ESIE07-03
Service Manual
EWAD190-600AJYNN
EWAD210-500AJYNN/Q
EWAD260-650AJYNN/A
EWAD200-600AJYNN/H
EWAD330-520AJYNN/S
EWAD330-520AJYNN/X
EWYD260-380AJYNN
Air-cooled units with R134a refrigerant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWAD190-600AJYNN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daikin EWAD190-600AJYNN

Summary of Contents for Daikin EWAD190-600AJYNN

  • Page 1 ESIE07-03 Service Manual EWAD190-600AJYNN EWAD210-500AJYNN/Q EWAD260-650AJYNN/A EWAD200-600AJYNN/H EWAD330-520AJYNN/S EWAD330-520AJYNN/X EWYD260-380AJYNN Air-cooled units with R134a refrigerant...

  • Page 3: Table Of Contents

    ESIE 07-03 Table of Contents Introduction About This Manual .................. i–i Nomenclature..................i–ii Part 1 System Outline General Outline What Is in This Chapter? ................ 1–3 Technical Specifications: EWAD-AJYNN..........1–5 Technical Specifications: EWAD-AJYNN/Q ..........1–11 Technical Specifications: EWAD-AJYNN/A ..........1–15 Technical Specifications: EWAD-AJYNN/H ..........
  • Page 4 ESIE 07-03 Piping Layout What Is in This Chapter? ................. 1–127 Piping Diagram: EWAD-AJYNN(/Q) with Thermostatic Expansion Valve 1–128 Piping Diagram: EWAD-AJYNN(/Q) with Electronic Expansion Valve ..1–130 Piping Diagram: EWAD-AJYNN/A with Thermostatic Expansion Valve .. 1–132 Piping Diagram: EWAD-AJYNN/A with Electronic Expansion Valve ..1–134 Piping Diagram: EWAD-AJYNN(/Q) with Thermostatic Expansion Valve and Partial Heat-Recovery................
  • Page 5 ESIE 07-03 Part 2 Functional Description Operation Range What Is in This Chapter? ................ 2–3 Operational Range: EWAD-AJYNN ............2–4 Operational Range: EWAD-AJYNN+OPLN ..........2–4 Operational Range: EWAD-AJYNN/Q ............ 2–5 Operational Range: EWAD-AJYNN/A............. 2–5 Operational Range: EWAD-AJYNN/A+OPLN......... 2–6 Operational Range: EWAD-AJYNN/H ............ 2–6 Operational Range EWAD-AJYNN/S and EWAD-AJYNN/X....
  • Page 6 ESIE 07-03 Part 3 Troubleshooting Alarm Messages What Is in This Chapter? ................. 3–3 Overview of the Alarm Messages ............3–4 Table of Contents...

  • Page 7: About This Manual

    EWAD190-600AJYNN (reduced noise): 75.0 - 79.0 dB(A) ■ EWAD440-600AJYNN + OPRN (reduced noise): 74.5 - 76.5 dB(A) ■ EWAD190-600AJYNN + OPLN (low noise): 70.0 - 73.0 dB(A) ■ EWAD190-600AJYNN/Q (super silent): 65.0 - 66.0 dB(A) ■ EWAD190-600AJYNN/H (high ambient): 77.0 - 79.5 dB(A) ■...
  • Page 8 Introduction ESIE 07-03 Nomenclature Machine type ERA : Air cooled condensing unit EWW : Water cooled packaged water chiller EWL : Remote condenser water chiller EWA : Air cooled chiller, cooling only EWY : Air cooled chiller, heatpump EWC : Air cooled chiller, cooling only with centrifugal fan EWT : Air cooled chiller, cooling only with heat recovery Refrigerant D : R-134a...

  • Page 9: Part 1 System Outline

    ESIE07-03 Part 1 System Outline Introduction This part contains an outline of all the relevant elements in the EWAD-AJYNN and EWDYD-AJYNN Air-cooled units. What is in this part? This part contains the following chapters: Chapter See page 1–General Outline 1–3 2–Piping Layout 1–127 3–Wiring Layout...
  • Page 10 ESIE07-03 1–2 Part 1 – System Outline...

  • Page 11: General Outline

    ESIE07-03 General Outline Part 1 General Outline What Is in This Chapter? Introduction This chapter contains the following information: Technical specifications  Electrical specifications  Outlook drawings  Capacity tables  Capacity correction factors  Heat recovery ratings  Sound level data. ...
  • Page 12 General Outline ESIE07-03 Topic See page 1.26–Cooling Capacity Tables: EWYD-AJYNN 1–85 1.27–Cooling Capacity Tables: EWYD-AJYNN + OPLN 1–92 1.28–Heating Capacity Tables: EWYD-AJYNN (+OPLN) 1–99 1.29–Capacity Correction Factors: EWAD-AJYNN 1–103 1.30–Capacity Correction Factors: EWYD-AJYNN 1–104 1.31–Heat Recovery Ratings: EWAD-AJYNN 1–105 1.32–Heat Recovery Ratings: EWYD-AJYNN 1–114 1.33–Partial Heat Recovery Ratings: EWAD-AJYNN/S &...
  • Page 13 ESIE07-03 General Outline Technical Specifications: EWAD-AJYNN Technical The table below contains the technical specifications for EWAD190-300AJYNN. specifications Model EWAD-AJYNN Unit size Capacity Cooling Nominal 184.0 197.8 225.0 245.0 261.0 275.0 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 81.3...
  • Page 14 General Outline ESIE07-03 Model EWAD-AJYNN Unit size Type Helical Drive Direct drive Diameter Nominal air flow 1374 1374 1356 1338 Model Quantity Speed Motor 1160 1160 1160 1160 1160 1160 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge Model...
  • Page 15 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWAD320-480AJYNN. specifications Model EWAD-AJYNN Unit size Capacity Cooling Nominal 298.4 321.0 370.0 401.3 451.0 478.7 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 119.4 123.4 133.4...
  • Page 16 General Outline ESIE07-03 Model EWAD-AJYNN Unit size Type Helical Drive Direct drive Diameter Nominal air flow 1338 1836 1836 1938 2694 2640 /min Model Quantity Speed Motor 1160 1160 1160 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge...
  • Page 17 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWAD500-600AJYNN. specifications Model EWAD-AJYNN Unit size Capacity Cooling Nominal 510.1 551.0 588.0 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 186.9 195.6 202.9 (Eurovent conditions specified in...
  • Page 18 General Outline ESIE07-03 Model EWAD-AJYNN Unit size Type Helical Drive Direct drive Diameter Nominal air flow 2580 2580 2580 /min Model Quantity Speed Motor 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge Model Quantity...

  • Page 19: Technical Specifications: Ewad-Ajynn/Q

    ESIE07-03 General Outline Technical Specifications: EWAD-AJYNN/Q Technical The table below contains the technical specifications for EWAD210-320AJYNN/Q. specifications Model EWAD-AJYNN/Q Unit size Capacity Cooling Nominal 203.0 231.1 252.7 270.8 286.1 299.4 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 79.8...
  • Page 20 General Outline ESIE07-03 Model EWAD-AJYNN/Q Unit size Type Helical Drive Direct drive Diameter Nominal air flow 1074 1032 1032 1032 1032 /min Model Quantity Speed Motor Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge Model Quantity Model...
  • Page 21 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWAD340-500AJYNN/Q. specifications Model EWAD-AJYNN/Q Unit size Capacity Cooling Nominal 308.8 400.5 428.5 458.4 500.8 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 136.3 156.0 173.8 182.4...
  • Page 22 General Outline ESIE07-03 Model EWAD-AJYNN/Q Unit size Type Helical Drive Direct drive Diameter Nominal air flow 1032 1704 1644 1926 2208 /min Model Quantity Speed Motor Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge Model Quantity Model...

  • Page 23: Technical Specifications: Ewad-Ajynn/A

    ESIE07-03 General Outline Technical Specifications: EWAD-AJYNN/A Technical The table below contains the technical specifications for EWAD260-380AJYNN/A. specifications Model EWAD-AJYNN/A Unit size Capacity Cooling Nominal 247.0 275.0 301.5 327.0 351.0 376.0 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 79.2...
  • Page 24 General Outline ESIE07-03 Model EWAD-AJYNN/A Unit size Type Helical Drive Direct drive Diameter Nominal air flow 1338 1836 1782 1782 1782 2640 /min Model Quantity Speed Motor 1160 1160 1160 1160 1160 1160 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge...
  • Page 25 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWAD420-650AJYNN/A. specifications Model EWAD-AJYNN/A Unit size Capacity Cooling Nominal 401.0 501.4 531.5 582.2 626.6 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 127.5 160.6 170.9 183.5...
  • Page 26 General Outline ESIE07-03 Model EWAD-AJYNN/A Unit size Type Helical Drive Direct drive Diameter Nominal air flow 2580 2580 2580 3228 3228 /min Model Quantity Speed Motor 1160 1730 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge Model...

  • Page 27: Technical Specifications: Ewad-Ajynn/H

    ESIE07-03 General Outline Technical Specifications: EWAD-AJYNN/H Technical The table below contains the technical specifications for EWAD200-300AJYNN/H. specifications Model EWAD-AJYNN/H Unit size Capacity Cooling Nominal 194.6 208.3 233.5 256.1 273.7 289.3 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 77.2...
  • Page 28 General Outline ESIE07-03 Model EWAD-AJYNN/H Unit size Type Helical Drive Direct drive Diameter Nominal air flow 1434 1368 2154 2154 2100 2046 /min Model Quantity Speed Motor 1800 1800 1800 1800 1800 1800 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge...
  • Page 29 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWAD320-480AJYNN/H. specifications Model EWAD-AJYNN/H Unit size Capacity Cooling Nominal 306.4 335.6 381.2 426.0 468.1 502.1 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 112.1 120.3 127.4...
  • Page 30 General Outline ESIE07-03 Model EWAD-AJYNN/H Unit size Type Helical Drive Direct drive Diameter Nominal air flow 2046 2874 2874 2580 3372 3300 /min Model Quantity Speed Motor 1800 1800 1800 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge...
  • Page 31 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWAD500-600AJYNN/H. specifications Model EWAD-AJYNN/H Unit size Capacity Cooling Nominal 529.5 561.0 600.4 (Eurovent conditions specified in notes) Capacity Steps 12.5 - 100 Nominal input Cooling 180.1 192.2 198.4 (Eurovent conditions specified in...
  • Page 32 General Outline ESIE07-03 Model EWAD-AJYNN/H Unit size Type Helical Drive Direct drive Diameter Nominal air flow 3228 3228 3228 /min Model Quantity Speed Motor 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil type Mobil Artic 68 Refrigerant oil charge Model Quantity...

  • Page 33: Technical Specifications: Ewad-Ajynn/S

    ESIE07-03 General Outline Technical Specifications: EWAD-AJYNN/S Technical The table below contains the technical specifications for EWAD330-520AJYNN/S specifications Model EWAD-AJYNN/H Unit size Capacity Cooling Nominal (Eurovent) Capacity Type stepless control Minimum capacity 12.5 12.5 12.5 12.5 12.5 12.5 12.5 Capacity Steps 13.5 - 100 Nominal Input Cooling...
  • Page 34 General Outline ESIE07-03 Model EWAD-AJYNN/H Unit size Compressor Type Single screw compressor Refrigerant oil type Artic Mobil 68H Refrigerant oil charge Model Quantity Model HSS3118 HSS3118 HSS3120 HSS3120 HSS3121 HSS3121 HSS3122 VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS S3118 S3120 S3120 S3121 S3121...

  • Page 35: Technical Specifications: Ewad-Ajynn/X

    ESIE07-03 General Outline Technical Specifications: EWAD-AJYNN/X Technical The table below contains the technical specifications for EWAD330-520AJYNN/X specifications Model EWAD-AJYNN/H Unit size Capacity Cooling Nominal (Eurovent) Capacity Type stepless control Minimum capacity 12.5 12.5 12.5 12.5 12.5 12.5 12.5 Capacity Steps 13.5 - 100 Nominal Input Cooling...
  • Page 36 General Outline ESIE07-03 Model EWAD-AJYNN/H Unit size Compressor Type Single screw compressor Refrigerant oil type Artic Mobil 68H Refrigerant oil charge Model Quantity Model HSS3118 HSS3118 HSS3120 HSS3120 HSS3121 HSS3121 HSS3122 VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS VR2.0+HS S3118 S3120 S3120 S3121 S3121...

  • Page 37: Technical Specifications: Ewyd-Ajynn

    ESIE07-03 General Outline Technical Specifications: EWYD-AJYNN Technical The table below contains the technical specifications for EWYD260-320AJYNN. specifications Model EWYD-AJYNN Unit size Capacity Cooling Nominal (Eurovent Heating Nominal conditions specified in notes) Capacity Type test Control Minimum capacity 15.5 15.5 15.5 15.5 Nominal input Cooling...
  • Page 38 General Outline ESIE07-03 Model EWYD-AJYNN Unit size Type Axial Drive Direct drive Diameter Nominal air flow 1932 1914 1908 2580 /min Model Quantity Speed Motor 1730 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil charge Model Quantity Sound Level Sound...
  • Page 39 ESIE07-03 General Outline Technical The table below contains the technical specifications for EWYD340-380AJYNN. specifications Model EWYD-AJYNN Unit size Capacity Cooling Nominal (Eurovent Heating Nominal conditions specified in notes) Capacity Type test Control Minimum capacity 15.5 15.5 15.5 Nominal input Cooling (Eurovent Heating conditions...
  • Page 40 General Outline ESIE07-03 Model EWYD-AJYNN Unit size Type Axial Drive Direct drive Diameter Nominal air flow 2580 2568 2544 /min Model Quantity Speed Motor 1730 1730 1730 Output Compressor Type Semi-hermetic single screw compressor Refrigerant oil charge Model Quantity Sound level Sound Cooling 100.4...

  • Page 41: Electrical Specifications: Ewad-Ajynn

    ESIE07-03 General Outline Electrical Specifications: EWAD-AJYNN Electrical The table below contains the electrical specifications for EWAD190-300AJYNN. specifications Model EWAD-AJYNN Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 209.3 208.4 219.7 219.7 263.8 272.5 Nominal Running Current...
  • Page 42 General Outline ESIE07-03 Model EWAD-AJYNN Unit size Notes Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%. Max unit starting current: Starting Max unit starting current: Max unit current of biggest compressor + 75% of Absorbed current of starting nominal absorbed current of the other...
  • Page 43 ESIE07-03 General Outline Model EWAD-AJYNN Unit size Compressor Phase Voltage Voltage Minimum -10% Tolerance Maximum +10% Maximum Running Current 233.3 246.6 291.9 323.3 336.7 Power factor 0.89 0.87 0.87 0.89 Starting Method Star-delta Notes Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ±...
  • Page 44 General Outline ESIE07-03 Model EWAD-AJYNN Unit size Pump Type Standard pump (OPSP) Phase Power input 11.0 11.0 11.0 Voltage Maximum Running Current 20.0 20.0 20.0 Type High ESP pump (OPHP) Phase Power input 11.0 11.0 11.0 Voltage Maximum Running Current 20.0 20.0 20.0...

  • Page 45: Electrical Specifications: Ewad-Ajynn/Q

    ESIE07-03 General Outline 1.10 Electrical Specifications: EWAD-AJYNN/Q Electrical The table below contains the electrical specifications for EWAD210-320AJYNN/Q. specifications Model EWAD-AJYNN/Q Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 207.9 218.7 218.1 262.7 273.8 285.7...
  • Page 46 General Outline ESIE07-03 Electrical The table below contains the electrical specifications for EWAD340-500AJYNN/Q. specifications Model EWAD-AJYNN/Q Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 285.7 385.0 405.0 407.2 413.7 Nominal Running Current 224.8 264.2 290.9...

  • Page 47: Electrical Specifications: Ewad-Ajynn/A

    ESIE07-03 General Outline 1.11 Electrical Specifications: EWAD-AJYNN/A Electrical The table below contains the electrical specifications for EWAD260-380AJYNN/A. specifications Model EWAD-AJYNN/A Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 211.4 224.8 223.4 267.8 278.3 291.1...
  • Page 48 General Outline ESIE07-03 Electrical The table below contains the electrical specifications for EWAD420-650AJYNN/A. specifications Model EWAD-AJYNN/A Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 291.1 395.7 417.9 418.3 428.1 Nominal Running Current 212.4 273.7 290.2...

  • Page 49: Electrical Specifications: Ewad-Ajynn/H

    ESIE07-03 General Outline 1.12 Electrical Specifications: EWAD-AJYNN/H Electrical The table below contains the electrical specifications for EWAD200-300AJYNN/H. specifications Model EWAD-AJYNN/H Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 212.2 211.3 226.1 226.1 270.1 278.3...
  • Page 50 General Outline ESIE07-03 Electrical The table below contains the electrical specifications for EWAD320-480AJYNN/H. specifications Model EWAD-AJYNN/H Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 286.9 293.0 296.7 391.6 412.0 412.7 Nominal Running Current 193.6 207.9 217.9...
  • Page 51 ESIE07-03 General Outline Electrical The table below contains the electrical specifications for EWAD500-600AJYNN/H. specifications Model EWAD-AJYNN/H Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current 420.9 424.3 430.0 Nominal Running Current 298.4 315.0 322.6 Cooling...

  • Page 52: Electrical Specifications: Ewad-Ajynn/S

    General Outline ESIE07-03 1.13 Electrical Specifications: EWAD-AJYNN/S Electrical The table below contains the electrical specifications for EWAD330-520AJYNN/S. specifications Model EWAD-AJYNN/Q Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current Maximum starting current Starting current soft start Nominal Running Current Cooling...
  • Page 53 ESIE07-03 General Outline Model EWAD-AJYNN/Q Unit size Evaporator Supply voltage Heater Tape Capacity Voltage Minimum -10% Tolerance Maximum +10% Recommended fuses 2 A gG Notes Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%. Nominal current in cooling mode is referred to installation with 25kA short circuit current and is based on the following conditions: evaporator 12°C/7°C;...

  • Page 54: Electrical Specifications: Ewad-Ajynn/X

    General Outline ESIE07-03 1.14 Electrical Specifications: EWAD-AJYNN/X Electrical The table below contains the electrical specifications for EWAD330-520AJYNN/X. specifications Model EWAD-AJYNN/Q Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current Maximum starting current Starting current soft start Nominal Running Current Cooling...
  • Page 55 ESIE07-03 General Outline Model EWAD-AJYNN/Q Unit size Evaporator Supply voltage Heater Tape Capacity Voltage Minimum -10% Tolerance Maximum +10% Recommended fuses 2 A gG Notes Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%. Nominal current in cooling mode is referred to installation with 25kA short circuit current and is based on the following conditions: evaporator 12°C/7°C;...

  • Page 56: Electrical Specifications: Ewyd-Ajynn

    General Outline ESIE07-03 1.15 Electrical Specifications: EWYD-AJYNN Electrical The table below contains the electrical specifications for EWYD260-320AJYNN. Specifications Model EWYD-AJYNN Unit size Power Supply Name Phase Frequency Voltage Voltage Minimum -10% Tolerance Maximum +10% Unit Starting Current Nominal Running Current Cooling Nominal Running Current Heating...
  • Page 57 ESIE07-03 General Outline Model EWYD-AJYNN Unit size Notes Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%. Nominal current in cooling mode is referred to installation with 25kA short circuit current and is based on the following conditions: evaporator 12°C/7°C, ambient 35°C.
  • Page 58 General Outline ESIE07-03 Model EWYD-AJYNN Unit size Pump Type Single pump - Low ESP (OPSP) Phase Power input Voltage Nominal Running Current Type Single pump - High ESP (OPHP) Phase Power input Voltage Nominal Running Current 10.1 10.1 10.1 Type Double pump - Low ESP (OPTP) Phase Power input...

  • Page 59: Outlook Drawings

    ESIE07-03 General Outline 1.16 Outlook Drawings Note Due to the fact that not one unit is the same, it is not possible to provide the dimensional drawings for all units in this Service Manual. However, for every serial number, there is a dimensional drawing available on http://passdoor.mcquay.it Part 1 –...

  • Page 60: Capacity Tables: Ewad-Ajynn

    General Outline ESIE07-03 1.17 Capacity Tables: EWAD-AJYNN EWAD190-280AJYN The table below contains the capacity tables for EWAD190-280AJYNN. Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap. input cap.
  • Page 61 ESIE07-03 General Outline EWAD300-400AJYN The table below contains the capacity tables for EWAD300-400AJYNN. Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap. input cap. input (kW) (kW) (kW) (kW)
  • Page 62 General Outline ESIE07-03 EWAD420-600AJYN The table below contains the capacity tables for EWAD420-600AJYNN. NOG GEEN GEGEVENS BESCHIKBAAR Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap. input cap.

  • Page 63: Capacity Tables: Ewad-Ajynn + Oprn

    ESIE07-03 General Outline 1.18 Capacity Tables: EWAD-AJYNN + OPRN EWAD440-600AJYN The table below contains the capacity tables for EWAD440-600AJYNN + OPRN. N + OPRN Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap.
  • Page 64 General Outline ESIE07-03 Note: CC (Cooling Capacity) and PI (Power Input) referred to evaporator fouling factor=0,0176m °C/kW.  Shaded values are referred to part load operation.  1–56 Part 1 – System Outline...

  • Page 65: Capacity Tables: Ewad-Ajynn + Opln

    ESIE07-03 General Outline 1.19 Capacity Tables: EWAD-AJYNN + OPLN EWAD190-280AJYN The table below contains the capacity tables for EWAD190-280AJYNN + OPLN. N + OPLN Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap.
  • Page 66 General Outline ESIE07-03 EWAD300-440AJYN The table below contains the capacity tables for EWAD300-440AJYNN + OPLN. N + OPLN Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap.
  • Page 67 ESIE07-03 General Outline EWAD480-600AJYN The table below contains the capacity tables for EWAD480-600AJYNN + OPLN. N + OPLN Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap.

  • Page 68: Capacity Tables: Ewad-Ajynn/A

    General Outline ESIE07-03 1.20 Capacity Tables: EWAD-AJYNN/A EWAD260-360AJYN The table below contains the capacity tables for EWAD260-360AJYNN/A. Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 238,2 56,3 232,9 62,7 226,3 69,6 218,6 77,2...
  • Page 69 ESIE07-03 General Outline EWAD380-600AJYN The table below contains the capacity tables for EWAD380-600AJYNN/A. Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 361,5 82,6 354,3 91,9 345,6 102,2 334,8 113,2 319,1 127,5 313,1 132,4...

  • Page 70: Capacity Tables: Ewad-Ajynn/A + Opln

    General Outline ESIE07-03 1.21 Capacity Tables: EWAD-AJYNN/A + OPLN EWAD260-360AJYN The table below contains the capacity tables for EWAD260-360AJYNN/A + OPLN. N/A + OPLN Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 202,5...
  • Page 71 ESIE07-03 General Outline EWAD380-600AJYN The table below contains the capacity tables for EWAD380-600AJYNN/A + OPLN. N/A + OPLN Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 358,0 87,2 350,0 97,0 340,3 107,7 328,5...
  • Page 72 General Outline ESIE07-03 EWAD650AJYNN/A The table below contains the capacity tables for EWAD650AJYNN/A + OPLN. + OPLN Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 596,6 150,4 581,9 165,7 564,7 182,8 545,0 201,9...

  • Page 73: Capacity Tables: Ewad-Ajynn/H

    ESIE07-03 General Outline 1.22 Capacity Tables: EWAD-AJYNN/H EWAD200-280AJYN The table below contains the capacity tables for EWAD200-280AJYNN/H. Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 195,8 55,6 187,0 61,2 177,7 67,2 167,9 73,8...
  • Page 74 General Outline ESIE07-03 EWAD300-420AJYN The table below contains the capacity tables for EWAD300-420AJYNN/H. Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 289,4 74,1 276,5 81,5 262,7 89,4 248,4 98,1 230,1 109,5 221,6 113,2...
  • Page 75 ESIE07-03 General Outline EWAD460-600AJYN The table below contains the capacity tables for EWAD460-600AJYNN/H. Air Ambient Temperature (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 373,3 171,8 364,0 179,0 422,6 137,4 400,0 152,0 112,9 447,5 124,7 468,3...

  • Page 76: Capacity Tables: Ewad-Ajynn/Q

    General Outline ESIE07-03 1.23 Capacity Tables: EWAD-AJYNN/Q EWAD210-300AJYN The table below contains the capacity tables for EWAD210-300AJYNN/Q. Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap. input cap.
  • Page 77 ESIE07-03 General Outline EWAD320-460AJYN The table below contains the capacity tables for EWAD320-460AJYNN/Q. Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap. input cap. input (kW) (kW) (kW) (kW)
  • Page 78 General Outline ESIE07-03 EWAD500AJYNN/Q The table below contains the capacity tables for EWAD500AJYNN/Q. Air Ambient Temperature (°C) Unit size Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. Cool. Pow. cap. input cap. input cap. input cap. input cap. input (kW) (kW) (kW) (kW)

  • Page 79: Capacity Tables: Ewad-Ajynn/S

    ESIE07-03 General Outline 1.24 Capacity Tables: EWAD-AJYNN/S EWAD330AJNN/S The table below contains the capacity tables for EWAD330AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) 86.3 87.2 88.1 89.9 90.9 91.8 92.7 93.7 94.6 95.6 96.6 CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 80 General Outline ESIE07-03 EWAD360AJNN/S The table below contains the capacity tables for EWAD360AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) 97.9 CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 81 ESIE07-03 General Outline EWAD400AJNN/S The table below contains the capacity tables for EWAD400AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 82 General Outline ESIE07-03 EWAD420AJNN/S The table below contains the capacity tables for EWAD420AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 83 ESIE07-03 General Outline EWAD460AJNN/S The table below contains the capacity tables for EWAD460AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 84 General Outline ESIE07-03 EWAD490AJNN/S The table below contains the capacity tables for EWAD490AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 85 ESIE07-03 General Outline EWAD520AJNN/S The table below contains the capacity tables for EWAD520AJYNN/S (+OPRN). (+OPRN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)

  • Page 86: Capacity Tables: Ewad-Ajynn/X

    General Outline ESIE07-03 1.25 Capacity Tables: EWAD-AJYNN/X EWAD330AJNN/X The table below contains the capacity tables for EWAD330AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) 84.4 85.3 86.2 87.1 89.9 90.8 91.8 92.7 93.7 94.7 CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 87 ESIE07-03 General Outline EWAD360AJNN/X The table below contains the capacity tables for EWAD360AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) 97.1 98.3 99.4 CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 88 General Outline ESIE07-03 EWAD400AJNN/X The table below contains the capacity tables for EWAD400AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 89 ESIE07-03 General Outline EWAD420AJNN/X The table below contains the capacity tables for EWAD420AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 90 General Outline ESIE07-03 EWAD460AJNN/X The table below contains the capacity tables for EWAD460AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 91 ESIE07-03 General Outline EWAD490AJNN/X The table below contains the capacity tables for EWAD490AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 92 General Outline ESIE07-03 EWAD520AJNN/X The table below contains the capacity tables for EWAD520AJYNN/X (+OPRN) (+OPLN). (+OPRN) (+OPLN) Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)

  • Page 93: Cooling Capacity Tables: Ewyd-Ajynn

    ESIE07-03 General Outline 1.26 Cooling Capacity Tables: EWYD-AJYNN EWYD260AJYNN The table below contains the cooling capacity table for EWYD260AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) 68.8 69.7 70.6 71.5 72.4 73.3 74.3 75.2 76.2 77.2 78.1 CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 94 General Outline ESIE07-03 EWYD280AJYNN The table below contains the cooling capacity table for EWYD280AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) 75.5 75.9 76.6 77.4 78.4 79.5 80.6 81.7 82.8 83.7 84.6 85.2 CC (kW) PI (kW) CC (kW) PI (kW) 79.9 80.6...
  • Page 95 ESIE07-03 General Outline EWYD300AJYNN The table below contains the cooling capacity table for EWYD300AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) 81.1 82.1 83.2 84.5 85.8 87.1 88.3 89.5 90.5 91.3 91.9 92.1 CC (kW) PI (kW) CC (kW) PI (kW) 86.3 87.2...
  • Page 96 General Outline ESIE07-03 EWYD320AJYNN The table below contains the cooling capacity table for EWYD320AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) 87.6 88.9 90.1 91.1 92.9 93.8 94.8 95.8 96.9 98.1 99.6 CC (kW) PI (kW) CC (kW) PI (kW) 95.5 96.8 99.1...
  • Page 97 ESIE07-03 General Outline EWYD340AJYNN The table below contains the cooling capacity table for EWYD340AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) 92.4 93.5 94.6 95.8 96.9 98.1 99.3 CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 98 General Outline ESIE07-03 EWYD360AJYNN The table below contains the cooling capacity table for EWYD360AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) 99.7 CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 99 ESIE07-03 General Outline EWYD380AJYNN The table below contains the cooling capacity table for EWYD380AJYNN. Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)

  • Page 100: Cooling Capacity Tables: Ewyd-Ajynn + Opln

    General Outline ESIE07-03 1.27 Cooling Capacity Tables: EWYD-AJYNN + OPLN EWYD260AJYNN + The table below contains the cooling capacity table for EWYD260AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) 65.8 66.7 67.7 68.6 69.6 70.7 71.7 72.8 73.8 76.1...
  • Page 101 ESIE07-03 General Outline EWYD280AJYNN + The table below contains the cooling capacity table for EWYD280AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) 73.3 74.5 75.5 76.6 77.6 78.7 79.7 80.8 81.9 83.2 84.5 85.9 CC (kW) PI (kW) CC (kW) PI (kW)
  • Page 102 General Outline ESIE07-03 EWYD300AJYNN + The table below contains the cooling capacity table for EWYD300AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) 80.6 83.2 84.3 85.4 86.4 87.4 88.5 89.7 92.5 94.2 CC (kW) PI (kW) CC (kW) PI (kW) 85.4...
  • Page 103 ESIE07-03 General Outline EWYD320AJYNN + The table below contains the cooling capacity table for EWYD320AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) 85.2 85.9 86.7 87.8 90.3 91.6 94.3 95.5 96.6 97.6 CC (kW) PI (kW) CC (kW) PI (kW) 90.9...
  • Page 104 General Outline ESIE07-03 EWYD340AJYNN + The table below contains the cooling capacity table for EWYD340AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) 89.7 90.9 92.2 93.5 94.8 96.2 97.6 CC (kW) PI (kW) CC (kW) PI (kW) 99.3 CC (kW) PI (kW)
  • Page 105 ESIE07-03 General Outline EWYD360AJYNN + The table below contains the cooling capacity table for EWYD360AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) 98.4 99.9 CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW)
  • Page 106 General Outline ESIE07-03 EWYD380AJYNN + The table below contains the cooling capacity table for EWYD380AJYNN + OPLN. OPLN Leaving Water Temp. (°C) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW) CC (kW) PI (kW)

  • Page 107: Heating Capacity Tables: Ewyd-Ajynn (+Opln)

    ESIE07-03 General Outline 1.28 Heating Capacity Tables: EWYD-AJYNN (+OPLN) EWYD260-280AJYN The table below contains the heating capacity tables for EWYD260-280AJYNN (+OPLN). N (+OPLN) Leaving Water Temp. (°C) HC (kW) PI (kW) 79.2 80.5 81.8 83.2 84.6 87.5 90.6 92.1 93.7 95.3 98.6 HC (kW)
  • Page 108 General Outline ESIE07-03 EWYD300-320AJYN The table below contains the heating capacity tables for EWYD300-320AJYNN (+OPLN). N (+OPLN) Leaving Water Temp. (°C) HC (kW) PI (kW) 96.7 98.4 HC (kW) PI (kW) HC (kW) PI (kW) 90.2 91.8 93.4 95.1 96.8 98.5 HC (kW) PI (kW)
  • Page 109 ESIE07-03 General Outline EWYD340-360AJYN The table below contains the heating capacity tables for EWYD340-360AJYNN (+OPLN). N (+OPLN) Leaving Water Temp. (°C) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) 96.4 98.3 HC (kW)
  • Page 110 General Outline ESIE07-03 EWYD380AJYNN The table below contains the cooling capacity table for EWYD380AJYNN (+OPLN). (+OPLN) Leaving Water Temp. (°C) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW) PI (kW) HC (kW)

  • Page 111: Capacity Correction Factors: Ewad-Ajynn

    ESIE07-03 General Outline 1.29 Capacity Correction Factors: EWAD-AJYNN Evaporator fouling The table below gives the evaporator fouling factors factors Fouling factors Cooling capacity Power input COP correction factor m²°C / kW correction factor correction factor 0.0176 1.000 1.000 1.000 0.0440 0.978 0.986 0.992...

  • Page 112: Capacity Correction Factors: Ewyd-Ajynn

    General Outline ESIE07-03 1.30 Capacity Correction Factors: EWYD-AJYNN Evaporator fouling The table below gives the evaporator fouling factors factors Fouling factors Cooling capacity Power input EER correction factor m²°C / kW correction factor correction factor 0.0176 1.000 1.000 1.000 0.0440 0.978 0.986 0.992...

  • Page 113: Heat Recovery Ratings: Ewad-Ajynn

    ESIE07-03 General Outline 1.31 Heat Recovery Ratings: EWAD-AJYNN EWAD-AJYNN & EWAD-AJYNN/Q & EWAD190AJYNN EWAD200AJYNN/H EWAD200AJYNN EWAD-AJYNN/H EWAD210AJYNN/Q EWAD210AJYNN/H diagram EWAD230AJYNN EWAD240AJYNN/Q EWAD240AJYNN/H EWAD260AJYNN EWAD260AJYNN/Q EWAD260AJYNN/H EWAD280AJYNN EWAD280AJYNN/H EWAD280AJYNN/H EWAD300AJYNN EWAD300AJYNN/Q EWAD300AJYNN/H EWAD320AJYNN EWAD320AJYNN/Q EWAD320AJYNN/H EWAD340AJYNN EWAD340AJYNN/Q EWAD340AJYNN/H EWAD360AJYNN EWAD400AJYNN/H EWAD400AJYNN/H EWAD400AJYNN/Q EWAD420AJYNN/H EWAD400AJYNN...
  • Page 114 General Outline ESIE07-03 EWAD200-300AJYN N & Heat Recovery Exchanger Leaving Water Temperature Totale (°C) EWAD200-300AJYN Unit size N/H table (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 186.1 59.7 245.8 175.4 65.7 241.1 163.8 72.2 236.0 151.2 79.1 230.3 192.8...
  • Page 115 ESIE07-03 General Outline EWAD320-440AJYN N & Heat Recovery Exchanger Leaving Water Temperature Totale (°C) EWAD320-420AJYN Unit size N/H table (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 302.9 82.2 385.1 288.7 90.6 379.3 273.7 99.8 373.5 257.7 109.9 367.6 313.2 82.9 396.1 298.7...
  • Page 116 General Outline ESIE07-03 EWAD480-550AJYN N & Heat Recovery Exchanger Leaving Water Temperature Totale (°C) EWAD480-550JYNN Unit size /H table (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 428.8 133.9 562.7 406.2 148.2 554.4 383.1 164.3 547.4 359.8 182.2 542.0 443.3 135.0 578.3 420.2 149.4 569.6 396.2 165.3 561.5 372.2 183.2 555.4 458.2 136.2 594.4 434.6 150.6 585.2 410.0 166.4 576.4 384.8 184.1 568.9 460/H...
  • Page 117 ESIE07-03 General Outline EWAD600AJYNN & EWAD550-600JYNN Heat Recovery Exchanger Leaving Water Temperature Totale (°C) /H table Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 523.8 158.8 682.6 502.8 174.7 677.5 479.7 192.4 672.1 454.7 211.9 666.6 540.2 160.6 700.8 518.7 176.4 695.1 495.4 194.0 689.4 469.9 213.5 683.4 556.6 162.4 719.0 535.0 178.2 713.2 511.2 195.7 706.9 485.4 215.2 700.6 550/H...
  • Page 118 General Outline ESIE07-03 EWAD260-380AJYN N/A table Heat Recovery Exchanger Leaving Water Temperature Totale (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 231.8 63.9 295.7 224.9 70.9 295.8 217.1 78.6 295.7 208.0 86.7 294.7 238.8 64.5 303.3 232.1...
  • Page 119 ESIE07-03 General Outline EWAD420-650AJYN N/A table Heat Recovery Exchanger Leaving Water Temperature Totale (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 368.3 101.5 469.8 358.2 112.7 470.9 346.0 124.7 470.7 331.4 137.6 469.0 379.7 102.3 482.0 369.1 113.4 482.5 356.9 125.5 482.4 342.4 138.5 480.9 391.3 103.1 494.4 380.5 114.3 494.8 367.9 126.3 494.2 353.4 139.4 492.8 403.0 104.0 507.0 392.3 115.2 507.5 379.3 127.2 506.5 364.7 140.3 505.0...
  • Page 120 General Outline ESIE07-03 EWAD210-320AJYN N/Q table Heat Recovery Exchanger Leaving Water Temperature Totale (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 207.0 60.9 267.9 196.7 67.0 263.7 185.6 73.7 259.3 173.8 80.9 254.7 213.9 61.4 275.3 203.5 67.6 271.1 192.2 74.3...
  • Page 121 ESIE07-03 General Outline EWAD340-500AJYN N/Q table Heat Recovery Exchanger Leaving Water Temperature Totale (°C) Unit size (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) 331.5 97.5 429.0 314.8 107.2 422.0 296.9 117.7 414.6 277.8 129.1 406.9 342.7 98.4 441.1 325.7 108.1 433.8 307.5 118.6 426.1 288.1 130.1 418.2...

  • Page 122: Heat Recovery Ratings: Ewyd-Ajynn

    General Outline ESIE07-03 1.32 Heat Recovery Ratings: EWYD-AJYNN EWYD-AJYNN table Heat recovery leaving water temperature (ΔT= 5°C) Unit 45 (ΔT=5°C) 50 (ΔT=5°C) 55 (ΔT=5°C) size Heating capacity Heating capacity Heating capacity 74.3 67.8 57.9 80.9 76.1 65.4 88.5 85.2 73.5 93.5 88.2 75.7...

  • Page 123: Partial Heat Recovery Ratings: Ewad-Ajynn/S & Ewad-Ajynn/X

    ESIE07-03 General Outline 1.33 Partial Heat Recovery Ratings: EWAD-AJYNN/S & EWAD-AJYNN/X EWAD-AJYNN/S The table below contains the partial heat recovery ratings for EWAD-AJYNN/S, (+OPRN) & EWAD-AJYNN/S+OPRN, EWAD-AJYNN/X, EWAD-AJYNN/X+OPRN and EWAD-AJYNN/X +OPLN EWAD-AJYNN/X Heat recovery leaving water temperature (ΔT= 5°C) (+OPRN) (+OPLN) 45 (ΔT=5°C) 50 (ΔT=5°C) 55 (ΔT=5°C)

  • Page 124: Total Heat Recovery Ratings: Ewad-Ajynn/S & Ewad-Ajynn/X

    General Outline ESIE07-03 1.34 Total Heat Recovery Ratings: EWAD-AJYNN/S & EWAD-AJYNN/X EWAD300-400AJYN The table below contains the total heat recovery ratings for EWAD300-400AJYNN/S (+OPRN) and N/S (+OPRN) & EWAD300-400AJYNN/X (+OPRN) (+OPLN) EWAD300-400AJYN Water Condensor Temperature (°C) N/X (+OPRN) Unit 30/35 35/40 40/45 45/50...
  • Page 125 ESIE07-03 General Outline EWAD420-490AJYN The table below contains the total heat recovery ratings for EWAD420-490AJYNN/S (+OPRN) and N/S (+OPRN) & EWAD420-490AJYNN/X (+OPRN) (+OPLN) EWAD420-490AJYN Water Condensor Temperature (°C) N/X (+OPRN) Unit 30/35 35/40 40/45 45/50 50/55 (+OPLN) size (kW) (kW) (kW) (kW) (kW)
  • Page 126 General Outline ESIE07-03 EWAD520AJYNN/S The table below contains the total heat recovery ratings for EWAD520AJYNN/S (+OPRN) and (+OPRN) & EWAD520AJYNN/X (+OPRN) (+OPLN) EWAD520AJYNN/X Water Condensor Temperature (°C) (+OPRN) (+OPLN) Unit 30/35 35/40 40/45 45/50 50/55 size (kW) (kW) (kW) (kW) (kW) (kW) (kW)

  • Page 127: Sound Level Data - Sound Pressure Correction Factor: Ewad-Ajynn

    ESIE07-03 General Outline 1.35 Sound Level Data - Sound Pressure Correction Factor: EWAD-AJYNN Sound level data EWAD-AJYNN Power Sound pressure level at 1 m from the unit in semispheric free field (rif. 2 x 10 Unit size 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz...
  • Page 128 General Outline ESIE07-03 Power Sound pressure level at 1 m from the unit in semispheric free field (rif. 2 x 10 Unit size 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz dB(A) dB(A) 76.4 69.4...
  • Page 129 ESIE07-03 General Outline Sound level data EWAD-AJYNN/A + OPLN Power Sound pressure level at 1 m from the unit in semispheric free field (rif. 2 x 10 Unit size 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz dB(A)
  • Page 130 General Outline ESIE07-03 Sound pressure correction factor Distance (m)² EWAD_AJYNN & Unit size EWAD-AJYNN + OPRN/OPLN -8.3 -13.3 -16.4 -18.7 -20.5 -8.3 -13.3 -16.4 -18.7 -20.5 -8.0 -12.9 -16.0 -18.2 -20.1 -8.0 -12.9 -16.0 -18.2 -20.1 -8.0 -12.9 -16.0 -18.2 -20.1 -8.0 -12.9...
  • Page 131 ESIE07-03 General Outline Sound pressure correction factor Distance (m)² EWAD-AJYNN/A or Unit size /A + OPLN -8.0 -12.9 -16.0 -18.2 -20.1 -7.7 -12.5 -15.6 -17.8 -19.6 -7.7 -12.5 -15.6 -17.8 -19.6 -7.7 -12.5 -15.6 -17.8 -19.6 -7.7 -12.5 -15.6 -17.8 -19.6 -7.7 -12.5...

  • Page 132: Sound Level Data: Ewyd-Ajynn

    General Outline ESIE07-03 1.36 Sound Level Data: EWYD-AJYNN Sound levels EWYD-AJYNN in cooling and heating Power Sound pressure level at 1 m from the unit in semispheric free field (rif. 2 x 10 Unit size 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz...
  • Page 133 ESIE07-03 General Outline Sound pressure correction factor for Distance (m)² different distances Unit size EWYD-AJYNN & EWYD-AJYNN + -7.9 -12.7 -15.8 -18.1 -19.8 OPLN -7.9 -12.7 -15.8 -18.1 -19.8 -7.9 -12.7 -15.8 -18.1 -19.8 -7.5 -12.2 -15.3 -17.5 -19.3 -7.5 -12.2 -15.3 -17.5...
  • Page 134 General Outline ESIE07-03 1–126 Part 1 – System Outline...

  • Page 135: Piping Layout

    ESIE07-03 Piping Layout Part 1z Piping Layout What Is in This Chapter? Introduction This chapter describes the internal refrigeration circuit. The water piping is considered as common practice and is therefore not explained. Overview This chapter contains the following top Topic See page 2.2–Piping Diagram: EWAD-AJYNN(/Q) with Thermostatic Expansion Valve...

  • Page 136: Piping Diagram: Ewad-Ajynn(/Q) With Thermostatic Expansion Valve

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN(/Q) with Thermostatic Expansion Valve Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar Air-cooled condenser...
  • Page 137 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN(/Q) units with Thermostatic Expansion Valve. Part 1 – System Outline 1–129...

  • Page 138: Piping Diagram: Ewad-Ajynn(/Q) With Electronic Expansion Valve

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN(/Q) with Electronic Expansion Valve Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar Air-cooled condenser...
  • Page 139 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN(/Q) units with Electronic Expansion Valve. Part 1 – System Outline 1–131...

  • Page 140: Piping Diagram: Ewad-Ajynn/A With Thermostatic Expansion Valve

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN/A with Thermostatic Expansion Valve Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar Air-cooled condenser...
  • Page 141 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/A units with Thermostatic Expansion Valve. Part 1 – System Outline 1–133...

  • Page 142: Piping Diagram: Ewad-Ajynn/A With Electronic Expansion Valve

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN/A with Electronic Expansion Valve Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar Air-cooled condenser...
  • Page 143 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/A units with Electronic Expansion Valve. Part 1 – System Outline 1–135...

  • Page 144: Piping Diagram: Ewad-Ajynn(/Q) With Thermostatic Expansion Valve And Partial Heat-Recovery

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN(/Q) with Thermostatic Expansion Valve and Partial Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 145 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/Q units with Partial Heat-Recovery and Thermostatic Expansion Valve. Part 1 – System Outline 1–137...

  • Page 146: Piping Diagram: Ewad-Ajynn(/Q) With Electronic Expansion Valve And Partial Heat-Recovery

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN(/Q) with Electronic Expansion Valve and Partial Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 147 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN(/Q) units with Partial Heat-Recovery and Electronic Expansion Valve. Part 1 – System Outline 1–139...

  • Page 148: Piping Diagram: Ewad-Ajynn/A With Thermostatic Expansion Valve And Partial Heat-Recovery

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN/A with Thermostatic Expansion Valve and Partial Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 149 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/A units with Partial Heat-Recovery and Thermostatic Expansion Valve. Part 1 – System Outline 1–141...

  • Page 150: Piping Diagram: Ewad-Ajynn/A With Electronic Expansion Valve And Partial Heat-Recovery

    Piping Layout ESIE07-03 Piping Diagram: EWAD-AJYNN/A with Electronic Expansion Valve and Partial Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 151 ESIE07-03 Piping Layout Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/A units with Partial Heat-Recovery and Electronic Expansion Valve. Part 1 – System Outline 1–143...

  • Page 152: Description Of The Refrigerant Cycle With Partial Heat-Recovery

    Piping Layout ESIE07-03 2.10 Description of the Refrigerant Cycle with Partial Heat-Recovery The low-temperature refrigerant gas from the evaporator is taken in by the compressor and travels through the electric engine cooling it. It is subsequently compressed and after this phase the refrigerant is mixed with the oil from the separator.

  • Page 153: Piping Diagram: Ewad-Ajynn(/Q) With Thermostatic Expansion Valve And Full Heat-Recovery

    ESIE07-03 Piping Layout 2.12 Piping Diagram: EWAD-AJYNN(/Q) with Thermostatic Expansion Valve and Full Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 154 Piping Layout ESIE07-03 Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN(/Q) units with Full Heat-Recovery and Thermostatic Expansion Valve. 1–146 Part 1 – System Outline...

  • Page 155: Piping Diagram: Ewad-Ajynn(/Q) With Electronic Expansion Valve And Full Heat-Recovery

    ESIE07-03 Piping Layout 2.13 Piping Diagram: EWAD-AJYNN(/Q) with Electronic Expansion Valve and Full Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 156 Piping Layout ESIE07-03 Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN(/Q) units with Full Heat-Recovery and Electronic Expansion Valve. 1–148 Part 1 – System Outline...

  • Page 157: Piping Diagram: Ewad-Ajynn/A With Thermostatic Expansion Valve And Full Heat-Recovery

    ESIE07-03 Piping Layout 2.14 Piping Diagram: EWAD-AJYNN/A with Thermostatic Expansion Valve and Full Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 158 Piping Layout ESIE07-03 Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/A units with Full Heat-Recovery and Thermostatic Expansion Valve. 22 23 1–150 Part 1 – System Outline...

  • Page 159: Piping Diagram: Ewad-Ajynn/A With Electronic Expansion Valve And Full Heat-Recovery

    ESIE07-03 Piping Layout 2.15 Piping Diagram: EWAD-AJYNN/A with Electronic Expansion Valve and Full Heat-Recovery Components N° Components Function/Remark Compressor Single screw compressor Discharge non-return valve To avoid that liquid from condenser returns into compressor when unit does not work Discharge stop valve Closed position when unit is delivered at site High pressure relief valve Setting 24.5 bar...
  • Page 160 Piping Layout ESIE07-03 Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWAD-AJYNN/A units with Full Heat-Recovery and Electronic Expansion Valve. 21 22 1–152 Part 1 – System Outline...

  • Page 161: Description Of The Refrigerant Cycle With Full Heat-Recovery

    ESIE07-03 Piping Layout 2.16 Description of the Refrigerant Cycle with Full Heat-Recovery Low-temperature refrigerant gas from the evaporator is taken in by the compressor and travels through the electric engine, cooling it. It is subsequently compressed and during this phase the refrigerant mixes with oil from the separator.

  • Page 162: Controlling The Full Heat Recovery Circuit And Installation Recommendations

    Piping Layout ESIE07-03 2.17 Controlling the Full Heat Recovery Circuit and Installation Recommendations Units with total heat recovery differ from the basic version in the following additional components for each circuit: ■ Gas/Water shell and tube heat exchanger complete with safety valve and 10 mm thermal insulation (20 mm on request).

  • Page 163: Piping Diagram: Ewyd-Ajynn

    ESIE07-03 Piping Layout 2.18 Piping Diagram: EWYD-AJYNN Components N° Components Check valve 1/4“ SAE connection Safety valve Expansion valve High-pressure switch Low-pressure valve Suction valve (optional) Delivery valve Direction of fluid for cooling Direction of fluid for heating Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWYD-AJYNN.

  • Page 164: Piping Diagram: Ewyd-Ajynn With Partial Heat-Recovery

    Piping Layout ESIE07-03 2.19 Piping Diagram: EWYD-AJYNN with Partial Heat-Recovery Components N° Components Check valve 1/4“ SAE connection Safety valve Expansion valve High-pressure switch Low-pressure valve Suction valve (optional) Delivery valve Direction of fluid for cooling Direction of fluid for heating Functional diagram The illustration below shows the functional diagram of the refrigerant cycle for EWYD-AJYNN with Partial Heat-Recovery.

  • Page 165: Wiring Layout

    ESIE 07-03 Wiring Layout Part 1 Wiring Layout What Is in This Chapter? Introduction This part gives a general overview of the wiring layout. Detailed wiring diagrams can be found on http://passdoor.mcquay.it. There you can find a wiring diagram for every serial number. Overview This chapter contains the following topics: Topic...

  • Page 166: Specific Wiring Diagrams For Every Serial Number

    Wiring Layout ESIE 07-03 Specific Wiring Diagrams for every Serial Number Note Due to the fact that not one unit is the same, it is not possible to provide wiring diagrams for all units in this Service Manual. However, for every serial number, there is a wiring diagram available on http://passdoor.mcquay.it 1–158 Part 1 –...

  • Page 167: Wiring Diagram - Ewad-Ajynn With Electronic Expansion Valve

    ESIE 07-03 Wiring Layout Wiring Diagram - EWAD-AJYNN with Electronic Expansion Valve Overview This chapter contains the following topics: Topic See page 3.3.1–Compressor 1-2 Power Supply 1–160 3.3.2–Circuits 1 Fan Power Supply 1–161 3.3.3–Circuits 2 Fan Power Supply 1–162 3.3.4–Kit Pumps 1–163 3.3.5–Unit Control Circuit Power Supply 1–164...
  • Page 168 Wiring Layout ESIE 07-03 3.3.1 Compressor 1-2 Power Supply M2 M1 1–160 Part 1 – System Outline...
  • Page 169 ESIE 07-03 Wiring Layout 3.3.2 Circuits 1 Fan Power Supply For more details on kit speedtrol, see page 1–173. Part 1 – System Outline 1–161...
  • Page 170 Wiring Layout ESIE 07-03 3.3.3 Circuits 2 Fan Power Supply For more details on kit speedtrol, see page 1–173. 1–162 Part 1 – System Outline...
  • Page 171 ESIE 07-03 Wiring Layout 3.3.4 Kit Pumps Part 1 – System Outline 1–163...
  • Page 172 Wiring Layout ESIE 07-03 3.3.5 Unit Control Circuit Power Supply 1–164 Part 1 – System Outline...
  • Page 173 ESIE 07-03 Wiring Layout 3.3.6 Electronic Expansion Valve Board 1/2 Part 1 – System Outline 1–165...
  • Page 174 Wiring Layout ESIE 07-03 3.3.7 Analog-Digital Inputs Board 1/2 1–166 Part 1 – System Outline...
  • Page 175 ESIE 07-03 Wiring Layout 3.3.8 Compressor 1 Control Part 1 – System Outline 1–167...
  • Page 176 Wiring Layout ESIE 07-03 3.3.9 Fan Control Circuits 1 1–168 Part 1 – System Outline...
  • Page 177 ESIE 07-03 Wiring Layout 3.3.10 Compressor 2 Control Circuit Part 1 – System Outline 1–169...
  • Page 178 Wiring Layout ESIE 07-03 3.3.11 Fan Control Circuits 2 1–170 Part 1 – System Outline...

  • Page 179: Pump Control

    ESIE 07-03 Wiring Layout 3.3.12 Pump Control Part 1 – System Outline 1–171...
  • Page 180 Wiring Layout ESIE 07-03 3.3.13 Economizer Expansion Board Kit 1–172 Part 1 – System Outline...
  • Page 181 ESIE 07-03 Wiring Layout 3.3.14 Heat Recovery Expansion Board Kit Part 1 – System Outline 1–173...
  • Page 182 Wiring Layout ESIE 07-03 3.3.15 Pump Control Expansion Board 1–174 Part 1 – System Outline...
  • Page 183 ESIE 07-03 Wiring Layout 3.3.16 Fan Step Control Board Part 1 – System Outline 1–175...
  • Page 184 Wiring Layout ESIE 07-03 3.3.17 Terminals M1-M2-M3 TERMINAL Compressor 1 – – – – – TERMINAL Compressor 2 – 2.16 2.11 – – 2.16 – 2.12 2.12 – MORSETTIERA QUADRO GENERALE Customer Services – – 17.4 – – 17.5 – –...
  • Page 185 ESIE 07-03 Wiring Layout 3.3.18 Terminals MQ MORSETTIERA QUADRO GENERALE Compressor 1 – – 7.15 – – 9.18 – – 11.13 – – 6.17 – – 9.13 – – 9.11 – – 9.10 – – 11.10 – – 11.11 – –...
  • Page 186 Wiring Layout ESIE 07-03 3.3.19 Legend Item Description Analog digital inputs board EXVB.1-2 Electronic expansion valve board EXV.1-2 Electronic expansion valve EXVb.1-2 Electronic expansion battery valve F1-2 Compressor fuses F13-23 High pressure switch F51-52 Compressor thermal relays Evaporator heater fuse F60/62 Protection auxiliary circuit fuse F100/200...

  • Page 187: Wiring Diagram - Ewad-Ajynn With Thermostatic Expansion Valve

    ESIE 07-03 Wiring Layout Wiring Diagram - EWAD-AJYNN with Thermostatic Expansion Valve Overview This chapter contains the following topics: Topic See page 3.4.1–Compressor 1-2 Power Supply 1–180 3.4.2–Circuits 1 Fan Power Supply 1–181 3.4.3–Circuits 2 Fan Power Supply 1–182 3.4.4–Kit Pumps 1–183 3.4.5–Unit Control Circuit Power Supply 1–184...
  • Page 188 Wiring Layout ESIE 07-03 3.4.1 Compressor 1-2 Power Supply M2 M1 1–180 Part 1 – System Outline...
  • Page 189 ESIE 07-03 Wiring Layout 3.4.2 Circuits 1 Fan Power Supply For more details on kit speedtrol, see page 1–193. Part 1 – System Outline 1–181...
  • Page 190 Wiring Layout ESIE 07-03 3.4.3 Circuits 2 Fan Power Supply For more details on kit speedtrol, see page 1–193. 1–182 Part 1 – System Outline...
  • Page 191 ESIE 07-03 Wiring Layout 3.4.4 Kit Pumps Part 1 – System Outline 1–183...
  • Page 192 Wiring Layout ESIE 07-03 3.4.5 Unit Control Circuit Power Supply 1–184 Part 1 – System Outline...
  • Page 193 ESIE 07-03 Wiring Layout 3.4.6 Analog-Digital Inputs Board 1/2 Part 1 – System Outline 1–185...
  • Page 194 Wiring Layout ESIE 07-03 3.4.7 Compressor 1 Control 1–186 Part 1 – System Outline...
  • Page 195 ESIE 07-03 Wiring Layout 3.4.8 Fan Control Circuits 1 Part 1 – System Outline 1–187...
  • Page 196 Wiring Layout ESIE 07-03 3.4.9 Compressor 2 Control Circuit 1–188 Part 1 – System Outline...
  • Page 197 ESIE 07-03 Wiring Layout 3.4.10 Fan Control Circuits 2 Part 1 – System Outline 1–189...
  • Page 198 Wiring Layout ESIE 07-03 3.4.11 Pump Control 1–190 Part 1 – System Outline...
  • Page 199 ESIE 07-03 Wiring Layout 3.4.12 Economizer Expansion Board Kit Part 1 – System Outline 1–191...
  • Page 200 Wiring Layout ESIE 07-03 3.4.13 Heat Recovery Expansion Board Kit 1–192 Part 1 – System Outline...
  • Page 201 ESIE 07-03 Wiring Layout 3.4.14 Pump Control Expansion Board Part 1 – System Outline 1–193...
  • Page 202 Wiring Layout ESIE 07-03 3.4.15 Fan Step Control Board 1–194 Part 1 – System Outline...
  • Page 203 ESIE 07-03 Wiring Layout 3.4.16 Terminals M1-M2-M3 TERMINAL Compressor 1 – – – – – TERMINAL Compressor 2 2.16 – – 2.11 – 2.16 – 2.12 – 2.12 MORSETTIERA QUADRO GENERALE Customer Services – – – – 11.6 – – 11.6 –...
  • Page 204 Wiring Layout ESIE 07-03 3.4.17 Terminals MQ MORSETTIERA QUADRO GENERALE Compressor 1 10.13 – – 6.17 – – 8.18 – – 6.18 – – 14.15 – – 6.17 – – 13.17 – – 13.18 – – 14.14 – – 8.11 –...
  • Page 205 ESIE 07-03 Wiring Layout 3.4.18 Legend Item Description Analog digital inputs board F1-2 Compressor fuses F13-23 High pressure switch F51-52 Compressor thermal relays Evaporator heater fuse F60/62 Protection auxiliary circuit fuse F100/200 Fan fuse F112 Phase volt monitor F116 Evaporator flow switch (not installed) F120 Transformer T1 protection F130...

  • Page 206: Wiring Diagram - Ewyd-Ajynn

    Wiring Layout ESIE 07-03 Wiring Diagram - EWYD-AJYNN Overview This chapter contains the following topics: Topic See page 3.5.1–Circuits Fan Power Supply 1 1–199 3.5.2–Circuits Fan Power Supply 2 1–200 3.5.3–Kit Pumps 1–201 3.5.4–Unit Control Circuit Power Supply 1–202 3.5.5–Power Compressor 1-2 1–203 3.5.6–Electronic Expansion Valve Board Circuit 1 1–204...
  • Page 207 ESIE 07-03 Wiring Layout 3.5.1 Circuits Fan Power Supply 1 Part 1 – System Outline 1–199...
  • Page 208 Wiring Layout ESIE 07-03 3.5.2 Circuits Fan Power Supply 2 1–200 Part 1 – System Outline...
  • Page 209 ESIE 07-03 Wiring Layout 3.5.3 Kit Pumps Part 1 – System Outline 1–201...
  • Page 210 Wiring Layout ESIE 07-03 3.5.4 Unit Control Circuit Power Supply 1–202 Part 1 – System Outline...
  • Page 211 ESIE 07-03 Wiring Layout 3.5.5 Power Compressor 1-2 Part 1 – System Outline 1–203...
  • Page 212 Wiring Layout ESIE 07-03 3.5.6 Electronic Expansion Valve Board Circuit 1 1–204 Part 1 – System Outline...
  • Page 213 ESIE 07-03 Wiring Layout 3.5.7 Analog - Digital Inputs Board 1 Part 1 – System Outline 1–205...
  • Page 214 Wiring Layout ESIE 07-03 3.5.8 Control Circuit Compressor 1 1–206 Part 1 – System Outline...
  • Page 215 ESIE 07-03 Wiring Layout 3.5.9 Control Circuits Fan 1 Part 1 – System Outline 1–207...
  • Page 216 Wiring Layout ESIE 07-03 3.5.10 Control Circuit Compressor 2 1–208 Part 1 – System Outline...
  • Page 217 ESIE 07-03 Wiring Layout 3.5.11 Control Circuits Fan 2 Part 1 – System Outline 1–209...
  • Page 218 Wiring Layout ESIE 07-03 3.5.12 Heat Pump Control Expansion Board 2 1–210 Part 1 – System Outline...

  • Page 219: Pumps Control

    ESIE 07-03 Wiring Layout 3.5.13 Pumps Control Part 1 – System Outline 1–211...
  • Page 220 Wiring Layout ESIE 07-03 3.5.14 Water Pump Control Expansion Board 3 1–212 Part 1 – System Outline...
  • Page 221 ESIE 07-03 Wiring Layout 3.5.15 Fan Step Control Expansion Board 4 Part 1 – System Outline 1–213...
  • Page 222 Wiring Layout ESIE 07-03 3.5.16 Terminals M1-M2-M3 TERMINAL – – – – TERMINAL – – – – TERMINAL – – 8. 7 – – 8. 11 – – 8. 12 – – 16 . 4 – – 16 . 3 325B –...
  • Page 223 ESIE 07-03 Wiring Layout 3.5.17 Terminals MQ TERMINAL – – 5. 16 – – 9. 18 – – 11. 18 – – 5. 16 – – 5. 18 – – 9. 10 – – 9. 11 – – 9. 12 –...
  • Page 224 Wiring Layout ESIE 07-03 3.5.18 Legend Item Description Analog digital inputs board EV bat.1 - EV bat.2 Electronic expansion battery valve EXB2 Heat recovery control expansion board 2 EXB3 Water pump control expansion board 3 EXB4 Fan step control expansion board 4 EXV.1 - EXV.2 Electronic expansion valve EXVB.1 - EXVB.2...
  • Page 225 ESIE 07-03 Wiring Layout Item Description Fan 2/4 P1-2 Pump ON-OFF unit switch Q1-2 ON-OFF compressor switch ON-OFF switch Main switch Automatic circuit breaker Magnetothermal fuse 1/1 Magnetothermal fuse 1/2 Magnetothermal fuse 1/3 Magnetothermal fuse 1/4 Magnetothermal fuse 2/1 Magnetothermal fuse 2/2 Magnetothermal fuse 2/3 Magnetothermal fuse 2/4 R1-2...
  • Page 226 Wiring Layout ESIE 07-03 3.5.19 Note Standard compressor FUSES + OVERCURRENT 3118 3120 3121 3122 160 A 160 A 200 A 200 A 160 A 160 A 200 A 200 A Standard pumps FUSES + OVERCURRENT 2,2 kW 3 kW 4 kW 5,5 kW 20 A...
  • Page 227 ESIE 07-03 Wiring Layout List of options Option Description OPSP single pump OPTP Twin pump or dual pump OPTR Total recovery SPN15a Variable Phase monitor SPN19 Current limit SPN75 Reset set point - Demand limit SPN76 OAT Sensor SPN79 External Fault Alarm Part 1 –...

  • Page 228: Field Wiring Connection

    Wiring Layout ESIE 07-03 3.5.20 Field Wiring Connection Digital input terminals Digital input terminals F116 OBLIGATORY Double setpoint ON – OFF Flow switch (remove wire "322") Remote (remove wire "MJ") Digital output terminals Digital output terminals Pump contact Alarm NO (default) Maximum load: Maximum load: 2A –...

  • Page 229: System Architecture

    ESIE07-03 System Architecture Part 1 System Architecture What Is in This Chapter? Introduction This part gives a general overview of the system architecture. Overview This chapter contains the following topics: Topic See page 4.2–General Description 1–222 4.3–Hardware Configuration 1–222 4.4–Control Panel 1–223 4.5–Layout pCO²...

  • Page 230: General Description

    System Architecture ESIE07-03 General Description The configuration modular architecture is based on the use of the pCO2 control. In particular, a base MicroTech II C+ controller (large version, built-in display, or, optionally, semi graphical additional display) is used to control the basic unit functions and to manage the two compressors.

  • Page 231: Control Panel

    ESIE07-03 System Architecture Control Panel The Control Panel is constituted by a backlight display 4 lines by 20 characters with a 6 key keypad whose functions will be illustrated in the following. This display can be built-in as a part of the master MicroTech II C+ controller (standard option), or it can be optionally a separate device based on the MicroTech II PGD serigraphic technology.

  • Page 232: Layout Pco² Controller

    System Architecture ESIE07-03 Layout pCO² Controller pCO² controller Power supply G (+), G0 (-) Status LED Fuse 250Vac Universal analog inputs (NTC, 0/1V, 0/10V,0/20mA, 4/20mA) Passive analog inputs (NTC, PT1000, On- off) Analog outputs 0/10V 24Vac/Vdc Digital inputs 230Vac or 24Vac/Vdc Digital inputs Synoptic terminal connection Standard terminal (and program download) connector Digital outputs (relays)
  • Page 233 ESIE07-03 System Architecture Address microswitches R G V Part 1 – System Outline 1–225...

  • Page 234: Layout Pco² Expansion Driver

    System Architecture ESIE07-03 Layout pCO² Expansion Driver pCO² driver The introduction of additional (optional) functionality in MTM architecture requires the use of expansion boards. Power supply connector (G(+), G0 (-)) Analogue output 0 to 10 V Network connector for expansions in RS485 (GND, T+, T-) or tLAN (GND, T+) 24 Vac/Vdc digital inputs Yellow LED showing power supply voltage and 3 signalling LEDs Serial address...
  • Page 235 ESIE07-03 System Architecture Detail switches Example address 1 Address switches Meaning LED on driver YELLOW GREEN Meaning Active CAREL/tLAN supervisor protocol Probe error "I/O mismatch" error caused by the inhibition matrix flashing Lack of communication Waiting for the system startup by the master (max.

  • Page 236: Layout Eev Driver

    System Architecture ESIE07-03 Layout EEV Driver General description The valve drivers contain the software for the control of the electronic expansion valve and are connected to the battery group that provides to close valve in case of power failure. Addressing Microswitches Normal conditions Under normal conditions five(5) LED indicates:...

  • Page 237: Addressing Of The Different Parts

    ESIE07-03 System Architecture Addressing of the Different Parts Setting addresses pLAN component Microswitch pCO1 Driver 1 Driver 2 Driver 3 Driver 4 Additional display RS485 component Microswitch Expansion board 1 Expansion board 2 Expansion board 3 Expansion board 4 Part 1 – System Outline 1–229...

  • Page 238: Identification Of Software

    System Architecture ESIE07-03 Identification of Software Introduction Unique control software is installed on Pco² controller, the unit controller is directly recognized on the basis of the pLAN address. No software is installed on the expansion boards and on EEXV drivers (factory-installed software is used).
  • Page 239 ESIE07-03 System Architecture Version To identify unambiguously the software class and version (also with respect to other control software) identification a string made of four fields is used: An identification three-digit literal field (C ) to identify the class of units for which the software is usable Type of chiller Air-cooled chiller...

  • Page 240: Description Connectors

    System Architecture ESIE07-03 4.10 Description Connectors Overview This chapter contains the following topics: Topic See page 4.10.1–Standard Version with Electronic Expansion Valve 1–232 4.10.2–Standard Version with Thermostatic Expansion Valve 1–240 4.10.1 Standard Version with Electronic Expansion Valve Connector Pco² The table below describes the connectors for the CP1 control board. controller Wiring diagram Block...
  • Page 241 ESIE07-03 System Architecture Wiring diagram Block Connection Description symbol ID10 ID11 ID12 Compressor contactor circuit circuit 1 IDC9 24 V power supply ID13 Compressor contactor circuit circuit 2 IDC13 ID14 Compressor terminal/thermal?? relay circuit 1 Not used Not used Terminal connector for display and download of software RX/TX- pLAN communication...
  • Page 242 System Architecture ESIE07-03 Wiring diagram Block Connection Description symbol Evaporator inlet water sensor Evaporator outlet water sensor BC10 ID17 Not used Remote start/stop ID18 IDC17 NO14 Liquid injection solenoid valve circuit 2 NC14 Not used NO15 Not used Not used NC15 Not used NO16...
  • Page 243 ESIE07-03 System Architecture Connector The table below describes the connectors for the Economizer kit and additional hardware expansion expansion board 1 board n°1 (serial address 1). Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Low pressure switch circuit 2 (only when low pressure...
  • Page 244 System Architecture ESIE07-03 Connector The table below describes the connectors for the Heat recovery control expansion board n°2. expansion board 2 Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Not used Not used...
  • Page 245 ESIE07-03 System Architecture Connector The table below describes the connectors for the Waterpump control expansion board n°3 (serial expansion board 3 address 3). Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Not used Not used...
  • Page 246 System Architecture ESIE07-03 Connector The table below describes the connectors for the Fan step control expansion board n°4 (serial address expansion board 4 Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Not used Not used...
  • Page 247 ESIE07-03 System Architecture Electronic The table below describes the connectors for the EEV driver. expansion valve driver Expansion valve CIRC. 1 EV bat. 1 Bat. 1 pLAN communication to PCO2 Part 1 – System Outline 1–239...
  • Page 248 System Architecture ESIE07-03 4.10.2 Standard Version with Thermostatic Expansion Valve Connector Pco² The table below describes the connectors for the CP1 control board. controller Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Oil pressure transmitter circuit 1 Oil pressure transmitter circuit 2 Low pressure transmitter circuit 1 +VDC...
  • Page 249 ESIE07-03 System Architecture Wiring diagram Block Connection Description symbol RX/TX- pLAN communication RX/TX+ Line contactor relay circuit 1 Loading left solenoid valve circuit 1 Unloading right solenoid valve circuit 1 Power supply 220 V Power supply 220 V Liquid injection solenoid valve circuit 1 Liquid line solenoid valve circuit 1 KM11 Fan step 1 circuit 1...
  • Page 250 System Architecture ESIE07-03 Wiring diagram Block Connection Description symbol Connection to expansion boards 1–242 Part 1 – System Outline...
  • Page 251 ESIE07-03 System Architecture Connector The table below describes the connectors for the Economizer kit and additional hardware expansion expansion board 1 board n°1 (serial address 1). Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Low pressure switch circuit 2 (only when low pressure...
  • Page 252 System Architecture ESIE07-03 Connector The table below describes the connectors for the Heat recovery control expansion board n°2. expansion board 2 Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Not used Not used...
  • Page 253 ESIE07-03 System Architecture Connector The table below describes the connectors for the Waterpump control expansion board n°3 (serial expansion board 3 address 3). Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Not used Not used...
  • Page 254 System Architecture ESIE07-03 Connector The table below describes the connectors for the Fan step control expansion board n°4 (serial address expansion board 4 Wiring diagram Block Connection Description symbol 24 V power supply microprocessor board Not used Connection to CP1 control board (J23) IDC1 Not used Not used...
  • Page 255 ESIE07-03 System Architecture Electronic The table below describes the connectors for the EEV driver. expansion valve driver Expansion valve CIRC. 1 EV bat. 1 Bat. 1 pLAN communication to PCO2 Part 1 – System Outline 1–247...

  • Page 256: Field Wiring For The Interface M3 Terminal Boards

    System Architecture ESIE07-03 4.11 Field Wiring for the Interface M3 Terminal Boards Unit basic connections Additional Additional expansion Additional expansion for Unit expansion for pump control limitation for Heat Recovery 1–248 Part 1 – System Outline...

  • Page 257: Functional Description

    ESIE07-03 Part 2 Functional Description Introduction This part gives more detailed information on the functions and controls of the unit. This information is used as background information for troubleshooting. An extensive overview of the functioning of the controller is also given in this part. Knowledge of the controller is essential to gather information prior to servicing and troubleshooting.
  • Page 258 ESIE07-03 2–2 Part 2 – Functional Description...

  • Page 259: Operation Range

    ESIE07-03 Operation Range Part 2 Operation Range What Is in This Chapter? Introduction This chapter contains information on the functions used to control the system. Understanding these functions is vital when diagnosing a malfunction that is related to the functional control. Overview This chapter contains the following topics: Topic...

  • Page 260: Operational Range: Ewad-Ajynn+Opln

    Operation Range ESIE07-03 Operational Range: EWAD-AJYNN Operational range The illustration below shows the operational range of EWAD-AJYNN. Check on rating tables for part load operation of each unit OPFS required OPLA required Leaving water temperature (˚C) Operational Range: EWAD-AJYNN+OPLN Operational range The illustration below shows the operational range of EWAD-AJYNN+OPLN.

  • Page 261: Operational Range: Ewad-Ajynn/A

    ESIE07-03 Operation Range Operational Range: EWAD-AJYNN/Q Operational range The illustration below shows the operational range of EWAD-AJYNN/Q. Check on rating tables for part load operation of each unit OPFS required OPLA required Leaving water temperature (˚C) Operational Range: EWAD-AJYNN/A Operational range The illustration below shows the operational range of EWAD-AJYNN/A.

  • Page 262: Operational Range: Ewad-Ajynn/A+Opln

    Operation Range ESIE07-03 Operational Range: EWAD-AJYNN/A+OPLN Operational range The illustration below shows the operational range of EWAD-AJYNN/A+OPLN. Check on rating tables for part load operation of each unit OPFS required OPLA required Leaving water temperature (˚C) Operational Range: EWAD-AJYNN/H Operational range The illustration below shows the operational range of EEWAD-AJYNN/H.

  • Page 263: Operational Range Ewad-Ajynn/S And Ewad-Ajynn/X

    ESIE07-03 Operation Range Operational Range EWAD-AJYNN/S and EWAD-AJYNN/X Operational range The illustration below shows the operational range of EWAD-AJYNN/S and EWAD-AJYNN/X. OPERATION WITH GLYCOL FAN SPEED REGULATION ONLY -10 -9 Evaporator Leaving Water Temperature (°C) Operational Range EWYD-AJYNN Operational cooling The illustration below shows the operational cooling range of EWYD-AJYNN.
  • Page 264 Operation Range ESIE07-03 Operational heating The illustration below shows the operational heating range of EWYD-AJYNN. range Leaving water temperature (°C) 2–8 Part 2 – Functional Description...
  • Page 265 ESIE07-03 The Digital Controller Menus Part 2 The Digital Controller Menus What Is in This Chapter? Introduction This chapter gives more detailed information about the controller and the software. Understanding these functions is vital when diagnosing a malfunction, which is related to system architecture or software.
  • Page 266 The Digital Controller Menus ESIE07-03 Main Menu Introduction The digital controller consist of a display panel with 4 lines and a keypad at the right-hand side of the display (see example below). < ALARM < VIEW < SETTINGS < MAINT Display panel The following screen shows the main menu of the controller.
  • Page 267 ESIE07-03 The Digital Controller Menus Use the Enter and Exit arrow key to: Press ... To ... Enter arrow key Edit the current screen. Exit arrow key Exit the current menu and to go back to the previous. Part 2 – Functional Description 2–11...

  • Page 268: Alarm Menu

    The Digital Controller Menus ESIE07-03 Alarm Menu Main screen of the In the Main menu of the controller, press the Left arrow key to access the Alarm menu. Alarm menu As a result the following screen appears. < A C T <...

  • Page 269: Active Menu

    ESIE07-03 The Digital Controller Menus 2.3.1 Active menu Accessing In the Alarm menu, press the Left arrow key to access the Active menu. The Active menu indicates Alarm menu > the current fault. Active When there is no alarm active, the following screen appears. a l a r m d e t e c t e d If there is an alarm active, the Left arrow key lights up red (function as an alarm button) and the current...
  • Page 270 The Digital Controller Menus ESIE07-03 2.3.2 LOG menu Accessing In the Alarm menu, press the Right arrow key to access the LOG menu. The LOG menu allows you Alarm menu > LOG to see the last 10 alarms that occurred. To browse through the last 10 alarms use the Up/Down arrow keys.
  • Page 271 ESIE07-03 The Digital Controller Menus C o m p r e s n d . T e m p 0 4 2 . 2 c . T e m p 0 6 2 . 3 C o m p r e s s o r E X V S t e p s 0 0 0 0...

  • Page 272: View Menu

    The Digital Controller Menus ESIE07-03 View Menu Main screen of the In the Main menu of the controller, press the Right arrow key to access the View menu. View menu As a result the following screen appears. < < C O M P R E S S O R <...
  • Page 273 ESIE07-03 The Digital Controller Menus 2.4.1 Unit menu Accessing In the View menu, press the Left arrow key to access the Unit menu. View menu > Unit < A T U S < W A T E R < E V A P Status menu In the Unit menu, press the Left arrow key to access the Status menu.
  • Page 274 The Digital Controller Menus ESIE07-03 Unit Status The compressor can start, but is still off. This can be because there is no load, the compressor is still in oil heating, the recycle timers are still running. The compressor is running. The compressor is not available, because it's switched off by the Q1 or Q2 switch or by the software.
  • Page 275 ESIE07-03 The Digital Controller Menus Setpoint Source ■ Softload ■ Stp source: Local ■ Stp source: Double ■ Stp source: 4-20mA (setpoint override) ■ Stp source: OAT reset ambient temperature ■ Stp source: ret reset (evaporator delta T) ■ Stp source: Ice (ice mode) ■...
  • Page 276 The Digital Controller Menus ESIE07-03 4 Press the Down arrow key. The modem status is shown. M o d e m S C O N N E C T E D A fixed or GSM modem can be used to monitor up to 32 chillers from a distance. For both the fixed modem (EKMODEM) and GSM modem (EKGSMOD), an RS485 serial address card (EKAC200J) and an RS485 to RS232 converter (EKCON) should be used.
  • Page 277 ESIE07-03 The Digital Controller Menus 6 Press the Down arrow key. The compressor state can be set to AUTO, MANUAL or OFF. In MANUAL mode, the capacity of the compressor can be changed. Note: Manager password is required (02001). C o m p r e s s o r A U T O c o m p .
  • Page 278 The Digital Controller Menus ESIE07-03 Water menu In the Unit menu, press the Right arrow key to access the Water menu. As a result the following screen appears. W a t e r T e m p e r a t u E v a p 0 1 6 .

  • Page 279: Compressor Menu

    ESIE07-03 The Digital Controller Menus 2.4.2 Compressor menu Accessing In the View menu, press the Right arrow key to access the Compressor menu. View menu > Compressor C o m p t u s : O f R e a d y C o m p t u s : R e a d y Compressor status...
  • Page 280 The Digital Controller Menus ESIE07-03 Scrolling through To scroll through the Compressor menu, use the Up/Down arrow keys. Below the successive screens the Compressor that appears when using the Down arrow key. menu 1 Press the Down arrow key. The following screen appears. n v e r e q u e n c y 6 0 H z...
  • Page 281 ESIE07-03 The Digital Controller Menus ■ Valve position The position of the electronic expansion valve (only visible on units with an electronic expansion valve). 4 Press the Down arrow key. The following screen appears. O i l P r e s s 0 1 0 .
  • Page 282 The Digital Controller Menus ESIE07-03 8 Press the Down arrow key. The following screen appears. E X V v e r S t a t e e s i s 0 0 0 . 0 V o l t a g e 0 0 .
  • Page 283 ESIE07-03 The Digital Controller Menus 2.4.3 I/O menu Accessing In the View menu, press the Up arrow key to access the I/O menu. View menu > I/O In the I/O menu, all the analog and digital inputs and outputs of the main controller (pCO2) and of the expansion boards are visible.
  • Page 284 The Digital Controller Menus ESIE07-03 Digital outputs The 18 digital outputs of the pCO2 controller (C = closed, O= open) ■ DO 1 Start compressor 1. ■ DO 2 Load compressor 1. ■ DO 3 Unload compressor 1. ■ DO 4 Liquid injection compressor 1.
  • Page 285 ESIE07-03 The Digital Controller Menus Scrolling through To scroll through the I/O menu, use the Up/Down arrow keys. Below the successive screens that the I/O menu appears when using the Down arrow key. 1 Press the Down arrow key. The following screen appears. A n a n p u t s : P r 1...
  • Page 286 The Digital Controller Menus ESIE07-03 ■ Low pressure 2 The low (evaporator) pressure of circuit 2. The sensor is 4-20mA. On units with an electronic expansion valve, the low pressure is measured via the driver of the electronic expansion valve. 4 Press the Down arrow key.
  • Page 287 ESIE07-03 The Digital Controller Menus Accessing the I/O As mentioned before, the first screen of the I/O menu shows the digital inputs and outputs of the main menu of the controller (pCO2) (see "Accessing View menu > I/O" on page 2–27). expansion boards C C C C C C C C C O O O O O O O O O O O O O O O O O O C C C C C C C C C...
  • Page 288 The Digital Controller Menus ESIE07-03 D O 4 : E c o n o m i z e r ■ DO4: Economizer2 This digital output controls the economizer on circuit 2. Expansion Board B: Heat Recovery or Inverter Expansion Board B can be configured to control Full Heat Recovery or compressor Inverters (EWAD-AJYNN/S, EWAD-AJYNN/X or EWYD-AJYNN).
  • Page 289 DI2: Overboost Allows the inverters to boost the compressors up to 90Hz in any condition. Note: It is not allowed to enable this digital input. Contact Daikin Europe FQS for more information. e x p D I 3 : M a x...
  • Page 290 The Digital Controller Menus ESIE07-03 ■ DI4: Max VFD 2 Limitation signal from the VFD (Variable Frequency Driver = Inverter) of circuit 2. This indicates that the inverter is absorbing too much current. The controller will then decrease the compres- sor capacity to lower the absorbed current.
  • Page 291 ESIE07-03 The Digital Controller Menus ■ DO1: Water pump 2 Digital output that controls the 2nd pump (1st pump is controlled by digital output 12 of the main pCO2 controller). ■ DO3: Heat recovery Controls the primary heat recovery pump. pump 1 D O 4 : 2 P u m p...
  • Page 292 The Digital Controller Menus ESIE07-03 E x p D O 1 : 4 F a n t e p D O 2 : 5 F a n t e p D O 3 : 4 F a n t e p ■...

  • Page 293: Settings Menu

    ESIE07-03 The Digital Controller Menus Settings Menu Main screen of the In the Main menu of the controller, press the Up arrow key to access the Settings menu. Settings menu As a result the following screen appears. < < C O M P R E S S O R <...
  • Page 294 The Digital Controller Menus ESIE07-03 2.5.1 Unit menu Accessing In the Settings menu, press the Left arrow key to access the Unit menu. Settings menu > Unit < C O N F G U R A T < S E T P O <...
  • Page 295 ESIE07-03 The Digital Controller Menus Changing the factory unit configuration settings To change the factory unit configuration settings, scroll through the Configuration menu using the Up/Down arrow keys. Below the successive screens that appears when using the Down arrow key. 1 Press the Down arrow key.
  • Page 296 The Digital Controller Menus ESIE07-03 5 Press the Down arrow key. The range of the inverter absorbed current is shown. The current is measured by the inverter. The pCO2 controller receives a 0-5 V DC from the inverter. ■ 0 V = minimum absorbed current ■...
  • Page 297 ESIE07-03 The Digital Controller Menus 8 Press the Down arrow key. The unit will restart automatically after a switch between cooling and heating (only for EWYD-AJ) units. You are able to fill out the number of seconds. In the example below, this will take 300 sec. t o r e s t a r t A f t e r...
  • Page 298 The Digital Controller Menus ESIE07-03 12 Press the Down arrow key. The following screen appears. 2 n d P u m p e n a b l i n g e s e Select Present if the unit is equipped with two full heat recovery pumps. 13 Press the Down arrow key.
  • Page 299 ESIE07-03 The Digital Controller Menus 17 Press the Down arrow key The following screen allows you to change the technical password. Note: It is recommended to leave the technical password a s standard. P a s s w o r d T e c h n i c i a n Setpoint menu In the Unit menu, press the Right arrow key to access the Setpoint menu.
  • Page 300 The Digital Controller Menus ESIE07-03 4 Press the Down arrow key. P u m p d o w n c o n 1 2 0 s 0 b a r g When pumpdown (= to put all refrigerant in the condenser when powered off) is enabled, it can take up to 120 sec, except if the evaporator pressure gets below 1,0 bar.
  • Page 301 ESIE07-03 The Digital Controller Menus 9 Press the Down arrow key. D e f r o s a m e t e r S t a r t u p 0 1 8 0 s D e f r 1 8 0 0 s D e f r P a r a m .
  • Page 302 The Digital Controller Menus ESIE07-03 14 Press the Down arrow key. H e a R e c P a r a m D e a d b a n d a g e C o n d 0 3 0 The heat recovery will operate in a 2,0 °C deadband around the setpoint.
  • Page 303 ESIE07-03 The Digital Controller Menus Condensation In the Condensation menu, press the Left arrow key to access the Condensation submenu. As a result the following screeen appears. C o n d e n s a t i o n t p o 0 4 0 .
  • Page 304 The Digital Controller Menus ESIE07-03 Fan step 5 of circuit 1 = digital output 2 of expansion board 4. Fan step 5 of circuit 2 = digital output 4 of expansion board 4. Depending on the amount of fan steps (contactors), different stage up and stage down parameters have to be set.
  • Page 305 ESIE07-03 The Digital Controller Menus Speed up time = 1 sec. This function puts the phase cut controlled fan(s) at maximum speed for 1 sec to ensure the fan is starting. This to protect the fan against burn out of the fan motor (when the fan is off and the controller gives a signal to run at very low speed, the fan may not be able to start and can burn out).
  • Page 306 The Digital Controller Menus ESIE07-03 F a n t S e t P s D e a d b a n d S t a g e 0 0 8 . 0 S t a g e D o w n 0 0 3 .
  • Page 307 ESIE07-03 The Digital Controller Menus Valve Driver menu In the Unit menu, press the Left arrow key to access the Val Driver menu. The Valve Driver menu allows you to change the settings of the electronic expansion valve. Consulting the Valve Driver menu To scroll further throug the Valve Driver menu, use the Up/Down arrow keys.
  • Page 308 The Digital Controller Menus ESIE07-03 E X V e t t t y p e C U S T O M ■ Electronic expansion Alco EX8 valav type Alco EX7 Alco EX6 Alco EX5 Custom Carel E2V**A Carel E2V**P Danfoss ETS100 Danfoss ETS50 Sporland 50-SHE 25 Sporland SEI 25...
  • Page 309 ESIE07-03 The Digital Controller Menus E X V S e t t i n g H e a t f a c t o r 5 0 . 0 f a c t o r 0 1 0 s f a c t o r 0 2 .
  • Page 310 The Digital Controller Menus ESIE07-03 E X V S u c T e m p e r a t u 0 6 0 . 0 When the suction temperature goes above a certain value, the circuit goes into alarm. E X V t i n g n i m u m e p s...
  • Page 311 ESIE07-03 The Digital Controller Menus E X V S e t t i n g e s s p r o b e v a l - 0 0 0 . 5 b a r g M a x v a l 0 0 7 .
  • Page 312 The Digital Controller Menus ESIE07-03 2.5.2 Compressor menu Accessing In the Settings menu, press the Right arrow key to access the Compressor menu. Settings menu > Compressor As a result the following screen appears. M i n s a m e c o m p s t a r t s M i n...
  • Page 313 ESIE07-03 The Digital Controller Menus ■ Down delay Before actually decreasing capacity (unloading) when the "down temperature" is reached, the controller will wait for the down delay. 4 Press the Down arrow key. The following screen appears. p r e s s u r e 0 6 0 .
  • Page 314 The Digital Controller Menus ESIE07-03 9 Press the Down arrow key. The following screen appears. a g e h o l d t a r o a d i n g When the current gets to the FLA max value, the compressor will hold its capacity (no longer load up).
  • Page 315 ESIE07-03 The Digital Controller Menus So there are about 34 steps from minimum to nominal capacity and 25 from nominal to maximum.. 14 Press the Down arrow key. The following screen appears. L o a d i m e 0 0 . 1 s p e r .
  • Page 316 The Digital Controller Menus ESIE07-03 2.5.3 User menu Accessing In the Settings menu, press the Up arrow key to access the User menu. Settings menu > User < e t p o n t s < S c h e d <...
  • Page 317 ESIE07-03 The Digital Controller Menus 2 Press the Down arrow key. The following screen appears. L v g W a t e r T e m p s e t p i n t r e s N O N E Choose one of the following Leaving water temperature settings ■...
  • Page 318 The Digital Controller Menus ESIE07-03 Used Setpoint Max Reset Base Setpoint Start Reset T Reset Delta T ■ If Return is selected, the following screen appears when pressing the Down arrow key: C h L W T R e t u r n R e s e 0 0 3 M a x...
  • Page 319 ESIE07-03 The Digital Controller Menus 5 Press the Down arrow key. When softload is enabled, the unit will not load more capacity then the maximum stage (50 %) during the maximum time (20 min). E n a b l S o f t l o a d M a x s t 0 5 0 M a x T i m e...
  • Page 320 The Digital Controller Menus ESIE07-03 9 Press the Down arrow key. The following screen appears. C o m p r e s s o r u e n c i n g A U T O Normally the compressor with the least amount of running hours starts first. The start-up procedure can be set to manual.
  • Page 321 ESIE07-03 The Digital Controller Menus ■ Speed 1200 (RS485 / RS422) 2400 (RS485 / RS422) 4800 (RS485 / RS422) 9600 (RS485 only) 19200 (RS485 only) ■ Identification number 1-200 12 Press the Down arrow key. The following screen appears. S u p e r v i s o r y e m o t e S u p e r v i s o r y R e m o t e...
  • Page 322 The Digital Controller Menus ESIE07-03 Time Schedule In the Settings menu, press the Right arrow key to access the Time Schedule menu. menu A a result the Enable time scheduling screen appears. E n a b S c h e d u l i n If you select Yes, you have the posibility to: ■...
  • Page 323 ESIE07-03 The Digital Controller Menus F S M S u n d a y S t o p 2 3 : 2 n d 0 0 : F S M F o r c e D a y s ( 1 ) 0 0 / 0 0 0 0 / 0 0 0 0 / 0 0...

  • Page 324: Alarms Menu

    The Digital Controller Menus ESIE07-03 2.5.4 Alarms menu Accessing In the Settings menu, press the Down arrow key to access the Alarms menu. Settings menu > Alarms As a result the following screen appears. A n t f r e e z e a l a r m S e t p o i n t 0 2 .
  • Page 325 ESIE07-03 The Digital Controller Menus 3 Press the Down arrow key. The following screen appears. p r e s s u r e a r m a y s d e l a y 3 0 0 s R u n 0 9 0 s This function compares the evaporator pressure with the oil pressure.
  • Page 326 The Digital Controller Menus ESIE07-03 7 Press the Down arrow key. The following screen appears. u r a s u c t i o n T e m p a r m d e l a y s 1 2 0 s n n i n g 0 4 0 s When the compressor is starting, the saturated suction temperature (low pressure) alarm is...
  • Page 327 ESIE07-03 The Digital Controller Menus 12 Press the Down arrow key. The following screen appears. E v a p l o w S w i t c h a r m a y s 0 2 0 s R u n 0 0 5 s When the unit starts, there has to be 20 sec of flow during the first 30 sec of pump operation.

  • Page 328: Maintenance Menu

    The Digital Controller Menus ESIE07-03 Maintenance Menu Main screen of the In the Main menu of the controller, press the Down arrow key to access the Maintenance menu. Maintenance menu As a result the following screen appears. < < S E T T N G S <...
  • Page 329 ESIE07-03 The Digital Controller Menus 2.6.1 View menu Accessing In the Maintenance menu, press the Left arrow key to access the View menu. Maintenance menu > View c o u n P u m p E v a p 0 0 0 0 0 7 o n d P u m p 0 0 0 0 0 7...
  • Page 330 The Digital Controller Menus ESIE07-03 o b a P I D r e q u e s t L o a d o a d a n d b y 2 Press the Down arrow key. The following screen appears. A v a i a b l e B o a r d...
  • Page 331 ESIE07-03 The Digital Controller Menus 4 Press the Down arrow key. The following screen appears. N u m . D e f r o s t c y c l e 0 0 4 0 0 7 Fill out the number of defrost of circuit 1 and circuit 2. 5 Press the Down arrow key.
  • Page 332 The Digital Controller Menus ESIE07-03 7 Press the Down arrow key. The defrost conditions of circuit 2 appears. D e f r o s t C o n d C # 2 < Fill out the defrost conditions, for more information refer to the defrost conditions of circuit 1 (see step 5).
  • Page 333 ESIE07-03 The Digital Controller Menus The following screens are only applicable if Heat recovery is selected. 10 Press the Down arrow key. The following screen appears. H o u r o u n t e r P u m p 0 0 0 0 1 7 P u m p 2 0 0 0 0 1 6...
  • Page 334 The Digital Controller Menus ESIE07-03 2.6.2 Settings menu Accessing In the Maintenance menu, press the Right arrow key to access the Settings menu. Maintenance menu > Settings E v a p . P u m p h . C o u n t T h r e s h 0 1 0 x 1 0 0 0 R e s e...
  • Page 335 ESIE07-03 The Digital Controller Menus C o m p . # 2 s t a r t s u s t 0 0 0 1 4 Compressor 2 number of starts and adjustment. 6 Press the Down arrow key. The following screen appears. R e g u b a n d 0 0 4 N e u t...
  • Page 336 The Digital Controller Menus ESIE07-03 M i n M a x i m e 1 5 m i n The unit will switch off when the evaporator delta T is less then 1,0 °C for 15 min. This is to prevent a compressor running at minimum capacity for a long time.
  • Page 337 ESIE07-03 The Digital Controller Menus E x p . D i g . I n p u E n a b 1 0 3 : N D I 1 0 4 : N 2 0 1 : N D I 2 0 2 : N 3 0 1 : N D I 3 0 2 : N E x p .
  • Page 338 The Digital Controller Menus ESIE07-03 r e l o a a n d e u n o a d c o m p 14 Press the Down arrow key. The following screen appears. R e s e t a l a r m b u f f e r 15 Press the Down arrow key.
  • Page 339 ESIE07-03 The Digital Controller Menus P u m p 2 h . C o u n t r e s 0 x 1 0 0 0 R e s e 0 0 0 0 0 7 Secondary heat recovery pump hour counter and adjustment. 20 Press the Down arrow key.

  • Page 340: Debug Menu

    The Digital Controller Menus ESIE07-03 2.6.3 Debug menu Note The Debug menu is beyond the scope of this service manual and will not be discussed. 2–84 Part 2 – Functional Description...

  • Page 341: Functional Control

    ESIE07-03 Functional Control Part 2 Functional Control What Is In This Chapter? Introduction This chapter gives more detailed information on the functions and controls of the unit. Overview This chapter contains the following topics: Topic See page 3.2–Control Possibilities 2–86 3.3–Operating Modes 2–87 3.4–Set-point Management...

  • Page 342: Control Possibilities

    Functional Control ESIE07-03 Control Possibilities Overview ■ Local control ■ Remote control ■ Network control ■ Time schedule ■ Ambient lock out Explanation The control allows different ways to enable/disable the unit: ■ Local Switch: When the digital input “Unit On/Off” is open, the unit is in “Local switch Off”.

  • Page 343: Operating Modes

    ESIE07-03 Functional Control Operating Modes Overview ■ Cooling mode ■ Cooling / Glycol mode ■ Ice operation ■ Heating ■ Cooling + Heat recovery ■ Cooling / Glycol + Heat recovery ■ Ice + Heat recovery Explanation Freeze up Freeze up MODE RANGE (°...

  • Page 344: Set-Point Management

    Functional Control ESIE07-03 Set-point Management Overview ■ Local set-point control ■ Double set-point control ■ Set-point controlled by external input ■ 4 – 20 mA ■ Floating set-point ■ Inlet water control ■ Set-point controlled by BMS system Explanation The control is able to manage the evaporator leaving water temperature on the base of several inputs: ■...
  • Page 345 ESIE07-03 Functional Control 4-20 mA set-point Through an external signal 4-20mA, it is possible to change the value of the local set-point within the control minimum and maximum set limits. Used Setpoint Max Reset Base Setpoint 0 4mA 20mA Analog Input Floating set-point This function is enabled under password "Consumer", setting the set-points in accordance with the range of external temperature set.
  • Page 346 Functional Control ESIE07-03 Delta T reset Allowable under password "Consumer", a reduction of the water evaporator delta T corresponds to an increase of the set-point control of the refrigerated water. This logic of control allows energy saving when the unit works at partial load. Used Setpoint Max Reset Base Setpoint...

  • Page 347: Unit Start Sequence

    ESIE07-03 Functional Control Unit Start Sequence Overview This chapter contains the following topics: Topic See page 3.5.1–Unit Starting Sequence Flow Charts 2–91 3.5.2–Water Pump Operation 2–92 3.5.3–Oil Heating 2–93 3.5.4–Pre-purge Operation 2–94 3.5.1 Unit Starting Sequence Flow Charts Flow chart 1 Refer set point management Unit start Evap pump start...
  • Page 348 Functional Control ESIE07-03 Flow chart 2 Control requires unit loading New Compressor start required (see loading table) New Compressors Compressors selection loading Compressors line contactor closing Transition confirmation Compressor Trip within 10 sec Compressor complete unloading EEV closed Te -10°C EEV 20% for 30 sec.
  • Page 349 ESIE07-03 Functional Control 3.5.3 Oil Heating Explanation Oil heating is required to avoid accumulation of liquid inside the compressor during start up. The start-up of compressors will not be allowed if the following formula is not respected: Discharge Temperature – TOilPress > 5 ° C Where: Discharge Temperature is the compressor discharge temperature (corresponding to oil temperature).
  • Page 350 Functional Control ESIE07-03 3.5.4 Pre-purge Operation General description ■ Principal control is the same for thermostatic and electronic expansion valve. ■ Thermostatic expansion valve • Close liquid solenoid valve till LP < –10° C • When LP < –10° C, compressor operates at 25% ■...
  • Page 351 ESIE07-03 Functional Control Compressor starts with liquid line closed and will open only after the saturated suction pressure gets below –10° C. It is only at this value when the pre-purge will be considered successful and will put the compressor at 25% capacity. Number of cycles at 1 means that the liquid line solenoid can be closed only once –...

  • Page 352: Compressor Management Control

    Functional Control ESIE07-03 Compressor Management Control Overview This chapter contains the following topics: Topic See page 3.6.1–Overview and Explanation 2–96 3.6.2–Definitions 2–97 3.6.3–Compressor Load Evaluation 2–99 3.6.4–Maximum Pull Down Rate 2–102 3.6.5–Compressor Timers 2–103 3.6.6–Inter-stage Timer 2–104 3.6.7–Compressor Rotation Management 2–105 3.6.1 Overview and Explanation...
  • Page 353 ESIE07-03 Functional Control 3.6.2 Definitions Number load pulses Quantity of pulses required to load up from 0 to 100%. The default quantity of pulses is programmed at 6. This should not be changed. Number unloading Quantity of pulses required to load down from 100 to 0%. The default quantity of pulses is programmed pulses at 9.
  • Page 354 Functional Control ESIE07-03 1st pulse duration The first pulse will be longer to make sure that the slide vane is moving correctly (increase in oil pressure). ■ Loading: 1 sec. ■ Unloading: 0.8 sec. During start up there is no pressure difference to move the sliding vanes, therefore the first pulse duration will be 1 second to create a pressure difference for the capacity vanes.
  • Page 355 ESIE07-03 Functional Control 3.6.3 Compressor Load Evaluation Overview ■ Calculation of quantity of lading and unloading pulses. ■ Fixed pulse duration of the loading and unloading pulses. ■ Time interval between 2 pulses evaluated by PD controller (variable). ■ Integral control Calculation of The compressor loading or unloading is obtained by keeping the loading or unloading solenoid loading and...
  • Page 356 Functional Control ESIE07-03 Pulse time A pure proportional logic, will load or unload with a frequence related to the set-point distance. Minimum loading pulse time Max loading pulse time No pulse, stand-by Evap water leaving Set Point Max unloading pulse time Minimum unloading Dead band pulse time...
  • Page 357 ESIE07-03 Functional Control Regulation band loading unloading band band 5.3 5.5 dead band 0.2°C shut down ΔT : 1.7°C start up ΔT : 2.7°C reload ΔT reload ΔT 0.7°C 0.7°C Regulation band : 3°C This value can be changed Values can be programmed as follows: Step Action Maintenance...
  • Page 358 Functional Control ESIE07-03 DT reload-unload reload unload loading unloading band band 5.3 5.5 dead band 0.2°C shut down ΔT : 1.7°C start up ΔT : 2.7°C reload ΔT reload ΔT 0.7°C 0.7°C Regulation band : 3°C This DT can be changed In the DT reload or unload area if a second compressor is requested, the first compressor will go to 50% and start up the second compressor at 25%.
  • Page 359 ESIE07-03 Functional Control 3.6.5 Compressor Timers Overview ■ Anti-recycling timer ■ Minimum time between 2 different compressors starts ■ Minimum operating time compressor ■ Quard timer of compressor Anti-recycling timer Minimum time between a same compressor starts. The compressor is allowed to start up 6 times per hour. Step Action Setting menu...
  • Page 360 Functional Control ESIE07-03 Quard timer of Minimum time compressor off (stop to start timer) compressor The minimum time the compressor has to be stopped; the compressor cannot be started if this timer is not expired. Step Action Setting menu Compressor menu Min.
  • Page 361 ESIE07-03 Functional Control 3.6.7 Compressor Rotation Management Overview There are two possibilities: ■ Automatic rotation: The selection of the compressor sequence will be done by the controller depending on the running hours. ■ Manual rotation: The operator can select which compressor will start first. Programming Step Action...

  • Page 362: Compressor Capacity Control

    Functional Control ESIE07-03 Compressor Capacity Control Principal capacity control Oil Supply Oil Vent to Suction Unload Load Slide Spring Discharge pressure acts on this side of piston HSS 3100 series compressors is provided with infinitely variable capacity control as standard. Since the compressor utilizes fixed intake and discharge ports instead of valves, the overall compression ratio is determined by the configuration of these ports.
  • Page 363 ESIE07-03 Functional Control Loading / unloading compressor Oil Supply Oil Vent Unload De-energised Energised (Closed) (Open) Discharge pressure acts Compressor Unloading on this side of piston Spring Force + Discharge Pressure > Cylinder Pressure = Slide Valve Moves Towards Unload Oil Supply Oil Vent Load...

  • Page 364: Compressor Stopping Sequence

    Functional Control ESIE07-03 Compressor Stopping Sequence Overview This chapter contains the following topics: Topic See page 3.8.1–Pump Down Control 2–108 3.8.2–Manual Control 2–109 3.8.1 Pump Down Control Explanation Every time before the compressor stop, the compressor starts downloading and will finally do a pump-down.

  • Page 365: Manual Control

    ESIE07-03 Functional Control 3.8.2 Manual Control Explanation ■ Can be used to operate the compressor in a certain capacity step ■ No temperature control available ■ All safeties are active ■ If safety activated unit returns to automatic mode Manual mode is mainly used during commissioning and trouble shooting. In the manual mode the installer can select the requested capacity.

  • Page 366: Fan Control Management

    Functional Control ESIE07-03 Fan Control Management Overview ■ Fan Troll ■ Pressure control ■ Pressure ratio control ■ Variable speed driver ■ Speed Troll Explanation ■ Fan Troll: : A step control is used; fan steps are activated or deactivated to keep compressor operation conditions within allowed envelop.
  • Page 367 ESIE07-03 Functional Control Each of the fan contactors is controlled with a digital output. Fan Troll (pressure control) Fan Troll (pressure control) Condensation set-point Fan step 3 Fan step 2 Step difference Fan step 1 °C Step length Depending on the installation and weather conditions, installer can program to head pressure control. A stage up is executed (the next stage is activated) if the condensing saturated temperature (saturated temperature at discharge pressure) exceeds the target set-point (default 40 °...
  • Page 368 Functional Control ESIE07-03 Three parameters need to be programmed: 1 Condensation set-point 2 Step difference: Switching point between the different fan motors 3 Step length: Band to decide to start the first fan or stop the last fan. All above settings are programmed in the controller, but can be changed in function of the operation conditions.
  • Page 369 ESIE07-03 Functional Control Each fan stage will have its own adjustable stage up and stage down dead band. Selection of method of head pressure control (pressure or pressure ratio): Step Action Setting Unit Configuration 4 X  Technical password Condensation Control possibility: PRESS / NONE / PR (pressure ratio) Type: DBL / SPEED / FANTROL / VSD / FAN modular Selection of the settings of the head pressure control:...
  • Page 370 Functional Control ESIE07-03 ■ Speed Troll Fan speed controlled using an analogue output signal 0 – 10Vdc. pressure / Speed ■ Only one fan per circuit is controlled by speed troll. Troll pressure ratio ■ Three other fans are ON / OFF controlled. Remove when Speed troll fan using speed troll...

  • Page 371: Liquid Injection

    ESIE07-03 Functional Control 3.10 Liquid Injection Liquid injection when discharge °C temperature becomes too high 85°C 75°C To avoid possible overheating of the compressor, a liquid injection is activated when the discharge temperature becomes higher than 85° C. This control is reset when the discharge temperature becomes 10° C lower. These values can be changed in the controller.

  • Page 372: Electronic Expansion Valve Control

    Functional Control ESIE07-03 3.11 Electronic Expansion Valve Control EEV valve control Superheat is controlled using the saturated suction temperature (LP) and the suction temperature. Expansion valve Live time battery 18 months The Electronic expansion valve (EEV) circuit is build up of the following parts: 1 Expansion valve 2 Suction sensor 3 Low pressure sensor (Saturated suction temperature)
  • Page 373 ESIE07-03 Functional Control ■ Parameters Pre-opening valve ■ Type of valve ■ Type of refrigerant ■ Superheat Set-Point e Dead Band ■ Proportional, Integral time and Derivative time ■ Low Superheat protection ■ LOP Protection ■ MOP Protection ■ High suction temperature ■...
  • Page 374 Functional Control ESIE07-03 Driver EXV status Under normal conditions, the five (5) LEDs indicate: ■ POWER (yellow): remains On in presence of supply. Remains Off in case of battery operation ■ OPEN (green): Flashing during the valve opening. On when valve is fully open. ■...
  • Page 375 ESIE07-03 Functional Control Electronic expansion valve Tapered side valve Inlet Outlet Part 2 – Functional Description 2–119...

  • Page 376: Economizer

    Functional Control ESIE07-03 3.12 Economizer Typical single compressor Principal application *To ensure equal distribution of gas, economiser line branches must be the same diameter, length and contain the same number of elbows TEV Equalising Line Evaporator Equaliser Line Condenser The compressor is provided with an economizer facility. This enables an additional charge of gas to be handled by the compressor, over and above that which is normally pumped.
  • Page 377 ESIE07-03 Functional Control unloads, the pressure at the economizer port falls towards suction pressure and the additional capacity and improved efficiency economizer system is no longer available. As a guide to this effect, approximately half of the improvement due to using an economizer system will be lost by the time the compressor unloads to 90% capacity, and falls to zero at around 70% capacity.
  • Page 378 Functional Control ESIE07-03 pCOe expansion # 1 To have this function an additional expansion board is required. This board will control the 2 economizer valves. - additional hardware & economizer Analog Input Digital Input Description Type Description Comp. Capacity Sensor # 1 4-20mA SPARE Comp.
  • Page 379 ESIE07-03 Functional Control ■ Economizer Installation of expansion board conditions ■ Address of expansion board: 1 ■ Economizer activated if compressor capacity = 90% ■ Economizer switch OFF if compressor capacity = 75% ■ Precaution ■ Economizer switch OFF if HP saturated > 65° C ■...

  • Page 380: Heat Recovery

    Functional Control ESIE07-03 3.13 Heat Recovery pCOe expansion # 2 – heat recovery Analog Input Digital Input Description Type Description Ambient temperature sensor Heat Recovery switch SPARE Heat Recovery Flow switch Entering HR water sensor SPARE Leaving HR water sensor SPARE Partial heat recovery...
  • Page 381 ESIE07-03 Functional Control Full heat recovery 1. Single-screw compressor 17. Liquid receiver 2. No-return valve 18. Recovery cycle three-way switch valve 3. Compressor delivery tap 19. Recovery exchanger 4. High-pressure safety valve (24.5 bars) WL1-2. Low-pressure transducer 5. Condenser battery (-0.5:7.0 bars) 6.
  • Page 382 Functional Control ESIE07-03 Heat recovery operation HR LWT Regulation Setpoint Band No staging Stage Stage down Time HR Interstage ■ Heat recovery dead band: area where the capacity of the compressor remains the same. ■ Stage timer: Time between 2 capacity step increases or decreases. ■...
  • Page 383 ESIE07-03 Functional Control ■ Flow switch Failure if flow is not within specification problem during ■ Same function if unit is switched OFF (no) operation Flow switch Anti recycling Anti recycling 30 sec 30 sec 30 sec timer timer Auto reset Auto reset Manual reset Part 2 –...

  • Page 384: Limitation

    Functional Control ESIE07-03 3.14 Limitation Overview ■ High pressure limitations (software / hardware) ■ Low pressure limitations (software / hardware) ■ Oil heating (software) ■ Chilled water limitation (software) ■ High leaving water start up ■ Enable outdoor ambient lock out Low pressure limitation Saturated...
  • Page 385 ESIE07-03 Functional Control Oil heating Start up compressor not allowed if: ■ Discharge temperature sensor in PT 1000 – T oil pressure < 50° C ■ No fault appears ■ Check at compressor status for oil heating Discharge Condition: superheat ■...
  • Page 386 Functional Control ESIE07-03 2–130 Part 2 – Functional Description...

  • Page 387: Part 3 Troubleshooting

    ESIE07-04 Part 3 Troubleshooting Introduction When a problem occurs, all possible faults have to be checked. This chapter gives an overview of all possible alarm messages, which visualize the faults. What is in this part? This part contains the following chapters: Chapter See page 1–Alarm Messages...
  • Page 388 ESIE07-04 3–2 Part 3 – Troubleshooting...

  • Page 389: Alarm Messages

    ESIE07-04 Alarm Messages Part 3 Alarm Messages What Is in This Chapter? Introduction This chapter gives an overview of all possible alarm messages. Overview This chapter contains the following topics: Topic See page 1.2–Overview of the Alarm Messages 3–4 Part 3 – Troubleshooting 3–3...
  • Page 390 Alarm Messages ESIE07-04 Overview of the Alarm Messages PVM or GPF alarm PVM (Phase Voltage Monitor) or GPF (Ground Protection Failure) alarm. This is caused by the voltage monitor. Voltage is either too low (<360 V) or too high (>440 V). Or a phase can be reversed or missing. A L : 0 0 1 P V M G P F...
  • Page 391 ESIE07-04 Alarm Messages Evaporator pump The primary evaporator pump hour counter reached the maintenance threshold. alarms p o r a t o r p u m p n t e n a n c e The secondary evaporator pump hour counter reached the maintenance threshold. A L : 0 S e c o n d p u m p...
  • Page 392 Alarm Messages ESIE07-04 Flow alarms Evaporator flow alarm. A L : 0 1 1 A L : 0 1 1 E v a p o r a t o E v a p o r a t o f l o w f l o w a l a r m a l a r m...
  • Page 393 ESIE07-04 Alarm Messages B10 probe fault 0 1 3 B 1 0 p r o b e f a u l t n o t c o n n e c t e d Probe fault on the driver of the electronic expansion valve. A L : D 1 1 E X V v e r...
  • Page 394 Alarm Messages ESIE07-04 Pressure alarms The ratio between the low and the high pressure is not big enough. A L : 1 0 2 L o w p r e s s u r a t i o a l a r m High pressure switch.
  • Page 395 ESIE07-04 Alarm Messages Oil pressure alarms The difference between the low pressure and the oil pressure is not big enough. A L : 1 1 4 L o w O i l P r e s s u The difference between the oil pressure and the high pressure is too big. Cause: oil filter is blocked.
  • Page 396 Alarm Messages ESIE07-04 3–10 Part 3 – Troubleshooting...

This manual is also suitable for:

Ewad210-500ajynn/qEwad260-650ajynn/aEwad200-600ajynn/hEwad330-520ajynn/sEwad330-520ajynn/xEwyd260-380ajynn

Table of Contents
