SWELLPRO ZERO User Manual

Monitoring camera

ZERO CAMERA USER MANUAL

1. Main Features

960x 240, 2 inch TFT LCD Screen

16MP Panasonic Full HD CMOS Sensor

166〫 7G Full Glass wide angle lens

Full HD 1080p H.264 Video Codec, MOV video format

Continuously recording without "Leakage seconds"

Loop record automatically, Footage Time Length settable

Support taking picture

Video/Audio playback

Support 1GB~64GB Class 10 SDHC or higher speed

High speed USB2.0 data transfer and power charge

USB and RCA video output optional

Support HDMI1.4 HD output

Support CVBS AV output

Support WIFI 802.11 b/g/n wireless control

Optional Resolution & Frame Rates：

16：9 1920x1080 60fps

4：3 1600x1200 60fps

16：9 1280 x 960p 60fps

16：9 1280 x 720p 120fps

4：3 848 x 480 240fps

Optional Image Resolution：

4608 x 3456 16MP/Piece

4608 x 3072 14MP/Piece

4608 x 2592 12MP/Piece

Table of Contents

Do you have a question about the ZERO and is the answer not in the manual?

Page 1 ZERO CAMERA USER MANUAL 1. Main Features 960x 240, 2 inch TFT LCD Screen 16MP Panasonic Full HD CMOS Sensor 166〫 7G Full Glass wide angle lens Full HD 1080p H.264 Video Codec, MOV video format Continuously recording without “Leakage seconds”...
Page 2 2. Buttons REC / Confirm Mode / Power UP ⑥Lens DOWN ⑦WIFI / REC indicator WIFI / Function ⑧Power indicator ① REC indicator ⑤ Battery house ② HDMI output ⑥ Speaker ③ TF slot ⑦ REC indicator ④ USB slot Note：The video recording might be interrupted or not functional if the using SD card is not original.
Page 3 4. Basic Instruction 1) . Power ON/OFF, Mode Switch 2) . REC/Taking Picture, Confirm Power ON: Press & Hold REC: Single press under REC Mode Power OFF: Press & Hold Taking Picture: Single press under Picture Mode Single Press: Switching Mode Confirm: Single press to save settings 3) .
Page 4 5. Definition of Photography functional cable① ③ Black: GND ①Red: Signal ② Black: GND ③ Connection port to ZERO Camera White: AV Out Red: DC 5V Input Note：The Input voltage is DC 5V for ZERO Camera. 6. Screen Icons...
Page 5 Attention: Camera will lost warranty if waterlogged or disassembled. Please read the user manual carefully before operation, this user manual might not be the newest, please contact us if any questions. SwellPro Team MOOGU (SHENZHEN) TECHNOLOGY CO. LTD. Tel: +86-755-86622175 Email: fpvfactory@gmail.com...
