- Page 1 OptiView 100 OV-100 LCD VIEWFINDER USER MANUAL...
- Page 2 Thank you for choosing Elvid. The Elvid OptiView 100 is a viewfinder that blocks out bright light so you can see the image on your LCD screen in greater detail. It fits screens up to 3.2 inches and features multi-coated optical glass for sharp images from edge to edge.
- Page 3 OVERVIEW Eyepiece Lower half of with diopter the viewfinder Eyecup Lanyard Rubber bumper Mounting frame...
- Page 4 PRECAUTIONS • Please read the following instructions. • Keep this manual in a safe place. • Remove the viewfinder when not in use for long periods of time. The OptiView’s lens could act as a magnifying glass which intensifies the direct light from the sun.
-
Page 5: Key Features
KEY FEATURES • Supports 3.0- and 3.2-inch LCD screens • Facilitates fine-image focusing • Blocks out ambient light for clear image viewing • Lower half of the viewfinder acts as an LCD shade • Soft eyecup can be used with left or right eye •... - Page 6 MOUNTING THE OPTIVIEW 100 Note: Once the OptiView 100’s mounting frame is attached to the camera with adhesive, the adhesive cannot be reused. 1. Clean the camera’s LCD screen with a soft, dry cloth. 2. Remove the mounting frame from the viewfinder.
- Page 7 3. Remove the protective strip on the adhesive side of the mounting frame. Make sure to carefully center the mounting frame before securing it on your camera’s LCD screen. Apply the adhesive at room temperature. 4. Once mounted on the camera, attach the viewfinder to the mounting frame.
- Page 8 USING THE OPTIVIEW 100 AS AN LCD SHADE 1. Detach the viewfinder from the magnetic mounting frame on the LCD. 2. Firmly hold the viewfinder, apply pressure to the grooves, and separate the two pieces. 3. Reattach the lower half of the viewfinder onto the mounting frame until it snaps into place.
- Page 9 USING THE RUBBER BUMPER The rubber bumper covers the end of the viewfinder. This is ideal to eliminate scratches when used over your camera’s LCD screen while quickly viewing your image. REMOVING THE OPTIVIEW 100 Note: Once the OptiView’s mounting frame has been detached from the camera, it cannot be reattached.
-
Page 10: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This ELVID product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
