VAXIS SL-1620 User Manual

Long range 1200ft wireless hdmi/sdi hd video transmission suite
Hide thumbs

Advertisement

Quick Links

Download this manual
SL-1620

Advertisement

loading

Related Manuals for VAXIS SL-1620

Summary of Contents for VAXIS SL-1620

  • Page 1 SL-1620...
  • Page 2 Long Range 1200FT Wireless HDMI/SDI HD Video Transmission Suite (VAXIS SL1620) User manual...

  • Page 3: Table Of Contents

    Preface..................... 1 1. Cautions....................2 2. About....................3 3. Installation................... 4 4. Operation instruction................5 5. Maintenance..................6 6. Truble shooting..................7...

  • Page 4: Preface

    Preface Thanks for purchasing our Long Range Wireless HDMI/SDI HD Video Transmission Suite. Before using this product, read this user manual carefully please. Follow the instruction to keep your safety and avoid products damage. This user manual might be modified irregularly because of updated products.

  • Page 5: Cautions

    1. Cautions ■Logo and meaning Careful, warning, dangerous, Pay attend to following items. ■Cautions  Do not use this product in the extreme hot, cold, dusty or humid environments.  Prevent friction with hard objects.  Avoid the product falling down from a high place, or it may damage the hardware.

  • Page 6: About

    2. About ■Product model and standard The VAXIS SL1620 1200FT Wireless HDMI/SDI Transmission Suite utilize today’s most advanced wireless video transmission technology, which can realize the broadcast-class and uncompressed 3G SDI/HDMI HD video signal transmitted with no compression and zero delay. The...
  • Page 7 ■Main features:  HDMI 1.3 spec supports  HDMI and 3G SDI input and output  24fps frame rates  Highest resolution 1080p 60，no delay and no compression  Support audio formats include Dolby True HD, DTS-master, etc.  AES-128 encryption with air interface HD video data stream ...
  • Page 8 All-metal housing, durable  Pure hardware connection; Plug and Play  ■Parameters: Transmitter Receiver SDI Input （BNC Female） ; HDMI Input(Type SDI Output （ BNC Female ） ; HDMI Interface A female); 2 Antenna port(2 SMA male ）; Output(Type A female); 5 Antenna port(SMA male）;...
  • Page 9 ■Product introduction Transmitter: ○ 1 3/8 Screw Hole
 ○ 2 RP-SMA male antenna connector ○ 3 Video input indicator, 1 yellow LED ○ 4 Power on Indicator, 1 green LED...
  • Page 10 ○ 5 Frequency selection knob,1-10
 ○ 6 3G SDI input
 ○ 7 HDMI Input
 ○ 8 DC power switch
 ○ 9 DC input, LEMO 4-pin B series connector ○ 10 1/4 Screw Hole Receiver:...
  • Page 11  2 DC convert cable (LEMO 4 pin-male to D-Type receptacle)  1 user manual, 1 torx screwdriver, 1 1/4-20 screw to ISO518 hot-shoe converter  1 11” Articulating magic arm,1 7” Articulating magic arm  SONY NP-F970 battery plate  VAXIS flight case...

  • Page 12: Installation

    3. Installation ■Installation details and cautions  Transmitter side a) Install 2 Omni-directional and high efficiency antennas to Transmitter’s SMA male antenna connectors. b) There are 3 1/4-20 screw nuts in transmitter metal case, which are located on surface, rear and bottom. So the user can utilize a 1/4 screw to ISO518 hot-shoe converter fix the transmitter on camera.
  • Page 13 c) Install Battery into battery buckle if your product model includes battery buckle option; please note the battery model must match the battery buckle type. d) The user can also utilize a subsidiary LEMO 4 pin male to D-Type receptacle power cable to get power input from an outside power source.

  • Page 14: Operation Instruction

    Connect HDMI or SDI output port of the receiver to SDI or HDMI input port of the HD monitor. Make sure all antennas and batteries are equipped normally. 4. Operation instruction ■Getting started After finishing all steps above, system is workable, follow below steps.
  • Page 15 f) If the camera is on and video input is OK, TX side ‘video’ indicator will light. g) Before RX finished wireless link with TX, 5 “RSSI” indicators and “Video” indicators will be off; when wireless link is OK, “RSSI” indicators will light first, and “RSSI” will indicate the received RF signal strength.
  • Page 16 connected HD monitor will display the video and audio accordingly. i) For the best wireless transmission performance, it need install the transmitter and receiver more than1.5m about the ground and keep the same height, and make sure no obstacles between them; Moreover, it is the best to keep the transmitter antennas face to face, and don’t turn round any sides with too big angle.
  • Page 17 ■ RSSI indicators The receiver will calculate received RF signal strength internally and 5 “RSSI” LEDs will be used to indicate wireless signal power and quality. The user can observe the RSSI LED status to know if the current wireless link is reliable or not.

  • Page 19: Maintenance

    5. Maintenance ■Storage conditions Products storage temperature should be -20°C~60°C. For long time storage requirement, please use original carbon boxes, and avoid from high humid, acid base or dusty place. ■Maintenance Warning To ensure your safety, place choose well-known brand DC batteries, and guarantee suitable work conditions that battery manual mentioned.

  • Page 20: Trouble Shooting

    6. Trouble shooting ■Normal problems a) No output on display Check TX and RX power first, and see if TX or RX is powered from external power, then check if TX antennas and RX antennas are installed right. After that, check ‘Video’ indicator, if TX ‘Video’ indicator is not light, then check SDI or HDMI cable is plugged in and video source is ready please.
