Related Manuals for Magnavox MR41806BT
Summary of Contents for Magnavox MR41806BT
- Page 1 1.8 INCH DUAL ALARM CLOCK with Bluetooth ® Wireless Technology OWNER'S MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT. MODEL: MR41806BT Size: 148.5(W) x 210(H)mm (A5)
-
Page 6: Location Of Controls
LOCATION OF CONTROLS (10) (11) (12) CLK/MEM (Clock set/Memory/BT Play-Pause) Button /HR ( Skip-Search Backward/Hour set) Button /MIN ( Skip-Search Forward/Minute set) Button DIMMER Button ALM 2/VOL- ( Alarm 2 set/Volume down) Button ALM 1/VOL+ ( Alarm 1 set/Volume up) Button ALM OFF/SOURCE/ ( Alarm off/Source selection/Power on-off) Button SNOOZE/SLEEP Button... -
Page 7: Power Source
POWER SOURCE Unwind the AC power cord and extend it to its full length. Insert the AC plug into any convenient 120V 60Hz household outlet as the illustrated below: NOTES: This unit is equipped with a polarized AC plug which has one blade wider than the ... -
Page 8: Operation
BATTERY PRECAUTIONS: Follow these precautions when using a battery in this device: Use only the size and type of battery specified. Be sure to follow the correct polarity when installing the battery as indicated in the battery compartment. A reversed battery may cause damage to the device. Do not mix different types of batteries together (e.g. - Page 9 (For details pairing procedures, please refer to the user’s manual of your BT device.). Notes: When the external BT Device searched the unit, our model number “MR41806BT” will appear on the display of external BT Device.
- Page 10 Normal operation after paired： Turn on the BT function of the external BT Device. In Standby mode, press the ALM OFF/SOURCE/ Button to power on the unit . Press the ALM OFF/SOURCE/ Button repeatedly until “bt” appears on the display. The “BT.”...
- Page 11 Adjust the volume to the desired level by pressing the ALM 2/VOL – or ALM 1/ VOL + Button. When finished listening, press and hold the ALM OFF/SOURCE/ Button until “OFF” appears on the display to shut off the radio (standby mode). AM Band: In standby mode, press the ALM OFF/SOURCE/ Button to power on the unit.
- Page 12 Notes: If the backup batteries are not installed when the power goes out presets may be erased. Preset stations can only be removed by storing another station over it. A total of 20 radio stations can be stored (10 AM / 10 FM ). ...
- Page 13 When no longer in use, press and hold the ALM OFF/SOURCE/ Button until “OFF” appear on the display to shut off the unit (standby mode). ALARM: Alarm 1 setting: Make sure the unit is in standby mode before setting. Press and hold the ALM 1/VOL + Button until alarm 1 time appears on the display and blinks.
-
Page 14: Sleep Timer
Shut off alarm: When alarm goes off, press the ALM OFF/SOURCE/ Button to turn off alarm, the alarm will be reset for next day. (The correspondence alarm indicator will keep illuminate). To turn off the alarm completely (not reset for next day). Press the ALM 1/VOL + ... -
Page 15: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Symptom Possible Cause Solution Power Plug from AC Power Cord had Insert the plug to wall outlet having No power not inserted to AC wall outlet. AC 120V~, 60 Hz. Radio Station not tuned properly. Retune the radio station. Noise or sound The location not good for radio Turn or relocation the unit. -
Page 16: General Specifications
GENERAL SPECIFICATIONS Power Source: AC 120V~, 60 Hz, 5W Clock back up: 3V, 2 x AAA size batteries; Not included Audio Power: 1 Watts Impendence of Speakers: 8 Ohm; 2W Radio Band Coverage: AM 520 - 1710 kHz FM 87.5 - 108 MHz BT Version: BT Effective Range: 32 feet in open area... - Page 17 This product has been manufactured by and is sold under the responsibility of Craig Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product. MAGNAVOX and SMART. VERY SMART are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V.
Need help?
Do you have a question about the MR41806BT and is the answer not in the manual?
Questions and answers
HOW TO I PUT IT IN STANDBY MODE
The manual does not explicitly state how to put the Magnavox MR41806BT in standby mode. However, based on the provided instructions, the unit is in standby mode when it is powered off. To turn it off, press and hold the ALM OFF/SOURCE/ button until "OFF" appears on the display, then release the button.
This answer is automatically generated
