INSTRUCTION MANUAL
1600W ELECTRIC
SAW BENCH
Model No: THSBENCH -- Product No: 193877002
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying attention to the safety instructions, before
use.
The manufacturer reserves the right to change the product specification and livery
according to continued product improvements.
All images used are for illustration purposes only.
24-02-2017
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for The Handy THSBENCH
Summary of Contents for The Handy THSBENCH
- Page 1 INSTRUCTION MANUAL 1600W ELECTRIC SAW BENCH Model No: THSBENCH -- Product No: 193877002 ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 Please read & understand this manual, paying attention to the safety instructions, before use. The manufacturer reserves the right to change the product specification and livery according to continued product improvements.
-
Page 3: Specifications
Tel: 01793 333212 - Monday to Friday (8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk SPECIFICATIONS The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model Number THSBENCH Product Number 193877001 Voltage 230V~ 50Hz Rated Power (Watt) -
Page 4: Intended Use
IMPORTANT INFORMATION INTENDED USE The device is intended for cutting fibrous or woody organic material from household and garden. It may not be filled with stones, glass, metal, bones, plastics or material scraps. This product is not intended for commercial use. Generally acknowledged accident prevention regulations and enclosed safety instructions must be observed. -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 STAY ALERT Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand. Be aware of what you are doing at all times. Use common sense. AVOID DANGEROUS CONDITIONS Make sure there is adequate surrounding workspace.
-
Page 7: Protect The Environment
MAINTAIN YOUR MACHINE WITH CARE Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full & safest performance. When maintaining this machine, only the manufacturer’s original replacement parts should be used. The use of non-original manufacturer parts may invalidate your warranty. PROTECT THE ENVIRONMENT Take left over materials to an authorised collection point or follow the stipulations in the country where the mixer is used. - Page 8 CONTENTS...
- Page 9 ASSEMBLY Insert four M8x75 bolts with flat washers through the holes located on the left leg, right leg separately and fixing bracket, tightly fasten down with flat washers and lock nuts. Install the switch with four M4x55 bolts on the fixed board.
- Page 10 Insert two M8x20 bolts with flat washers through holes on the guard cover & the motor board, tightly fasten with flat washers and lock nuts. Align the holes on the bottom of stand attached to the guard cover with the upper holes on the mounting board for shaft as shown in Fig C, insert the M8x50 bolt with a flat washer through the hole, fasten with a...
- Page 11 Lifting the assembled sawing table slightly, push the left & right pull- back pieces into the rear of the left & right guard cover as shown in Fig E. Align the holes on the left and right legs of the sawing table with the holes on the left & right legs, insert two M8x75 bolts with flat washers into the holes from outside, tightly fasten with flat washers and lock nuts.
-
Page 12: Operation
OPERATION DANGER The product must only be put into operation if no defects are found. It is crucial that a defective parts are replaced before the product is used again. Check the safety equipment and the safe condition of the product: Check all parts to make sure that they fit tightly. -
Page 13: Preventative Maintenance
MAINTENANCE DANGER Before all cleaning & maintenance work, switch the device off & disconnect the mains plug from the electrical source. Wait until all moving parts have come to a complete stop & the device has cooled. PREVENTATIVE MAINTENANCE Inspect the general condition of the entire product. Check for loose screws, misalignment or binding of moving parts, cracked or broken parts, and any other condition that may affect its safe operation. -
Page 14: Cleaning The Device
CLEANING DANGER Before all cleaning and maintenance work, switch the device off and disconnect the mains plug from the electrical source. Wait until all moving parts have come to a complete stop and the device is cooled off. CLEANING THE DEVICE –... -
Page 15: Troubleshooting
TROUBLE SHOOTING DANGER Improper repairs can cause your device to stop functioning safely. You therefore endanger yourself, bystanders and your environment. PROBLEM PROBABLE CAUSE REMEDY SUGGESTED No Mains Voltage? Check cable, plug, socket and fuse. Contact your local Approved Service Cable Faulty? Dealer or Electrical Specialist if out of Warranty. -
Page 16: Parts Diagram
PARTS DIAGRAM (193877002) -
Page 17: Parts List
PARTS LIST (193877002) -
Page 18: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: 1600 Watt Electric Saw Bench Model(s): THSBENCH Product No: 193877002 Type/Serial No: As per rating label on machine Complies with the following directives: 2006/42/EC –... - Page 19 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 20 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
- Page 21 NOTES _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________...
- Page 22 NOTES _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________...
- Page 24 For spares or support of your handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
