Laser Pegs 1290 Instruction Manual

Please read this manual before you begin!
1290
Failure to follow this manual's instructions may
result in damage to the Triangle Power Base, AC
HEAVY DUTY
Adapter and/or Laser Pegs®. Not adhering to
these instructions will void the manufacturer's
For Boys And Girls
warranty. The packaging must be kept because
Ages 5 And Up
it contains important information.
24 Models+
WARNING:
ANY CREATION YOU CAN BUILD CHOKING HAZARD
- Small parts.
Not for children under 3 yrs.
LIGHTED
Do not submerge in water.
CONSTRUCTION SET INCLUDES:
• 29 Laser Pegs®
• 94 Construction parts
• Laser Pegs® Peg Cord
• Triangle Power Base
• Instruction Manual
Construction Compatible
Requires 3-AA Batteries
Compatible with other construction kits
Batteries NOT
EN71, RoHS COMPLIANT
Included
This product complies to
all safety requirements
of ASTM F 963
MODEL INSTRUCTIONS
All additional model instructions can
be downloaded at www.LaserPegs.com
Laser Pegs® Parts List
x4
x2
There is No LED In The 90 Degree Peg
90° PEG
x1
x2 x2 x1
x3
SQUARE x2
PEG
x2
TRIANGLE PEG
STRAIGHT TRUSS PEG
45° PEG
STRAIGHT
SQUARE
PEG
T PEG
M-M PEG
Y PEG
Each Laser Peg® is color coded on the circuit board inside
Color
Code each shape. There is No LED In The 90 Degree Peg.
Laser Pegs ® Stackable
Laser Pegs
Laser Pegs ® link that
Triangle Power
Peg Cord
allows you to connect to
Base
other construction kits.
Construction Parts List
x8
x12
x4
x4
x4
x12 x4
x4
x4
x4
x2
x1
x2 x5
x2 x1 x5
x2
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs®Ventures
LLC. 8304 Consumer Ct Sarasota FL. 34240. Contact: Support@LaserPegs.com
Connecting Pegs
To construct with Laser Pegs®, slide two pieces together to form a
connection. Slide each piece on and off smoothly. The 90° Pegs are
essential to construction but they DO NOT LIGHT UP.
Push Red
Red
Power Button
Power Button
to turn on/off
Push Red Power Button to
cycle through 3 different
light settings.
AC Adapter
OFF/ON/FLASH
Connection
Replacing Batteries
1. Remove the three (3) screws.
2. Place three (3) AA batteries in the correct
position - as displayed inside the Triangle
Power Base.
3. Reassemble the Triangle Power Base.
4. Replace the three (3) screws.
5. Push RED Power Button to turn on!
6. Do not mix old and new batteries.
x6 7. Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium,
NiMH) batteries!
8. Exhausted batteries are to be removed
from the Triangle Power Base.
9. Never connect more than 200 Laser Pegs®
WHEEL PEG
10. Non-rechargeable batteries are not to be
recharged.
11. Rechargeable batteries are only to be
recharged under adult supervision.
12. Rechargeable batteries are to be removed
x4
from the toy before being recharged.
STACKABLE 13. Batteries are to be inserted with the
correct polarity.
14. The supply terminals are not to be short-
circuited.
Using an
AC Adapt
er
Remove all batteries
from Laser Pegs® power
® base before using the
5-volt AC adapter.
*To avoid short-circuits, keep metal objects and
other unauthorized materials from obstructing
x2
the peg holes.
The AC adapter and the Triangle Power Base are to be regularly examined for
x2
damage to the cord, plug, enclosure and other parts, and in the event of such
x2
damage, they must not be used until the damage has been repaired.
x2
WARNING! Each Laser Peg® draws current from the batteries. Therefore, the more
pegs you use, the quicker you will deplete your battery power! As the power
x4
weakens, the current will slowly fail and some Laser Pegs® will illuminate (typically
the reds and yellows) and some won't. When the Laser Pegs® dim the Laser Pegs®
are not broken, they just need stronger batteries or an AC Adapter.
x2
You have 3 simple options...
1. Use a 5-volt AC Adapter –available from www.LaserPegs.com
2. Change the batteries.
3. Use high quality batteries. They will last a little longer, but they will still deplete
rapidly the more laser pegs you connect!
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs®Ventures
LLC. 8304 Consumer Ct Sarasota FL. 34240. Contact: Support@LaserPegs.com
BULLDOZER - With a weight of over 183 tons, the ACCO Super Bulldozer is the largest
bulldozer ever built.
Peg Holes
STEP
1
Add 3-AA Batteries
3-AA Batteries
STEP
2
When using an AC
Adapter, NEVER
place the adapter
plug into the Tri-
angle Power Base
top peg holes.
Never connect more than 200
Laser Pegs® when using a 5-volt
(2000mA) AC Adapter.
BULLDOZER
Model
Difficulty
Level
