1. Technical Specifications

EVO
WW (wood work)
EVO
SM
(saw mill)
Scanning depth
Min. wood thickness
Density range
Timber group
Resolution
Measuring range
Temperature range
Operating temperature
Storage temperature
Temp. Compensation
Menu language
Power supply
Aut. Shut off function
Power input
Display
Dimensions
Weight incl. batteries
Protection class
Scope of supply
* see page 19 Exceedance of measuring range
Version October 2016, Version 1.0
MERLIN Technology GmbH, Austria
EVO WW: 20 mm
EVO SM: 40 mm
EVO WW:13 mm
EVO SM: 25 mm
175 - 1075 kg/m³
1 - 21
0,1 % humidity; 0,5 °C/°F
2 - 30% wood humidity* (test area to max. 99%)
-10 °C to +60 °C (0,5 °C), 14 to 140 °F (0,5 °F)
0 °C to 40 °C, 32 to 104 °F
-20 °C to +60 °C, -4 to 140 °F without batteries
automatically
German, English, French, Spanish, Italian,
Portuguese, Czech, Russian
4 x 1,5 V AAA Alkaline batteries
after approx. 3 minutes
35 mA (incl. display lightning)
128 x 64 matrix display
124 mm x 71 mm x 30 mm
175 g
IP40
EVO WW/SM, Soft case, batteries, user manual
