Summary of Contents for Suzuki TP-100
- Page 1 Modern Console Piano Owner’ s Manual...
- Page 2 Suzuki Musical Instrument Corporation P.O. Box 710459 Santee, California 92072-0459 800-854-1594 www.suzukimusic.com Copyright Suzuki Musical Instrument Corporation O W N E R ’ S M A N U A L...
-
Page 3: Table Of Contents
Table of Contents General Precautions ..........4 Taking Care Of Your Digital Piano. -
Page 4: General Precautions
General Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated or “dangerous voltage”... - Page 5 Suzuki listed within this owners manual. In order digital piano. With proper care this piano will to make the most of your Suzuki Piano’s provide you with years of musical enjoyment. performance potential and musical features, Suzuki’s Advanced State of the art electronics...
-
Page 6: Taking Care Of Your Digital Piano
Taking Care Of Your Digital Piano This digital piano will supply you with years of musical enjoyment if you follow the simple rules listed below. Important Safety Instructions Warning High Gloss Lacquer Finish Furniture may be used on the cabinet. Do not use paint thinner or petrochemical When using electrical products, basic safety precautions based polishes. -
Page 7: Control Panel And Pedal
Control Panel And Pedal Front Control Panel Master Volume –/NO +/YES Record Song Voice Select Demo, Setup, EQ, Chorus, Layer, Lower, Display Metro,Tempo Duet, Transpose See detailed description of the control panel in the following chapters. Power Switch The power switch is located to the left of the keyboard. Press the button to turn the power on and off. -
Page 8: Piano Pedals
Piano Pedals q w e SOFT PEDAL — When the left pedal is engaged the piano volume is reduced and the timbre slightly altered on the notes that are played. SOSTENUTO PEDAL— The function of it is similar with the sustain pedal. However when playing notes and then engaging the middle pedal, the notes will be sustained. -
Page 9: Preparing For Play
Preparing For Play Key Cover / Fallboard Suzuki has installed a slow close fallboard on this piano to ensure the upmost of safety. This means that the Key Cover slowly falls to the closed position when set in a downward position. -
Page 10: Demo Songs
Headphones This Piano has two stereo headphone jacks on the front left of the bottom of the piano. You can play in total silence, without disturbing others in the room. When Headphones are plugged into the headphone jacks the speakers will turn off. -
Page 11: Instrument Voices
Instrument Voices When the piano is turned on, the LED display shows the voice number. The default voice setting is 01 for the Grand Piano. Select A Insturment Voice There are 15 instrument voices numbered 1-15 and selected by the voice quick select buttons and a VARIATION button. -
Page 12: Layer Voice
Layer Voice With layer mode, you can layer (or mix) two instrument sounds together. Press the LAYER button and its indicator lights. The LED display shows the layered voice number (the default layered voice is strings). LAYER To Change the LAYER instrument voice Press the LAYER button and a voice select button simultaneously, the layer voice mode is engaged as well but the LAYER indicator flashes. -
Page 13: Keyboard Mode
Keyboard Mode There are two modes of the keyboard: full keyboard and duet keyboard. Full Keyboard The full keyboard is standard mode as shown below. Duet Keyboard The keyboard is divided to A2- E6 and F2 – C6 two sections. Two sections have the same voice (master voice) and volume. -
Page 14: Sound Effect
Press the Lower button and its indicator lights up to engage the split keyboard mode. The display shows the master voice number. If press the LOWER button and LOWER a voice select button simultaneously, the lower voice selection is engaged and the LAYER indicator flashes. -
Page 15: Brightness
Each voice has its own reverb and chorus default setting. When a voice with chorus effect is selected, the CHORUS indicator will turn on automatically. The sound effects adjustment applies to two voices in the dual voice and duet keyboard mode. -
Page 16: Record
Record The recording function features a two track recorder that lets you record what you play on the keyboard and then play it back. Two tracks mean that you can “overdub” one part on top of another, using a different voice if you like. TRACK 1 TRACK 2 PLAY/STOP... -
Page 17: Erasing Tracks
5. Stop Recording - Press the PLAY/STOP button, the REC button or the recording track button to stop recording. The REC indicator turns off and the recorded track PLAY/STOP indicator is lit to show the track now contains data. Note: When the record memory is full, recording will stop automatically and “FUL” will appear on the LED display. -
Page 18: Play Along Songs
Play Along Songs There are 58 songs built into this Suzuki Piano for your musical enjoyment. These songs have separate left and right-hand parts that can be turned on and off as required so you can practice the corresponding part on the keyboard. -
Page 19: Function Mode
Practicing Both Hands Of The Selected Song 1. Press the RIGHT and LEFT buttons simultaneously. The right and left indicators will both turn on. LEFT HAND RIGHT HAND 2. Press the PLAY/STOP button. Its indicator lights up and you will hear the metronome “count in”... -
Page 20: Master Tuning
Master Tuning This function allows you to adjust the piano’s pitch to match recordings or other instruments in an ensemble. When entering this mode by pressing the SETUP button, the display shows “tun”. Use the –/NO +/YES buttons to set desired tuning value ranged -64 to 64. Press SETUP –/NO +/YES buttons simultaneously to recall the default setting 0. -
Page 21: Local Off
Local Off “Local Off” is a special mode of piano performance when the piano is connected with another MIDI device or computer. When “Local” is “On”, performance on the piano will sound by built-in speakers while the performance message is transmitted via MIDI out. When “Local” is “Off”, performance on the piano will not sound but the performance message is transmitted via MIDI out. -
Page 22: Soft Reset
Soft Reset The recorded music, layer voice, touch mode, song number are non-volatile. When turn on the power, the settings above will be recalled automatically. If you want to recover the default setting, press and hold down both –/NO +/ V A L U E YES buttons when turn on the power. -
Page 23: Midi
MIDI MIDI (Musical Instrument Digital Interface) is a world-standard interface that enables electronic musical instruments and computers to communicate with each other so that instructions and other data can pass between them. This makes it possible to create a system of MIDI instruments and devices that offer far greater versatility and control than is available with isolated instruments. -
Page 24: Midi Application Chart
Midi Application Chart Function Transmitted Recognized Remark Basic Channel 1 CH 1 – 16 CH Channel changed 1 – 16 CH 1 – 16 CH Default mode Note number 11 – 118 0 – 127 Velocity Note On 9nV,V=0–127 9nV,V=0–127 Note Off 8nV,V=0–127 8nV,V=0–127... -
Page 25: Specifications
Specifications Keyboard: 88-note, Hammer-Action keyboard Voices: 15 Voices, 5 buttons + a variation button Voice Mode: Upper, Layer, duet Sound Effects: Reverb and Chorus Control Buttons: Transpose, Tempo, Setup, Metronome, Demo, +/-, Setup: Tuning, Octave, Touch response, Volume balance Demonstration: 10 orchestra songs; each voice has a demo music piece Teaching: 58 Lesson songs, right / left hand training Recording: 2 tracks Display: 3 X 7-segment LED...
