Page 1: User Manual
BDA6801N/UDA6801N Digital Audio Distribution Amplifier USER MANUAL... - Page 2 Product Information Model: BDA6801N/UDA6801N Digital Audio Distribution Amplifier Version: V010000 Release Date: March 13th, 2009 Company OSEE TECHNOLOGY CO., LTD. Contact Information Address: No.22 Building, No.68 zone, Beiqing Road, Haidian District, Beijing, China 100094 Post Code: Tel: (+86) 010-62434168 Fax: (+86) 010-62434169 http://www.osee-dig.com/...
-
Page 3: Table Of Contents
1.2 Features ............................1 1.3 Module Descriptions ........................2 1.3.1 6800-C2 Frame Back Panel Connector ................2 1.3.2 BDA6801N/UDA6801N Module Back Connector ............2 1.3.3 Signal Flow ........................... 4 Chapter 2 Installation ......................4 2.1 Maximum Power Ratings for Frame .................... 4 2.2 Unpacking the Module ........................ -
Page 4: Chapter 1 Introduction
BDA6801N has one channel balanced digital audio input, and 8 channels balanced digital audio outputs by distributing and amplifying. UDA6801N has one channel unbalanced digital audio input and 8 channels unbalanced digital audio outputs, by distributing and amplifying. Both of them support various alarm indications. -
Page 5: Module Descriptions
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 1.3 Module Descriptions 1.3.1 6800-C2 Frame Back Panel Connector Fig.1-1 Back Connector of 6800-C2 frame 1.3.2 BDA6801N/UDA6801N Module Back Connector Specifications are subject to change without notice. —2—... - Page 6 Tab. 1-2 Description of BDA6801N Back Connector Position Description AES balanced digital audio input AES balanced digital audio output ab. 1-3 Description of UDA6801N Back Connector Position Description AES unbalanced digital audio input AES unbalanced digital audio output AES unbalanced digital audio output...
-
Page 7: Signal Flow
BDA6801N/UDA6801N Operating Manual 1.3.3 Signal Flow Fig. 1-3 Signal Flow of BDA6801N/UDA6801N Chapter 2 Installation 2.1 Maximum Power Ratings for Frame The maximum power ratings that different types of frames can sustain are listed in the Table 2-1 Tab. 2-1 Maximum Power Consumption... -
Page 8: Check The Packing List
Description BDA6801N BDA6801N module (1pc), Back Connector(1pc), other accessories UDA6801N UDA6801N module (1pc), Back Connector(1pc), other accessories 2.3 Installing the Module Static electricity may cause sensitive semiconductor out of order. Avoid installing Caution： or removing the module in the electrostatic-induced environment. -
Page 9: Making The Connections
Please connect AES audio signals based on the types of module input signal and the connectors showed in Fig. 1-2. 2.5 Removing the Module Follow the following steps to remove BDA6801N/UDA6801N module: Open the front part of frame. Open the swivel handle to the full. -
Page 10: Chapter 3 Description Of Led Alarm Indicator
Parameter Connector 3-pin connector (male) Impedance 110Ω AES 3：1992，AES3id：1995， Standard SMPTE276M Rise and fall time 5 to 30ns Table 4-2 Unbalanced Digital AES Audio Input Specifications (applicable to UDA6801N) Item Parameter Connector BNC（IEC 169-8） Impedance 75Ω AES 3：1992，AES3id：1995， Standard SMPTE276M... -
Page 11: Digital Aes Audio Outputs
5 to 30 ns (10% to 90% of amplitude) Impedance 110Ω+/- 20% (0.1 to 6 MHz) CMR Ratio >30 dB below output signal (0 to 6 MHz) Table 4-4 Unbalanced Digital AES Audio Output Specifications (applicable to UDA6801N) Item Parameter Connector BNC（IEC 169-8）... -
Page 12: Chapter 6 Warranty For Osee Product
This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty. If there is no proof of purchase provided with a warranty claim, osee reserves the right not to honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer.
