Daikin EWAQ006BAVP Installation Manual
Packaged air-cooled water chillers and packaged air
to water heat pumps
Hide thumbs
Also See for EWAQ006BAVP:
- Installer's reference manual (96 pages) ,
- Operation manual (12 pages)
Table of Contents
Related Manuals for Daikin EWAQ006BAVP
Summary of Contents for Daikin EWAQ006BAVP
-
Page 1: Installation Manual
Installation manual Packaged air-cooled water chillers and packaged air to water heat pumps EWAQ006BAVP EWAQ008BAVP Installation manual EWYQ006BAVP Packaged air-cooled water chillers and packaged air to water heat English EWYQ008BAVP pumps... - Page 2 (mm) † A, B, C — ≥100 ≥250 ≥400 ≥100 ≥150 ≥400 ≥150 A, B, C, E — ≥150 ≥250 ≥150 ≥1000 ≤500 — ≥500 ≥150 — D, E ≥500 ≥1000 ≤500 ≥150 B, D <H ≥250 ≥400 ≥500 ≥150 ≤500 B, D, E <H...
- Page 3 3P469107-2A...
-
Page 4: Table Of Contents
Table of contents About the documentation Table of contents About this document 1 About the documentation Target audience About this document..............Authorised installers 2 About the box INFORMATION Outdoor unit................2.1.1 To remove the accessories from the outdoor unit..This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for 3 Preparation commercial use by lay persons. -
Page 5: About The Box
Daikin website (publicly accessible). INFORMATION ▪ The full set of latest technical data is available on the Daikin extranet (authentication required). The instruction sheet for valve kit EKMBHBP1 only applies in case valve kit EKMBHBP1 is part of the system. If so, do NOT take into account the instruction sheet delivered with the valve kit;... -
Page 6: Preparing Electrical Wiring
4 Installation If valve kit EKMBHBP1 is part of the system, then the NOTICE required cable section is 0.75 mm². If valve kit EKMBHBP1 When circulation in each space heating/cooling loop is is NOT part of the system, then the minimum required controlled by remotely controlled valves, it is important that cable section is 0.75 mm². -
Page 7: Mounting The Outdoor Unit
4 Installation 6× M12 3× Mounting the outdoor unit 4.2.3 To provide drainage 4.2.1 To provide the installation structure Make sure that condensate can be evacuated properly. When the Prepare 6 sets of anchor bolts, nuts and washers (field supply) as unit is in cooling mode, condensate may also form in the hydro part. -
Page 8: To Prevent The Outdoor Unit From Falling Over
4 Installation Water outlet 1 Drill (a, 4×) and remove the knockout hole (b). 1 Screw the outdoor unit nuts on the shut-off valves. 4× Ø6 mm 2 Connect the field piping on the shut-off valves. NOTICE Install a manometer in the system. ... -
Page 9: To Fill The Water Circuit
4 Installation 4 Fill the circuit with water until the manometer (field supply) NOTICE indicates a pressure of ±2.0 bar. Glycol absorbs water from its environment. Therefore do 5 Purge as much air as possible from the water circuit. For NOT add glycol that has been exposed to air. Leaving the instructions, see "6 Commissioning" on page 17. -
Page 10: To Connect The Main Power Supply
4 Installation Routing Possible cables (depends on the installed options) ▪ User interface Low voltage ▪ Interconnection cable to control box EKCB07CAV3 ▪ Remote outdoor sensor (option) ▪ Normal kWh rate power supply High voltage ▪ Preferential kWh rate power supply ▪... -
Page 11: To Connect The Shut-Off Valve
5 Configuration Secure the wiring to the front part of the casing using the Action wiring retainer and clamp. Connect the user interface cable to the outdoor unit. 4.4.4 To connect the shut-off valve 1 Connect the valve control cable to the appropriate terminals as shown in the illustration below. -
Page 12: To Access The Most Used Commands
5 Configuration Result: The user permission level switches to End user. The user interface will return to the default home screen. If you do NOT configure the system correctly, it might NOT work as expected. The configuration influences the following: To modify an overview setting ▪... -
Page 13: Quick Wizard: Standard
5 Configuration 5.2.2 Quick wizard: Standard Code Description [A.2.2.E.2] [5-0D] BUH type: Space heating/cooling settings ▪ 1 (1P,(1/1+2)): 6 kW 1~ 230 V Code Description (default) [A.2.1.7] [C-07] Unit temperature control: ▪ 4 (3PN,(1/2)): 6 kW 3N~ 400 V (*9W) ▪ 0 (LWT control): Unit operation is ▪... -
Page 14: Quick Wizard: Capacities (Energy Metering)
5 Configuration Code Description Code Description [A.2.2.F.3] [D-08] Optional external kWh meter 1: [7.7.1.1] [1-00] Weather-dependent curve (heating): ▪ 0 (No): NOT installed [1-01] ▪ 1: Installed (0.1 pulse/kWh) [1-02] [1-02] ▪ 2: Installed (1 pulse/kWh) [1-03] ▪ 3: Installed (10 pulse/kWh) [1-03] ▪ 4: Installed (100 pulse/kWh) ▪... -
Page 15: Contact/Helpdesk Number
5 Configuration Code Description [8-06] Leaving water temperature maximum modulation: 0°C~10°C (default: 3°C) Requires modulation to be enabled. This is the value by which the desired leaving water temperature is increased or lowered. INFORMATION When leaving water temperature modulation is enabled, the weather‑dependent curve needs to be set to a higher position than [8-06] plus the minimum leaving water temperature setpoint required to reach a stable condition... -
Page 16: Menu Structure: Overview Installer Settings
5 Configuration Menu structure: Overview installer settings Installer settings Language System layout [A.2] System layout Space operation Standard Heat sources [A.2.1] Standard Options System operation Unit type Capacities Commissioning Compressor type Confirm layout Overview settings Indoor software type Unit control method Pump operation mode Power saving possible User interface location... -
Page 17: Commissioning
6 Commissioning NOTICE Commissioning ▪ Make sure glycol setting [E-0D] matches the liquid NOTICE inside the water circuit (0=water only, 1=water+glycol). If the glycol setting is NOT set correctly, the liquid NEVER operate the unit without thermistors and/or inside the piping can freeze. pressure sensors/switches. -
Page 18: To Perform A Test Run
7 Hand-over to the user INFORMATION INFORMATION ▪ To purge air, use all air purge valves present in the Make sure that all air is purged before executing the test system. This includes the manual air purge valve of the run. -
Page 19: About Locking And Unlocking
7 Hand-over to the user ▪ Explain the user about energy saving tips as described in the operation manual. About locking and unlocking If required, it is possible to lock the buttons of the main user interface, making it impossible for the user to operate it. For the user to be able to change setpoint temperatures, the simplified user interface or an external room thermostat is then required. -
Page 20: Technical Data
8 Technical data Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin extranet (authentication required). Piping diagram: Outdoor unit t >... -
Page 21: Wiring Diagram: Outdoor Unit
8 Technical data Wiring diagram: Outdoor unit See the internal wiring diagram supplied with the unit (on the inside of the outdoor unit switch box cover). The abbreviations used are listed below. Outdoor unit: compressor module Symbols: Legend: Live Neutral Printed circuit board (main) Field wiring Printed circuit board... - Page 22 8 Technical data English Translation English Translation Wiring depending on model R1H (A3P) Humidity sensor PC (A7P) Power circuit Switch box Q*DI # Earth leakage circuit breaker R1T (A3P) Ambient sensor On/OFF (4) Legend (4) Legend thermostat Main PCB External sensor (floor or ambient) Current loop PCB # Preferential kWh rate power # Shut-off valve...
- Page 23 8 Technical data English Translation Min. load Minimum load Ext. heat source External heat source Power limitation digital inputs: 5 Power limitation digital inputs: V DC detection (voltage supplied 5 V DC detection (voltage by PCB) supplied by PCB) External indoor ambient sensor External indoor ambient sensor option option...
-
Page 24: Power Supply
8 Technical data Electrical connection diagram Notes: Typical configuration - In case of signal cable: keep minimum distance to power cables > 5 cm - Available heaters: see combination table Standard part 2 low voltage wires Minichiller unit Power supply Standard: 4 low voltage wires Control Optional: 4 high voltage wires... - Page 28 4P478610-1 2017.02...
