- Page 1 FIELDVISION OCM-7B-4K 7˝ 4K IPS Monitor USER MANUAL...
- Page 3 THANK YOU FOR CHOOSING ELVID. The Elvid FieldVision 4K is a lightweight, 7-inch on-camera monitor that is capable of displaying signals up to 4K UHD (3840 × 2160) and up to 30p. The LCD panel’s native resolution of 1280 × 800 provides a sharp image and facilitates precise color rendering.
- Page 4 PRECAUTIONS • Exposure to high sound levels • Avoid any impacts to this can cause permanent hearing product. loss. Avoid listening at high • Do not block the vents in this volumes for extended periods product. of time. • Disconnect this product from its •...
-
Page 5: Table Of Contents
TABLE OF CONTENTS Overview ................6-7 Product Contents ..............8 Powering Options ..............9-10 Using The OCM-7B-4K ............. 11-12 The HDMI Lock ..............13 The Sunshade .................14 Front Panel Buttons .............15 Function Buttons ..............16 The Menu ................17 Color Menu ............... 18-19 OSD Menu ................ -
Page 6: Overview
OVERVIEW Sunshade slots FIELDVISION 4K MODE MENU Left Nav/Vol - Screen Mode button Status LED Right Nav/Vol + Power button Menu button F4 button Down Nav/F1 button F3 button Up Nav/F2 button... - Page 7 Speaker HDMI locking mount Battery mounting plate DC power input HDMI input 1/4″-20 threaded socket AV input Headphone jack OSD controller port USB port...
-
Page 8: Product Contents
PRODUCT CONTENTS · 7˝ On-Camera Monitor · Battery charger · Mini HDMI to HDMI cable · Sunshade · HDMI Locking Collar · Sunshade mounting frame · Shoe-mount ball head · User manual · NP-F550 (2200 mAh) battery Note: Additional battery plates available. Please visit us at www.elvidcinema.com for more information. -
Page 9: Powering Options
POWERING OPTIONS There are two ways to power the FieldVision 4K: AC or the included rechargeable battery. CAMERA BATTERY The FieldVision’s built-in battery mounting plate accommodates a Sony L-Series–type battery. For more information on compatible battery types, refer to Specifications on page 26. To install a compatible battery, follow these steps: 1. - Page 10 To turn on the FieldVision 4K, press the power button on the front panel of the monitor. The FieldVision 4K will turn on and enter standby mode, and the status LED will glow red. To remove the battery, press and hold the battery release button, and slide the battery out of the plate.
-
Page 11: Using The Ocm-7B-4K
USING THE OCM-7B-4K MOUNTING THE FIELDVISION Use the FieldVision 4K’s 1/4″-20 threaded socket to attach the monitor to your mounting system or the included ball head. Make sure your bracket can support the monitor. CONNECTING THE VIDEO SOURCE HDMI Input: The FieldVision 4K is equipped with an HDMI input for use as a wired high-definition video monitor. - Page 12 Composite Video Input: To use your FieldVision 4K as a wired standard-definition video monitor, an A/V breakout cable (available separately) is needed. 1. Insert the 1/8″ (3.5 mm) plug into the A/V input on the side of the monitor. 2. Connect your composite video source to the yellow RCA jack.
-
Page 13: The Hdmi Lock
HDMI LOCK An HDMI lock is included with the FieldVision 4K to reduce stress on the HDMI plug and ensure that the HDMI plug is not pulled out of the input while you’re shooting. To install the HDMI lock, follow these steps: 1. -
Page 14: The Sunshade
SUNSHADE The sunshade prevents glare on the monitor’s screen by blocking out stray light, and it is useful when shooting outdoors. To attach the sunshade to the monitor, follow these steps: 1. Match the pegs of the mounting frame with the slots on the back of the monitor. -
Page 15: Front Panel Buttons
FRONT PANEL BUTTONS For greater efficiency while using the FieldVision 4K, you can use the buttons on the front of the monitor as shortcuts to various functions, instead of cycling through the onscreen menus. Mode Button: Selects between HDMI and A/V input signals. Left Navigation/Vol –... -
Page 16: Function Buttons
FUNCTION BUTTONS The four function buttons (F1–4) have preset shortcuts assigned to them, but can be changed to accommodate your specific needs. See Function Shortcut Menu on page 24 for information on changing the function assignment for each button. F1 Button: Preset to Check Field. In Check Field mode, only the one selected color will appear onscreen. -
Page 17: The Menu
THE MENU To get the most out of the FieldVision 4K, make sure the monitor’s settings are properly configured. All of the setting configurations are located in the main menu, which has four submenus: Color, Onscreen Display (OSD), Settings, and Function. Menu Button: Pressing the menu button •... -
Page 18: Color Menu
COLOR MENU The color menu offers three preset picture modes (standard, mild, and dynamic) as well as a user mode with adjustable brightness, contrast, saturation, and sharpness settings. In all picture modes, the values of color temperature and tint can be adjusted to your specific needs. Other parameters that can be adjusted appear black, and when selected with the Up/Down buttons, a horizontal submenu icon appears next to it. - Page 19 Brightness: Adjusts the monitor’s brightness value from 0–100. Contrast: Adjusts the value of contrast of the onscreen image from 0–100. Saturation: Adjusts the value of screen color saturation from 0–100. Sharpness: Adjusts the value of fine detail of the picture from 0–100. Color Temp.: Presets are 6500 (default) and 9600.
-
Page 20: Osd Menu
ONSCREEN DISPLAY (OSD) Language: You can set the onscreen language to English (default), Simplified Chinese, Spanish, Portuguese, French, Dutch, German, and Japanese. Aspect Ratio: Adjusts the aspect ratio of the incoming video signal and how it is displayed onscreen. Available settings are Panorama, Auto, 4:3, 16:9, Zoom 1, Zoom 2, and Just Scan. - Page 21 Note: U/D Zoom and L/R Zoom will change the aspect ratio of your picture. USB Upgrade: Contact Elvid customer support to see if there is a firmware update for your monitor. Reset: Pressing the Right Nav button resets the FieldVision...
-
Page 22: Function Menu
FUNCTION MENU Center Marker: Selecting On puts a center marker onscreen. Off is the default setting. The center marker does not appear while the menu is displayed. Press the Menu button twice to close the menu and make the center marker visible. Safe Frame: Safe frame displays and adjusts the size of the onscreen safety frame markers. - Page 23 Check Field: In Check Field mode, only the one selected color will appear onscreen. Select red, green, blue, mono, or off (default). Check Field mode is useful for calibrating the monitor. P2P: Pixel-to-Pixel mode turns off scaling and displays the incoming video signal in its native resolution and aspect ratio with 1:1 pixel mapping.
-
Page 24: Function Shortcut Menu
FUNCTION SHORTCUT MENU This menu allows you to select or change the settings of the four function buttons on the front of the monitor. 1. Press the Menu button and use the navigation button to scroll to the Function Button Shortcut menu. 2. -
Page 25: Supported Formats
SUPPORTED FORMATS (60/50 HZ) 480i, 480p 60/59.94, 30/29.97, 24/23.98 576i, 576p 50, 25 720p 60/59.94, 50, 30/29.97, 25, 24/23.98 1080i 60/59.94, 50 1080p 60/59.94, 50, 30/29.97, 25, 24/23.98 4K UHD 30, 25, 24 (3840×2160) 4K (4096 × 2160) -
Page 26: Specifications
SPECIFICATIONS MONITOR 7 ″ Panel size Panel type Backlight Resolution 1280 × 800 Brightness 400 cd/m² Contrast ratio 800:1 Viewing angle L/R: 89°/89° U/D: 89°/89° Dot pitch (W × H) 0.11775 × 0.11775 Aspect ratio 16:10 Inputs HDMI, composite video, stereo audio... - Page 27 (CONTINUED) Outputs Composite video, headphone (3.5 mm stereo), mono speaker Threaded socket 1/4″-20 Input voltage DC: 7.4 V - 35 V Power consumption ≤5 W Battery type Sony L-Series Dimensions 6.9″ × 5.1″ × 0.7″ (W × H × D) (17.6 ×...
-
Page 28: Troubleshooting
PROBLEM SOLUTION The FieldVision 4K will • If you are powering the FieldVision 4K with a battery, not turn on. make sure the battery is fully charged and properly seated in the battery plate. • Make sure that the 12 V DC adapter is fully plugged in, and that your AC power source is reliable. - Page 29 PROBLEM SOLUTION The onscreen image size • Make sure the Camera mode is is incorrect. disabled. • Check whether the aspect ratio is set correctly. • Make sure that the correct input signal is selected. • Check your cables to make sure they are properly connected and that they are reliable.
-
Page 30: Fcc Statement
FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and AUTION: (2) This device must accept any interference received, OT SURFACE including interference that may cause undesired operation. -
Page 31: Warranty
ONE-YEAR LIMITED WARRANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be...
