Lux Products GEOx Operating Instructions Manual

Smart thermostat with humidification/de-humidification control
Hide thumbs

Advertisement

Table of Contents

TABLE OF CONTENTS

1.
Adjusting Temperature .................................................................................3
2. Adjusting System Mode and Fan Mode ..................................................4
3. Adjusting and Setting Schedules ..............................................................5
4. Adjusting Relative Humidity Set-Point ...................................................7
5. Network ..............................................................................................................8
6. Display .................................................................................................................8
7. System .................................................................................................................9
8. Humidification / De-Humidification .......................................................10
9. About-Device / About-Network ............................................................. 13
10. LCD Display Icon Reference ...................................................................... 14
Smart thermostat
x
with Humidification/De-humidification control
Operating Instructions
Enter/Confirm
Scroll
Right = Increase
Left = Decrease
Back/Cancel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GEOx and is the answer not in the manual?

Questions and answers

Related Manuals for Lux Products GEOx

Summary of Contents for Lux Products GEOx

  • Page 1: Table Of Contents

    Smart thermostat with Humidification/De-humidification control Enter/Confirm Scroll Right = Increase Left = Decrease Back/Cancel TABLE OF CONTENTS Everyday Use Adjusting Temperature .................3 2. Adjusting System Mode and Fan Mode ..........4 3. Adjusting and Setting Schedules ..............5 4. Adjusting Relative Humidity Set-Point ...........7 Custom Settings 5.
  • Page 2 J: Relative Humidity C: Current System Mode K: Humidification Mode D: Active System Process L: Current Time E: Fan Status M: External Temperature F: Wifi Connection Status N: Current Date G: Current Schedule Period H: Current Set Temperature LUX GEOx OPERATING INSTRUCTIONS...

  • Page 3: Everyday Use Adjusting Temperature

    HEAT COOL 71°F 73°F FOR: 01HR 45MINS If you have not yet set a HOLD schedule, it will hold this new temperature indefinitely. °F HEAT COOL 71°F 73°F LUX GEOx OPERATING INSTRUCTIONS...

  • Page 4: Adjusting System Mode And Fan Mode

    Rotate the wheel to select your desired system mode and press to confirm. • Auto: GEOx will automatically activate your cooling or heating system to maintain a temperature within a given range. • Heat: GEOx will automatically activate your heating system to keep your temperature above a certain set point.

  • Page 5: Adjusting And Setting Schedules

    20 minute segments (6 minutes on and 14 minutes off, per segment). You can also set a countdown timer for your filter in this menu by highlighting filter, pressing to confirm, and rotating the wheel to select your filter’s remaining lifespan. LUX GEOx OPERATING INSTRUCTIONS...
  • Page 6 If you are not connected to WiFi or if you do not have the LUX app, you can create and change a schedule on the GEOx device. Highlight the “Schedule” menu and select it by pressing...

  • Page 7: Adjusting Relative Humidity Set-Point

    SYSTEM SETTINGS section. Everyday Use: RUNTIME Your GEOx has many output terminals, and gives you a detailed view of how much each of these terminals has run, in Hours and Minutes. This screen shows a cumulative total of runtime and these numbers cannot be reset without performing a full reset of the thermostat to factory defaults (not recommended).

  • Page 8: Custom Settings 5. Network

    Network page The thermostat will begin the WiFi joining process. To connect to a WiFi network, download the LUX Products app from the iOS App Store or the Google Play Store. Launch the LUX app, create an account, and log into the app.

  • Page 9: System

    Select as appropriate for each individual system type. Stage-2 Offset: These settings (if multiple stages are used) determine how much the room temperature can sag from the target set temperature, before the additional stages are applied. LUX GEOx OPERATING INSTRUCTIONS...

  • Page 10: Humidification / De-Humidification

    • De-Humid No Fan: this is for a separate dehumidification device that does not require the system’s blower fan to run during a call for dehumidification. • De-Humid W/Fan: this is for a separate dehumidification device LUX GEOx OPERATING INSTRUCTIONS...
  • Page 11 OUTDOOR TEMPERATURE RH% SETPOINT Less than –20F Between –20F and –10F Between –10F and 0F Between 0F and 10F Between 10F and 20F Greater than 20F LUX GEOx OPERATING INSTRUCTIONS...
  • Page 12 Jumper Wire GEOx RH C U U THIS DIAGRAM IS HUMIDIFIER FOR CONTROL OF 120VAC DE-HUMIDIFIER HUMIDIFIERS AND DE-HUMIDIFIERS THAT CONTAIN R (+) C (-) THEIR OWN 24V 24VAC TRANSFORMER FOR ACTIVATION. GEOx RH C U U LUX GEOx OPERATING INSTRUCTIONS...

  • Page 13: About-Device / About-Network

    NOTE: This item will not be shown if the thermostat is connected online, as time will be set by the online server, including automatic Daylight Savings Time adjustments. When not connected to a WiFi network, the Year, Month, Day, and Clock Time can all be adjusted manually. LUX GEOx OPERATING INSTRUCTIONS...

  • Page 14: Lcd Display Icon Reference

    Heat, Stage-2 WiFi, Running Mid Signal Heat Pump, WiFi, AUX Heat Running Low Signal Cool, Min-Off WiFi, No Platform Protection (Internet Problem) Cool, Stage-1 WiFi, No Network Running (Router Problem) Cool, Stage-2 Locked, Running (Level-1) Locked, (Level-2) LUX GEOx OPERATING INSTRUCTIONS...
  • Page 15 Display, Auto Degrees “F” Change-Over Display, DR Event, Degrees “C” Heat OFF DR Event, Filter Limit Cool Off Reached Value, IAQ Event Percentage (Indoor Air Quality) LUX GEOx OPERATING INSTRUCTIONS...
