S/PDIF Input S/PDIF Input
S/PDIF Input S/PDIF Input
The 328 S/PDIF input can be routed to any one of the following inputs:
Stereo Input 1;
Stereo Input 2;
FX Return 1;
FX Return 2;
2 Track Tape Return,
provided that the AES/EBU input has not already been assigned to that input. Commonly the
Lexicon Studio LDI-12T S/PDIF output would best be routed to Stereo Input 1 or the 2 Track
Tape Return input.
NOTE
Press <MENU> to enter the menu pages, scroll through the pages until the 'SPDIF I/P Setup' is
highlighted and press <ENTER>. Using the encoder, select the destination for the S/PDIF
input, press <ENTER> to set and <MENU> to return to the menu pages.
NOTE
< SPDIF
Route To: STE-1
< SPDIF
Route To:
4
<Tape Ch25->32 >
Bank Source:ADAT
<Tape Ch25->32 >
Wordlength:
Assigning a digital source to an input will override an analogue signal, if
present.
If the S/PDIF input is not required, NOWHERE should be selected in the
menu.
Input >
Input >
2TRK
Spirit Digital 328 v2
24
< SPDIF Input >
Route To: FX-1
< SPDIF Input >
Route To:NOWHERE
