- Page 1 OptiView 150 OV-150 LCD VIEWFINDER USER MANUAL...
- Page 3 INTRODUCTION Thank you for choosing the Elvid OptiView 150. This LCD viewfinder provides a clear 3x magnification for a 3-inch LCD screen with 4:3 or 3:2 aspect ratio that’s built into most DSLR cameras. The magnification creates a larger than normal view of the image on your device’s screen, facilitating fine detail focusing.
- Page 4 PRECAUTIONS • Please read and follow these Remove the viewfinder when instructions. not in use, as the camera’s LCD may be damaged by the • Keep this manual in a safe magnified light. place. • Do not use the viewfinder’s •...
- Page 5 • Handle this product with care. • Clean this product with a soft, dry cloth. • Use only parts provided by the manufacturer. • Make sure everything is secure before proceeding. • Make sure that this product is intact and that there are no missing parts before use.
-
Page 6: Table Of Contents
TABLE OF CONTENTS Product Contents ............7 Overview ................ 8 Features ................9 Using the Optiview ............10-15 Specifications ..............16 Notes ................17 Warranty ................ 18-19... -
Page 7: Product Contents
PRODUCT CONTENTS • 3x LCD Viewfinder • Plastic mounting frame/screen protector with optical glass • 17″ lanyard • Warranty • User manual... -
Page 8: Overview
OVERVIEW Diopter Ring Screen protector/ mounting frame Release button Eyecup Eyepiece Lanyard... -
Page 9: Features
FEATURES • Turns your camera’s LCD • Flips up to reveal your screen into a magnified camera’s LCD screen viewfinder • Includes a LCD screen- • Facilitates fine detail focusing protecting mounting frame with optical glass • Supports most 3″ LCD screens with a 4:3 or 3:2 •... -
Page 10: Using The Optiview
USING THE OPTIVIEW 1. Clean your LCD screen with a soft, dry cloth. 2. Turn on your LCD screen. The heat from the camera will promote adhesion of the LCD mounting frame. 3. Remove the plastic cover on the adhesive side of the screen protector/mounting frame and apply its adhesive side to your camera’s LCD screen. - Page 11 (Fig. 1)
- Page 12 USING THE OPTIVIEW (CONTINUED) 4. Place a light object (like a hardcover book) on the mounting frame overnight to fully secure it to the camera’s LCD screen. 5. Once securely attached, remove the plastic film from the outside of the mounting frame. 6.
- Page 13 (Fig. 2)
- Page 14 USING THE OPTIVIEW (CONTINUED) 7. With the camera on, look at the image on the LCD screen through the OptiView. If out of focus, use the diopter ring. 8. To view the LCD screen without magnification, simply lift the viewfinder upward to expose the camera’s screen. (Fig. 3) 9.
- Page 15 (Fig. 3) (Fig. 4)
-
Page 16: Specifications
SPECIFICATIONS Magnification Support Most DSLR cameras with a 3-inch, 4:3 or 3:2 aspect ratio LCD screen Diopter 3± Lanyard Length 17 inches Dimensions 3.5″ x 2.8″ x 2.2″ (8.9 x 7.1 x 5.5 cm) Weight 4 oz. (113.3 g) -
Page 17: Notes
NOTES... -
Page 18: Warranty
ONE-YEAR LIMITED WARRANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. -
Page 19: Warranty
To obtain warranty coverage, contact the Elvid Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Elvid along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
