aoyue Int883 Instruction Manual

Ir-preheating system

Advertisement

BASIC TROUBLESHOOTING GUIDE
PROBLEM 1: THE UNIT HAS NO POWER
1. Check if the unit is switched ON.
2. Check the fuse. Replace with the same type if fuse is blown.
3. Check the power cord and ensure there are no disconnections.
4. Verify that the unit is properly connected to the power source.
PROBLEM 2: PANEL DISPLAYS "Err" MESSAGES
DESCRIPTION: Display show "SEnS" "Err" messages. \
ERR0 — First external temperature probe not detected
ERR1 — Second external temperature probe not detected
ERR2 — Internal temperature probe not detected
ERR3 — First external temperature probe not attached.
SOLUTION: Turn off power and back on.
If err messages shows err0 or err1 check the connection of sensor to
its receptacle. Check if the temperature probe tip is still intact.
If err messages shows err2 internal temperature connector might have
come loose or needs to be replaced.
If err messages shows err3, the first external temperature probe was
not detected, secure the external temperature on the underside of the
board to be worked on.
PROBLEM 3: DISPLAY AND OTHER DEVICE OPERATION
ISSUES
SOLUTION: Turn off power and back on.
OTHER PROBLEMS NOT MENTIONED:
Contact the vendor.
12
IR-Preheating System
INSTRUCTION MANUAL
Thank you for purchasing Aoyue Int 883 IR-Preheating System.
It is important to read the manual before using the equipment.
Please keep manual in accessible place for future reference.
This manual is designed to familiarize the technician with
the proper operation and maintenance of the equipment.
The "Care and Safety Precautions" section explains the
hazards of using any type of soldering or reworking device.
Please read carefully and observe the guidelines in order to
maximize usage and minimize the risk of injury or accidents .
Int883

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Int883 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for aoyue Int883

  • Page 1 ERR2 — Internal temperature probe not detected ERR3 — First external temperature probe not attached. Thank you for purchasing Aoyue Int 883 IR-Preheating System. SOLUTION: Turn off power and back on. It is important to read the manual before using the equipment.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS OPERATING PROCEDURES CARE & SAFETY PRECAUTIONS ……………...…….. 3 PRODUCT DESCRIPTION …………………….……… 4 Note:There is a built in protection feature to automatically limit the temperature rising slope to no more than 3 degrees per second. Therefore FUNCTIONS & FEATURES …………….……………… 4 based on your set time, the maximum temperature may not reach 250C.
  • Page 3: Care & Safety Precautions

    OPERATING PROCEDURES CARE and SAFETY PRECAUTIONS D. TYPE “2” OPERATION CAUTION: Improper usage can cause injury and physical damage. Before proceeding with this type of operation, attach the first external For your own safety, please observe the following precautions. temperature probe (Marked “B”) to the underside of the PCB to be worked on.
  • Page 4: Product Description

    PRODUCT DESCRIPTION OPERATING PROCEDURES The Aoyue Int883 IR-Preheating System is a reworking equipment D. TYPE “1” OPERATION that combines infrared (IR) heating technology, enhanced pre-heating Before proceeding with this type of operation, attach the first external area, versatile board holder, and profile control of heating in one temperature probe to the underside of the PCB to be worked on.
  • Page 5: Package Inclusion

    OPERATING PROCEDURES PACKAGE INCLUSION 3. To view the actual temperature read by the internal temperature probe, repeatedly press the selection button until the top display shows the word “Act3”, and the bottom display shows the actual temperature of internal temperature probe followed by a suffix “d”. 4.
  • Page 6: Operating Procedures

    CONTROL PANEL GUIDE OPERATING PROCEDURES A. INITIAL PROCEDURES 1. Make sure all switches are deactivated. 2. Attach external sensor probes to the three pin socket. (#6 on control panel guide) 3. Attach power cord to the power cord attachment (#8 on control panel guide) 4.
