CLN-SW-6x1-M Copyright and Trademarks: All rights reserved by APANTAC LCC, Portland, Oregon, USA. No part of this document may be reproduced in any form or by any means without written permission from the product manufacturer. Changes are periodically made to the information in this document.
HDMI-8x8 Matrix Switch WHAT’S IN THE BOX? CLN-SW-6x1-M Switch RS-232 Communication Connecting Cable Power Cord IR Extender Female 1x5 screw terminal IR Remote Control Rack Ear Screws 2 Rack-Mount Bracket Features Seamless switching with different resolutions § Multiple different types of inputs VGA, YPbPr, DVI or HDMI §...
Buttons 4 ~ 6: HDMI inputs (4, 5 and 6) • Aspect Ration Full Figure 4.2: Aspect ratio Full Figure 4.3: Aspect ratio 1:1 APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 7
Resolutions: To set the output resolution to 720P or 1080P • IR: IR receiver can receive signals from the remote control APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
HDMI-8x8 Matrix Switch 4.0.3 Rear Panel Figure 4-5 CLN-6x1-M Rear Panel Power: 90 to 250 50/60Hz IR Rx: Used to connect the IR receiver cable for IR control IR EXT port: This is used to connect the IR receiver cable for the matrix remote control Input: HDMI 1~4 Output: RJ-45 (1~4).
Page 9
Inputs 4 ~ 6: HDMI inputs (4, 5 and 6) VGA E-DDC assignment DVI connector assignment HDMI Type A connector assignment APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Use a HDMI cable to connect any HDMI devices to the Matrix. Use a CATx cable to connect the HDBT-1-Rs-II-POE to the output (RJ-45) APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Figure 5.2: Output connection IR EXT Connection An IR receiver cable is provided to extend the IR receiver to a more convenient location. APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
CLN-SW-4x4-HDBT also supports a LAN port that allows you to control the switch through browser. Figure 5.7: LAN port and Control PC Connection APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Note: RS-232/485 baud rates are 9600bps, no odd or een, 8 bit , 1 bit stop (9600, N, 8, 1) APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 15
HDMI-8x8 Matrix Switch 5.6.4 DIP Switch (8 pins) Figure 5.12: DIP Switch Dip switch pins 1 to 5: Down position (ON) is “0”, the up position (OFF) is “1”. The default value is “ON” Dip switch pin 6: Master/slave (enable/disable). Only the master can be controlled by the external controller, the others switches in the system must be slave.
Page 16
ID determines which matrix is to be controlled. This can be set by using the On/Off switches on the real panel. APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
CLN-SW-6x1-M 6.0 Switcher Application Software 6.1 Software Introduction The <AV Matrix> matrix control software is used in many different Apantac products. 6.1.1 Software Description The <AV Matrix> is a matrix testing application. The operating environment is as follows, Windos 7/98/2000/NT/XP/Vista...
Page 19
Once the installation is complete, click on the <AV Matrix> Icon to launch the application. In the “Options” dialogbox, select the comport and baud rate, then click “OK”. Figure 6.2: Matrix Option Dialog APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Launch the browser on the PC, type in the IP address, http://192.168.0.3 to log into the AV Matrix control configuration. APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 21
CLN-SW-6x1-M Figure 6.4: Web interface Note: Only the video portion of the interface applies to CLN-SW-6x1-M. Set: To set the video (input) and output matrix OFF: Disable all outputs Refresh: To refresh the status of the configuration. Physical button pushes on the front panel will not correlate to the web interface in real time.
Page 22
Clicn on “Refresh” to retrieve the latest statrus. Figure 6.8: Device Status Information APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 23
IP address, you will need to power cycle the matrix You can also use the DIP switches on the rear panel to reset the IP address. APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
APPENDIX A Portable Remote Control APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 25
2. Click on the browser to select the firmware file in “.bin” formate, the click “Upgrade” to upload the firmware to the webserver APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 26
4. 1: Matrix device will allow you to upgrade FW to switches ID 0 to ID 32 5. Select “2: Switcher I/O module” will allow you to uprade I/O modules. You will APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 27
7. If there is firmware that is already on the webserver. The “Erase Flash” information window will appear to notify you to remove the existing firmware before you can upgrade the device. APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 28
Byte 5: CRC Byte (CB) Note: Host must send CRC code to follow the last byte Device Byte BT: Broadcast Command Flag APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 31
3. Memory/Preset #0 is the current status. Presets can only be stored from memoery #1 – 8. 4. Use 0x3F to confirm the device connection APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 32
Table – Command Index List Value Byte Index: Please refer to “Table-Host Request List” and “Table – Command Index List” APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 33
CLN-SW-6x1-M Table – Command Value List APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 36
IB: Often means the input or output port number (Port1=1, Port 2=2 … Port n=n) VB: Response the status refers to this table APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 37
Firmware version contains VERA, VERB and VERC (ex: VERA.VERB.VERC) VERA: Data 1, Bit 7 Bit 4 (Range 0 - 9) APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 38
Bit 6: 1 – Support video routing tools request (Request 0x01, 0x03, 0x05 and 0x07) 0 – Not supported for Video route tool request Bit 5: 1 – Extended information exists (Request 0x3F [0x01] APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 39
0 – Maximum LB is 64 bytes (default) 1 – Maximum LB is 128 bytes 2 – Maximum LB is 254 bytes 3 – Rserved APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 40
VIPD - Video input plug detection command flag. (Request 0x09) 1 - Supports Video input plug detection. 0 – Does not support Video input plug detection. APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
Page 41
0 – Does not support Audio output plug detection. Others - Bit 7~4 are reserve, always 0 DTMAX: defines audio maximum delay time (Unit 100ms) APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224 INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921...
