aoyue INT883 Instruction Manual

Ir-preheating system

Advertisement

Quick Links

BASIC TROUBLESHOOTING GUIDE
PROBLEM 1: THE UNIT HAS NO POWER
1.  Check if the unit is switched ON.
2.  Check the fuse. Replace with the same type if fuse is blown.
3.  Check the power cord and ensure there are no disconnections.
4.  Verify that the unit is properly connected to the power source.
PROBLEM 2: PANEL DISPLAYS "Err" MESSAGES
DESCRIPTION: Display show "SEnS" "Err" messages. \
ERR0  — First external temperature probe not detected
ERR1  — Second external temperature probe not detected
ERR2  — Internal  temperature probe not detected
ERR3  — First external temperature probe not  attached.
SOLUTION: Turn off power and back on.
If  err  messages  shows  err0  or  err1  check  the  connection  of  sensor  to  its
receptacle. Check if the temperature probe tip is still intact.
If err messages shows err2 internal temperature connector might have come
loose or needs to be replaced.
If  err  messages  shows  err3,  the  first  external  temperature  probe  was  not
detected, secure the external temperature on the underside of the board to be
worked on.
PROBLEM 3: DISPLAY AND OTHER DEVICE OPERATION
ISSUES
SOLUTION: Turn off power and back on.
OTHER PROBLEMS NOT MENTIONED:
Contact the vendor.
12
IR­Preheating System
INSTRUCTION MANUAL
Thank you for purchasing Aoyue Int883 IR­Preheating System.
It is important to read the manual before using the equipment.
Please keep manual in accessible place for future reference.
This manual is designed to familiarize the technician with
the proper operation and maintenance of the equipment.
The "Care and Safety Precautions" section explains the
hazards of using any type of soldering or reworking device.
Please read carefully and observe the guidelines in order to
maximize usage and minimize the risk of injury or accidents .
Int883

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INT883 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for aoyue INT883

  • Page 1 BASIC TROUBLESHOOTING GUIDE  PROBLEM 1: THE UNIT HAS NO POWER  1.  Check if the unit is switched ON.  Int883  2.  Check the fuse. Replace with the same type if fuse is blown.  3.  Check the power cord and ensure there are no disconnections.  4.  Verify that the unit is properly connected to the power source.  IR­Preheating System  PROBLEM 2: PANEL DISPLAYS “Err” MESSAGES  DESCRIPTION: Display show “SEnS” “Err” messages. \  INSTRUCTION MANUAL  ERR0  — First external temperature probe not detected  ERR1  — Second external temperature probe not detected  ERR2  — Internal  temperature probe not detected  ERR3  — First external temperature probe not  attached.  Thank you for purchasing Aoyue Int883 IR­Preheating System.  It is important to read the manual before using the equipment.  SOLUTION: Turn off power and back on.  Please keep manual in accessible place for future reference. If  err  messages  shows  err0  or  err1  check  the  connection  of  sensor  to  its ...
  • Page 2 OPERATING PROCEDURES  6.  After the process is finish the display will show “End”,  press the  increase button to save the profile and exit to profile adjustment  mode.  7.  To  exit  before the  process  is  finished  press  the  increase  button  TABLE OF CONTENTS while the profile is running. The system would exit and return to  profile adjustment mode.  CARE & SAFETY PRECAUTIONS ………………………….. 3 Note:There  is  a  built  in  protection  feature  to  automatically  limit  the  PRODUCT DESCRIPTION …………………………………… 4 temperature ...
  • Page 3 OPERATING PROCEDURES  CARE and SAFETY PRECAUTIONS  D.  TYPE “2”  OPERATION  Before  proceeding  with  this  type  of  operation,  attach  the  first  CAUTION:  Improper usage can cause injury and physical damage.  For your own safety, please observe the following precautions.  external  temperature  probe  to  the  underside  of  the  PCB  to  be  worked  on.  The  second  probe  can  be  placed  near  areas  of  Temperature may reach as high as 500°C when turned ON.  ●  interest. Such as near the component to be worked on. ...
  • Page 4 PRODUCT DESCRIPTION  OPERATING PROCEDURES  D.  TYPE “1”  OPERATION  The Aoyue Int 883 IR­Preheating System is a reworking equipment that com­  Before proceeding with this type of operation, attach the first external  bines infrared (IR) heating technology, enhanced pre­heating area, versatile board  temperature  probe  to  the  underside  of  the  PCB  to  be  worked  on.  The  holder, and profile control of heating in one sophisticated package. It is  designed  second probe can be placed near areas of interest.  for  reworking  double­sided,  diverse  technology  printed  circuit  boards  (PCB)  This type of operation utilizes the first external temperature sensor to  which  utilizes traditional or lead free solder.  control the heat.  Using this type of operation allows us to closely control  The system is equipped with a high powered IR­heating elements combined  the  temperature  at  board  level.  While  freeing  up  the  second  external ...
  • Page 5 PACKAGE INCLUSION  OPERATING PROCEDURES  2.  Press  the  increase  or  decrease  button  to  adjust  the  set  temperature  level.  The  set  temperature  is  adjustable  from  50 to 400 C in this type of operation.  3.  To  view  the  actual  temperature  read  by  the  internal  temperature  probe,  repeatedly  press  the    selection  button  until ...
  • Page 6 Control Panel Guide  OPERATING PROCEDURES  2  A.  INITIAL PROCEDURES  3  1.a  5  1.  Make sure all switches are deactivated.  2.  Attach external sensor  probes to the three pin socket. (#6 on  control panel guide)  7  3.  Attach  power  cord  to  the  power  cord  attachment  (#8  on  control panel guide)  4  6  4.  Plug the device to the main power source.  1.b  5.  To  turn  the  unit  ON.  Toggle  the  main  power  switch    to  ON  Front Panel ...
