Notes On Schematic Diagram - Sharp QT-50Z Service Manual

I
A
Resistor:
l
To differentiate the units of resistors, such symbol as K is
used: the symbol K means 1000 ohm and the resistor
without any symbol is ohm-type resistor.
To indicate the unit of capacitor, a symbol P is used:
this symbol P means micro-micro-farad and the unit of
the capacitor without such a symbol is microfarad. As
to electrolytic capacitor, the expression "capacitance/
withstand voltage" is used.
The indicated voltage in each section is the one measured
l
I
1
2 3
2 I 3
4 I
by Digital Multimeter between such a section and the
chassis with no signal given.
Marking except for (
Schematic diagram and Wiring Side of P.W.Board for this
l
model are subject to change for improvement without prior
notice.
. Parts marked with " A" ( -,' ) a r e i m p o r t a n t f o r m a i n -
taining the safety of the set. Be sure to replace these parts
with specified ones for maintaining the safety and per-
formance of the set.
I 4 I
5 6
I
5 I 6
Figure 9 WIRING SIDE OF
I
