child’s safety at risk by using without a seat cover. The seat cover should not be replaced with any other than the one recommended by Mothercare, because the cover constitutes an integral part of the restraint performance. -
Page 11: Replacement Parts
Customer Care Your child’s safety is your responsibility If you have a problem with this product or require replacement parts, please contact your nearest Mothercare store or telephone the Mothercare Customer Care Line on 01923 210 210. Alternatively, write to:... - Page 12 4. If in doubt, consult either the child restraint manufacturer or the retailer. 5. Only suitable if the approved vehicles are fitted with 3 point static or retractor safety belts approved to UN/ECE Regulation No. 16 or other equivalent standards. Made in France for Mothercare, Watford, Herts, WD24 6SH...
