Switch 1100 — Rear
View Detail
Unit Information
Label

Power Socket

Redundant Power
System Socket

Console Port

Figure 2 Switch 1100 — Rear view
This label shows the following:
The 3Com product name of the Switch
The 3Com 3C number of the Switch
The unique MAC address (Ethernet address) of the Switch
The serial number of the Switch
You may need this information for fault reporting purposes.
The Switch automatically adjusts its power setting to any supply voltage
in the range 90–240V A.C.
To protect against internal power supply failure, you can use this socket
to connect a SuperStack II Advanced Redundant Power System (RPS) to
the Switch. See "Connecting a Redundant Power System"
The console port allows you to connect a terminal and perform remote or
local out-of-band management. The console port uses standard null
modem cable and is set to auto-baud, 8 data bits, no parity and 1 stop
bit.
Switch 1100 — Rear View Detail 15
on page 29.
