[Stop] regardless of what state, select "Close" button, the channel will not output an
alarm signal
3.5.6

PTZ control

*PTZ control is a little different between hybrid mode & full digital mode:
Digital channel – the digital channel need link PTZ, the remote device should connect
with PTZ and with protocol correctly set also.
The functions include: PTZ direction control, step, zoom, focus, iris, and setup
operation, patrol between spots, trail patrol, boundary scan, assistant switch, light switch,
level rotation and so on.
Note:
1. Decoder A (B) line connects with NVR A (B) line. The connection is right.
2. [main menu]> > [system] > [PTZ Config] to set the PTZ parameters.
3. The PTZ functions are decided by the PTZ protocols.
Figure 3.13 PTZ settings
【Speed】Set the PTZ rotation range. Default range: 1 ~ 8.
【Zoom】Click
/ button to adjust the zoom multiple of the camera.
【Preset】Click
/ button calls the preset points, PTZ automatically turns to
the setting position.
【Hide】Current interface will be temporarily hidden after click it.
【Direction control】Control the PTZ rotation. 8 directions control is supportive. (4
directions in Front panel is supportive)
【Advanced】Full-screen show channel image. Left press mouse and control PTZ to
rotate orientation. Left press mouse and then rotate the mouse to adjust the zoom
multiple of the camera.
【Page switch】Switch between different pages.
【Preset】
1.Increase the preset point
，
By the arrow keys to adjust the good Yuntai location，Enter a number in
