Right View And Rear View - Modecom XINO PRO User Manual

Item Description
Wireless LAN / Bluetooth
1 Turn on/off Wireless LAN and Bluetooth device.
Switch
2 DC Jack Connector for the AC-adapter.
3 RJ-45 port Ethernet Network Connection
4 USB port Connector for USB devices.
5 ODD Optical Driver module
6 Microphone port Audio input
Audio output 5.1 channel front-side output.
7 Audio output port Compatible with headphone, speaker or other line
out audio devices.
8 Display Panel Display panel for your notebook PC
9 Power button Power on/off
10 Keyboard Input device
11 TouchPad Function like the mouse
12 Microphone Built-in M icrophone
13 HDD Activity indicator Green light indicates hard disk is in use
Solid light indicates system is on. Flashing light in-
14 Power indicator
dicates system is in standby
Green light indicates wireless connection is ac-
Wireless LAN Activity indi- cessed. It blinks every three seconds when no con-
15
cator nection is available. It is off when the wireless LAN
is not active
16 Number Lock indicator Num Lock is active when lit
17 CAPS Lock indicator Caps Lock is active when lit
18 Environment Button Change environment mode
19 Camera Built-in 1.3 mega pixel camera

Right View and Rear View

XINO PRO notebook
