Centurion
CAST IRON FLUELESS GAS STOVE
INSTALLATION, SERVICING
AND USER INSTRUCTIONS
All i i nstructions m m ust b b e h h anded t t o t t he u u ser f f or s s afekeeping
Revision A - 07/01
Country(s) of destination - GB,IE
Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e-mail: sales@focalpointfires.co.uk
Advertisement
Table of Contents
Related Manuals for Focal Point Centurion
Summary of Contents for Focal Point Centurion
- Page 1 All i i nstructions m m ust b b e h h anded t t o t t he u u ser f f or s s afekeeping Revision A - 07/01 Country(s) of destination - GB,IE Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT Tel: 01202 499330 Fax: 01202 499326 www.focalpointfires.co.uk...
- Page 2 INST T ALLAT T ION I I NST T RUCT T IONS P P r r e e l l i i m m i i n n a a r r y y N N o o t t e e s s B B e e f f o o r r e e I I n n s s t t a a l l l l a a t t i i o o n n This appliance is a High Efficiency, Flueless, Live Fuel Effect stove.
-
Page 3: Table Of Contents
Sec c tion Contents s Pag g e N N o. Sec c tion Contents s Pag g e N N o. Important N N otes Operating the Appliance Appliance D D ata Spark Failure Installation R R equirements Setting Pressure 3.1 Room Sizing 10.0 Briefing t t he C C ustomer... -
Page 4: Appliance D D Ata
APPLIANCE D D ATA Gas Group G20 Natural Gas CAT I2H Inlet Pressure 20 mbar Max Energy Input Gross 3.5 kW 3.15 kW Max Gas Rate 0.33 m3/h Min Energy Input Gross 2.1 kW 1.89 kW Pilot Energy Input Gross 166 W 150 W Burner Pressure High... -
Page 5: Site R R Equirements
SITE R R EQUIREMENTS ( ( continued) The stove is designed to be versatile, and as such will operate correctly when exposed to normal gentle draughts experienced within the home. It is not recommended, however that the appliance be installed in areas where it is likely to be exposed to persistent strong draughts, that may be generated by outside doors or windows, air vents or other. -
Page 6: Ventilation
VENTILATION A minimum of 100 cm2 purpose provided ventilation is required for this appliance. An openable window or equivalent is also required. The requirements of other flued appliance operating in the same room or space must be taken into consideration when assessing ventilation. Any ventilation fitted must comply with BS 5871 part 1 and BS 5440 part 2. -
Page 7: Fuel B B Ed L L Ayout
FUEL B B ED L L AYOUT Place the brick panel against the rear of the firebox. Place the ceramic combustion matrix onto the burn- er and the ceramic side cheeks onto the matrix. Ensure that the hole for pilot flame viewing is clear and easily visible. -
Page 8: Testing A A Nd C C Ommissioning
FUEL B B ED L L AYOUT ( ( continued) Note: T T he c c oals s m m us s t n n ot b b e c c rammed t t og g ether o o r i i ns s erted i i nto t t he h h oles s i i n t t he m m atrix. A A w w ell l l aid o o ut, g g ener- ous s ly s s pac c ed c c oal l l ayout w w ill g g ive t t he b b es s t r r es s ults s . -
Page 9: Setting Pressure
SETTING P P RESSURE Remove the screw from the pressure test point, situated on the main burn- er supply pipe and protruding from between the gas valve and the fire tray, and attach a U gauge. Light the stove and set the thermostat to the maximum setting (6). -
Page 10: Cleaning The Coals
11.0 SERVICING ( ( continued) 14. Refit the cast front and then replace the lid, push firmly downward. 15. Check the purpose provided ventilation is un-obstructed. 16. Light the stove and test setting pressures. 17. Check safe operation of the appliance. 11.1 For specific servicing instructions, see relevant sections. -
Page 11: Catalyst
11.4 CATALYST It is recommended that the catalyst is inspected for signs of damage and dirt during routine servicing proce- dures. The expected life of the catalyst is in excess of 11,000 hours (10 years of normal use). After this time the cata- lyst should be replaced. -
Page 12: Troubleshooting G G Uide
12.0 TROUBLESHOOTING G G UIDE Stove s s parks s b b ut p p ilot d d oes s n n ot l l ig g ht No gas to stove, check isolators are open. Pipe work blockage, clean out. Air not fully purged, re purge supply or wait longer. - Page 13 USER I I NSTRUCTIONS Sec c tion Content Pag g e N N o Important Notes Clearances to Combustibles Ventilation & Room Size Operating Instructions Combustion Spillage Monitoring System Cleaning Coals & Ceramics Servicing List of Replacement Parts IMPORTANT N N OTES The installation and Servicing of this stove MUST only be carried out by a competent person (such as a CORGI registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the rele- vant British Standards, Codes of Practice, the Building Regulations and the manufacturer's instructions.
- Page 14 This appliance is only suitable for the gas type for which it is supplied. CLEARANCES T T O C C OMBUSTIBLES Clearance to the sides of the stove are 100mm (4in) but curtains, drapes and other fabrics are not permitted within a distance of 500mm (20in) of the stove sides and back.
- Page 15 Upon lighting and after the further 10 seconds, release the knob and turn further to the left to the ON posi- tion. The main burner will light and be controlled in accordance with the thermostat knob setting. Adjust the thermostat knob to the desired setting, the higher the number the higher the room temperature will become prior to the stove reducing its heat input.
- Page 16 COAL AND CERAMICS ( ( contin- ued) Place the ceramic combustion matrix onto the burner and the ceramic side cheeks onto the matrix. Ensure that the hole for pilot flame viewing is clear and easily visible. Place the front row of 5 moulded coals onto the matrix, equally spaced across the width of the fire.
- Page 17 Refit the glass door and secure in position using the four large retaining screws. Refit the front casting, and replace the lid of the stove. COAL A A ND CERAMICS (continued) SPECIA A L N N OTE: E E valuate t t he f f lame p p ic c ture w w ith t t he g g las s s s d d oor i i n p p lac c e, p p aying g p p artic c ular a a ttention t t o a a ny flames s t t hat p p lay o o nto t t he f f irebox s s ides s o o r f f orwards s t t oward t t he g g las s s s d d oor.
