Takenaka System FC1500FCL Instruction Manual

1.45mega pixel progressive scan monochrome camera

Advertisement

Quick Links

Instruction Manual
1.45Mega pixel Progressive Scan Monochrome Camera
● We greatly appreciate your confidence choosing our TAKEX CCD Video Camera.
● Please read this manual and the attached guarantee certificate carefully and manage the camera properly.
Keep this manual at hand and reread it whenever you are uncertain about the operation.
Video Camera
FC1500FCL

Table of Contents

......................................................... 3
......................................................... 3
......................................................... 4
......................................................... 6
......................................................... 8
......................................................... 10
......................................................... 13
......................................................... 16
.........................................................19
......................................................... 19
......................................................... 20
TAKENAKA SYSTEM CO., LTD.
Document No. K11414
FC1500FCL Instruction Manual (8
- 1 -
K11414;1/20
th
Version)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC1500FCL and is the answer not in the manual?

Questions and answers

Summary of Contents for Takenaka System FC1500FCL

  • Page 1: Table Of Contents

    6. How to change settings ………………………………………………… 10 7. Serial communication ………………………………………………… 13 8. Timing chart ………………………………………………… 16 9. Usage note …………………………………………………19 10. Specifications ………………………………………………… 19 11. Dimensions ………………………………………………… 20 TAKENAKA SYSTEM CO., LTD. Document No. K11414 FC1500FCL Instruction Manual (8 Version) - 1 -...
  • Page 2 K11414;2/20 [Revision history] Version Revised contents Articles Date Remarks Document No. version Initial version K03613 version Error correction K04308 Camera Link,bit assignment table version Error correction Specification table K04609 Rear panel diagram version Amendment HD,VD driving circuit, Descriptions of external sync, Horizontal timing chart etc.
  • Page 3: Features

    K11414;3/20 1. Features Progressive scan camera incorporated with 1.45 megapixel, 2/3”-size CCD image sensor. ● 10bit (2 tap) Video signal is output in progressive scanning (non-interlaced scanning) format, complying with Camera ● Link (Base configuration). A full frame shutter image can be obtained at a rate of 30 frames per second. ●...
  • Page 4: Description Of Each Component

    K11414;4/20 3. Description of Each Component Camera link connector Camera Link (3-1) Description of rear panel of camera Shutter switch Panel to set up operation mode, electronic shutter speed and other Mode switch MODE EXP. parameters and to connect each output connector POWER (3-2) Camera connector (HRS HR10A-10R-12PB) The pin arrangement of the camera cable connector (12 pins) and...
  • Page 5 K11414;5/20 [Table of Camera Link bit assignment] (showing correspondence relation between before and after encoding) Camera Link port Camera signal Remark (Node name) name Strobe Pixel clock LVAL Horizontal synchronous timing FVAL Vertical synchronous timing DVAL (Fixed to H level) Spare (Fixed to H level) PORTA0 / PORTC0...
  • Page 6: How To Operate

    K11414;6/20 4. How to Operate (4-1) Connection method ● Connection Refer to the connection example between the camera and peripheral devices (Fig. 4-1). (1) Remove the cover of the lens attachment section F C 1 5 0 0 F C L and attach a lens (option).
  • Page 7 K11414;7/20 ● Recommended timing of asynchronous shutter trigger signal (Vinit signal) for preset shutter/pulse width control Tvinit For the case of the pulse width control exposure mode, numeric value of the L level interval of the input Vinit pulse (shown as Vinit Tvinit in the figure) is retrieved in synchronization with the HD trailing edge inside the camera, and the integer multiple number...
  • Page 8: Various Settings

    K11414;8/20 Electronic shutter operation mode 5. Various Settings Shutter switch = 0 Shutter switch = 1 to 9 (5-1) Operation mode No shutter Electronic shutter operation operation ● Electronic shutter operation mode Shutter mode Continuous shutter Asynchronous shutter No shutter/continuous/asynchronous Shutter speed category Low speed High speed/low speed/pulse width control...
  • Page 9 K11414;9/20 (5-3) Level setting Signal level The level setting is mostly divided into the 1023 following two groups: (Before setting adjustment) Image signal ● Gain setting This is to set the gain (amplification ratio) of the preamplifier between the CCD imaging device inside the camera to A/D converter.
  • Page 10: How To Change Settings

    (Note) The items marked with <* C> in the table are automatically stored in EEPROM whenever they are changed. (!) Clock phase changing function is omitted as digital output of FC1500FCL is dependent on Camera Link device. - 10 -...
  • Page 11 K11414;11/20 (6-3) Setting of program page The setting operations for the program pages are roughly divided into 2 groups: save (writing the current setting into the program page) and load (reading out the setting that was previously saved in the program page as the current setting). More specifically, “save”...
  • Page 12 K11414;12/20 (6-4) Typical setting procedure (Example 1) This is the procedure for setting the gain for the START asynchronous shutter operation (1/250 sec.). Turn on power. [Explanation] Be ready for switching between The left example of the setting procedure is for using the Set mode switch to “5”.
  • Page 13: Serial Communication

    Return by camera: STX: ACK: “R”: “Takenaka SYS.FC1500FCL V1.00”: ETX * The underlined values show the control program version number of the camera and a file name. These values and the number of characters vary by program version. Use when confirming the communication mode of the camera and obtaining internal information of the camera.
  • Page 14 K11414;14/20 4) Shutter mode report Transmission from host: STX: “R”: “S”: ETX Return by camera: STX: ACK: “R”: “ ” * : “ ” * : “ ” * : Exposure time * : ETX □ □ □ 1 to 3 : Refer to (4) command “S”...
  • Page 15 K11414;15/20 (5) Command “A” Function: Command for setting analog image signal Transmission from host: STX: “A”: (SETUP setting value): (WC setting value): “.”: ETX Return by camera: STX: ACK: ETX (transaction completion), or STX: NAK: ETX (transaction rejection) 2 digit ASCII codes in the hexadecimal system are used for the data setting values of SETUP and WC. Example) If level 128 (decimal) is set: “80”...
  • Page 16: Timing Chart

    10 bit x 2 tap output is employed for FC1500FCL. Therefore, there is no compatibility with the conventional parallel type camera FC1500F . and so dedicated setting files are required.
  • Page 17 K11414;17/20 ● Vertical timing: Continuous shutter/No shutter 1ve rti cal per iod ( 1 V) = 1fra me tim e 1 06 8 ;Nor mal sca n 9 53 4 ;Par tial sc an VD (I nt er n al v e rt ic a l s yn c s ig na l )...
  • Page 18 K11414;18/20 ● Vertical timing: Pulse width control/Asynchronous shutter Vin it 1 2 3 m HD ( I nt e r na l h or i z on t a l s yn c si g n a l ) m SG...
  • Page 19: Usage Note

    K11414;19/20 9. Notes ● Do not disassemble this equipment or alter the internal circuits. Accidents such as a fire may be caused by the heat generation associated with failure in operation. ● Refrain from connecting or disconnecting cables and connectors while power is being supplied, otherwise troubles may be caused.
  • Page 20: Dimensions

    C a m e r a L i n k EX P. M OD E PO WE R 2×2-M3 depth 6 (Right and left sides) 4-M3 depth5 1 9.75 2×2-M3 depth 8 (Same as top side) 2-M6 depth7 18.5 1/4”-20UNC depth 7 FC1500FCL external views - 20 -...
