Laser Pegs 1280 World Of Speed Model Instructions

1280 Please read this manual before you begin!
Failure to follow this manual's instructions may
result in damage to the Triangle Power Base,
WORLD OF SPEED
AC Adapter and/or Laser Pegs®. Not adhering to
For Boys And Girls
these instructions will void the manufacturer's
Ages 5 And Up warranty. The packaging must be kept because
it contains important information.
12 Models+
WARNING:
ANY CREATION YOU CAN BUILD CHOKING HAZARD
- Small parts.
LIGHTED Not for children under 3 yrs.
Do not submerge in water.
CONSTRUCTION SET INCLUDES:
• 14 Laser Pegs®
• 104 Construction parts
• Triangle Power Base
• Laser Pegs® Peg Cord
• Instruction Manual
Construction Compatible
Requires 3-AA Batteries
Compatible with other construction kits
Batteries NOT
EN71, RoHS COMPLIANT
Included
This product complies to
all safety requirements
of ASTM F 963
MODEL INSTRUCTIONS
All additional model instructions can
be downloaded at www.LaserPegs.com
Laser Pegs® Parts List
There is No LED In The 90 Degree Peg
x1
x1 x3
x4
x1
SQUARE
M-M PEG
SQUARE STRAIGHT
Y PEG
WHEEL PEG
PEG T PEG
Each Laser Peg® is color coded on the circuit board inside
Color
each shape. There is No LED In The 90 Degree Peg.
Code
Laser Pegs ® Stackable
Laser Pegs
Laser Pegs
® link that
Triangle Power
Peg Cord
allows you to connect to
Base
other construction kits.
Construction Parts List
x12
x4
x4
x16 x2
x2
x4
x4
x12
x3
x3
x4
x4
x2
x2
x2 x3
x4
x1 x1
x2
x3
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs®Ventures
LLC. 8304 Consumer Ct Sarasota FL. 34240. Contact: Support@LaserPegs.com
Connecting Pegs
To construct with Laser Pegs®, slide two pieces together to form a
connection. Slide each piece on and off smoothly. The 90° Pegs are
essential to construction but they DO NOT LIGHT UP.
Push Red
Red
Power Button
Power Button
to turn on/off
Push Red Power Button to
cycle through 3 different
light settings.
AC Adapter
OFF/ON/FLASH
Connection
Replacing Batteries
1. Remove the three (3) screws.
2. Place three (3) AA batteries in the correct
position - as displayed inside the Triangle
Power Base.
3. Reassemble the Triangle Power Base.
4. Replace the three (3) screws.
5. Push RED Power Button to turn on!
6. Do not mix old and new batteries.
7. Do not mix alkaline, standard (carbon-
x2 zinc), or rechargeable (nickel-cadmium,
NiMH) batteries!
8. Exhausted batteries are to be removed
from the Triangle Power Base.
90° PEG
9. Never connect more than 200 Laser Pegs®
10. Non-rechargeable batteries are not to be
recharged.
11. Rechargeable batteries are only to be
recharged under adult supervision.
12. Rechargeable batteries are to be removed
x2
from the toy before being recharged.
STACKABLE 13. Batteries are to be inserted with the
correct polarity.
14. The supply terminals are not to be short-
circuited.
Using an
AC Adapt
er
Remove all batteries
from Laser Pegs® power
®
base before using the
5-volt AC adapter.
*To avoid short-circuits, keep metal objects and
other unauthorized materials from obstructing
x2
the peg holes.
The AC adapter and the Triangle Power Base are to be regularly examined for
x2
damage to the cord, plug, enclosure and other parts, and in the event of such
damage, they must not be used until the damage has been repaired.
x2
WARNING! Each Laser Peg® draws current from the batteries. Therefore, the more
pegs you use, the quicker you will deplete your battery power! As the power
x2
weakens, the current will slowly fail and some Laser Pegs® will illuminate (typically
the reds and yellows) and some won't. When the Laser Pegs® dim the Laser Pegs®
are not broken, they just need stronger batteries or an AC Adapter.
You have 3 simple options...
x2 1. Use a 5-volt AC Adapter –available from www.LaserPegs.com
2. Change the batteries.
3. Use high quality batteries. They will last a little longer, but they will still deplete
rapidly the more laser pegs you connect!
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs®Ventures
LLC. 8304 Consumer Ct Sarasota FL. 34240. Contact: Support@LaserPegs.com
BAJA TROPHY TRUCK: - Able to exceed 150 miles per hour, these desert trucks are the fastest
off-road racing vehicles in the world.
BAJA TROPHY TRUCK
Model
Difficulty
Level
Peg Holes
A
Add 3-AA Batteries
STEP
1
3-AA Batteries
When using an AC
Adapter, NEVER
place the adapter
plug into the Tri-
angle Power Base
top peg holes.
Never connect more than 200
STEP
Laser Pegs® when using a 5-volt 2
(2000mA) AC Adapter.
STEP
3
B
STEP
4
STEP
5
www.LaserPegs.com
Copyright 2013© All Rights Reserved Global & Multiple Patents Pending.
US Patent #7,731,558
