Summary of Contents for Hitachi DV-P325U
-
Page 1: Dvd Player
No. 9202E DV-P325U DV-P323U SERVICE MANUAL OPEN / CLOSE POWER / STANDBY SURROUND SUB TITLE AUDIO SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT DVD PLAYER February 2002 Digital Media Products Division, Tokai... -
Page 2: Table Of Contents
CONTENTS SPECIFICATIONS ....... .1-1-1 COMPARISON OF MODELS ..... . .1-2-1 LASER BEAM SAFETY PRECAUTIONS . -
Page 3: Specifications
SPECIFICATIONS Manufatured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works. (1992-1997 Dolby Laboratories, Inc. All rights reserved.) "DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems Inc. 1-1-1... -
Page 4: Comparison Of Models
Picture Control ← Progressive Out Audio Audio D/A Converter 96kHz / 24bit 192kHz / 24bit O / O (DV-P325U) Digital Audio Out Optical / Coaxial O / O --- / O (DV-P323U) ← Dolby Digital 5.1 ch Decode ← DTS Digital Out... - Page 5 Features O (DV-P315U) Disc Navigation --- (DV-P313U) ← DVD Zoom x2 / x4 / x16 O / O / --- Program and Random Play of DVD / VCD O / O ← A-B Repeat ← Repeat ← Last Play ← Closed Caption for NTSC DVD ←...
-
Page 6: Laser Beam Safety Precautions
LASER BEAM SAFETY PRECAUTIONS This DVD player uses a pickup that emits a laser beam. Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin. The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30cm away from the pickup lens when the diode is turned on. -
Page 7: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS Product Safety Notice I. Also check areas surrounding repaired locations. J. Be careful that foreign objects (screws, solder Some electrical and mechanical parts have special droplets, etc.) do not remain inside the set. safety-related characteristics which are often not evi- K. -
Page 8: Safety Check After Servicing
Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts, Chassis or Secondary Conductor and wires have been returned to their original posi- tions. Afterwards, do the following tests and confirm the specified values to verify compliance with safety Primary Circuit Terminals standards. -
Page 9: Standard Notes For Servicing
STANDARD NOTES FOR SERVICING Circuit Board Indications How to Remove / Install Flat Pack-IC a. The output pin of the 3 pin Regulator ICs is indi- 1. Removal cated as shown. With Hot-Air Flat Pack-IC Desoldering Machine:. (1) Prepare the hot-air flat pack-IC desoldering Top View Bottom View machine, then apply hot air to the Flat Pack-IC... - Page 10 With Soldering Iron: (4) Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply (1) Using desoldering braid, remove the solder from all soldering iron to center of the flat pack-IC and heat pins of the flat pack-IC.
-
Page 11: Instructions For Handling Semi-Conductors
2. Installation Instructions for Handling Semi-conductors (1) Using desoldering braid, remove the solder from the foil of each pin of the flat pack-IC on the CBA Electrostatic breakdown of the semi-conductors may so you can install a replacement flat pack-IC more occur due to a potential difference caused by electro- easily. -
Page 12: Operating Controls And Functions
FRONT PANEL 3 4 5 6 7 OPEN / CLOSE POWER / STANDBY SURROUND SUB TITLE AUDIO DV-P325U only REMOTE CONTROL 5. STOP Button DV-P325U only 6. SKIP DOWN/REV Button Plays back from the beginning of the current SEARCH OPEN... -
Page 13: Displays During Operation
DISPLAYS DURING DISPLAY OPERATION Power on No disc inserted Tray open Tray closed Loading the Disc Power off LOADING THE BATTERIES 1. Open the battery compartment cover. 2. Insert two AA batteries, with each one oriented correctly. 3. Close the cover. Notes Do not mix alkaline and manganese batteries. - Page 14 DIGITAL ANALOG COMPONENT S-VIDEO AUDIO OUT AUDIO OUT VIDEO OUT DV-P325U only VIDEO OPTICAL COAXIAL 1. DIGITAL AUDIO OUT JACKS: Use either an optical or coaxial digital cable to connect to a comcompatible Dolby Digital receiber. Use to connect to a Dolby Digital decoder or DTS decoder.
-
Page 15: Cabinet Disassembly Instructions
FFC cable (CN101) from 4(S-4), it. If you disconnect the FFC cable (CN101), the (S-5) --- DV-P325U only laser diode of pickup will be destroyed. (Fig. 5) AV CBA 4(S-6),*2(L-4), 2-3. Disconnect Connector (CN401). Remove three *CN1001, *CN1601 Screws (S-3) and lift the DVD Mecha. - Page 16 View for A DVD Mecha (L-3) Fig. D2 Bottom View Fig. D5 [5] AV CBA (S-2) (S-6) [3] Function CBA (S-6) CN1601 (S-7) (S-4) Jog Shuttle Key CN1001 Fig. D3 (S-5) (L-4) [6] DVD Main CBA Unit DV-P325U only Fig. D6 1-7-2...
- Page 17 (S-8) [7] Rear Panel Fig. D7 HOW TO MANUAL EJECT 1. Remove the Top Case. 2. Insert the eject-bar (length = approximately 80 mm, diameter = approximately 3 mm) into the manual eject hole on the DVD Mecha. Then, press it until the tray is ejected. Top Case Tray Manual...
-
Page 18: Rom Renewal Mode
ROM RENEWAL MODE 1. Turn the power on and remove the disc on the tray. 2. To put the DVD player into version up mode, press [9], [8], [7], [6], and [SEARCH MODE] buttons on the remote control unit in that order. The tray will open automatically. -
Page 19: Troubleshooting
TROUBLESHOOTING FLOW CHART NO.1 The power cannot be turned on.(1) Is the fuse normal? Replace the fuse. See FLOW CHART No.3 <The fuse blows out.> Is normal state restored when once unplugged Check for lead or shor-circuiting of primary power cord is plugged again after several seconds. circuit component? (Q1001, Q1003, D1001, D1002, D1004, D1005, D1011, T1001, C1003, C1005, etc.) - Page 20 FLOW CHART NO.4 When the output voltage fluctuates. Does the secondary side photo coupler circuit Check the circuit and replace the parts. operate normally? (IC1001, IC1006, D1048, D1015, etc.) Does the primary side photo coupler circuit Check the circuit and replace the parts. operate normally? (IC1001, IC1012, D1024, etc.) Replace IC1001.
- Page 21 FLOW CHART NO.8 No operation is possible from the infrared remote control. Replace the remoter control receiver or replace the Operation is possible from the DVD, but no remoter control transmitter is necessary. operation is possible from the infrared remote control? Is 5V voltage supplied to the pin(3) terminal of Check EV 5V line.
- Page 22 FLOW CHART NO.10 PON 5V is not outputted. (PON 12V is possible.) Check the AT 5V line. Is 5V voltage supplied at collector of Q1004? Check for load circuit short-circuiting or leak. Is voltage of 5V sent out from the collector of Q1004? Check the Q1004 periphery circuit.
- Page 23 FLOW CHART NO.13 PON 1.8V is not outputted. (PC 3.3V(1), (2) is possible) Is 5V voltage supplied at pin(1) of IC1002? Check the secondary circuit, AT 5V line. Check for load circuit short-circuiting of leak. Is voltage of 1.8V sent out from the pin(2) of IC1002? Check the IC1002 periphery circuit.
- Page 24 FLOW CHART NO.17 The [No Disc] indication. (In case focus servo does not function.) Is the focus control signal outputted to the pin(115) Check the periphery circuit of pins(57, 78, 88, 99, of IC201? 109, 116, 125, 143, 156, 162) of IC201 and power source.
- Page 25 FLOW CHART NO.20 Picture do not operate normally. Set the disc on the disc tray. Check the main unit. (IC601 periphery circuit.) Are the video signals outputted to each pins of main unit connector CN701? CN701 7PIN CVBS CN701 5PIN CN701 6PIN Check the line between each pins of main unit Are the video signals shown above input into each...
- Page 26 FLOW CHART NO.21 Picture do not operate normally. Set the disc on the disc tray. Check the main unit. (IC601 periphery circuit.) Are the analog audio interface signals outputted to each pins of main unit connector CN701? CN701 13PIN FL CN701 15PIN FR Are the analog audio interface signals inputted Check the line between each pins of main unit...
-
Page 27: Block Diagrams
BLOCK DIAGRAMS System Control Block Diagram AV CBA IC2001 IC601 (FRONT PANEL CONTROL) (DVD HOST PROCESSOR) FL2001 CN501 CN1001 IC301 TFWD (FRONT END PROCESSOR) VFD-STB FP-STB FP-STB TREV GRID FP-DIN VFD-DIN FP-DIN VFD-DOUT FP-DOUT FP-DOUT TFWD TOUT TFWD VFD-CLK FP-CLK FP-CLK TREV REMOTE... -
Page 28: System Control Block Diagram
RF Signal Process/Servo Block Diagram DATA(VIDEO/AUDIO) SIGNAL FOCUS SERVO SIGNAL TRACKING SERVO SIGNAL SLIDE SERVO SIGNAL DISK SERVO SIGNAL IC101 (RF SIGNAL PROCESS) PICK-UP UNIT DVD MAIN CBA UNIT HOLD TESTSG CN101 FROM/TO DVD SIGNAL PROCESS BLOCK DIAGRAM NARF C 10 DETECTOR BDO DET INPUT... -
Page 29: Dvd Signal Process Block Diagram
DVD Signal Process Block Diagram DATA(VIDEO/AUDIO) SIGNAL DVD MAIN CBA UNIT IC201 (DVD SIGNAL PROCESS) PARA0 PARA1 PARA2 DATA VIDEO/AUDIO PARA3 SLICER PARA0-PARA7 TO VIDEO DEMODULATOR FROM/TO RF SIGNAL INTERFACE NARF PARA4 BLOCK DIAGRAM PROCESS/SERVO PARA5 BLOCK DIAGRAM TESTSG PARA6 PARA7 MEMORY MANAGER... -
Page 30: Video Block Diagram
Video Block Diagram DATA(VIDEO) SIGNAL DATA(AUDIO) SIGNAL VIDEO SIGNAL DATA(VIDEO/AUDIO) SIGNAL IC601 (DVD HOST PROCESSOR) CACHE SUBSYSTEM FROM DVD PARA0 INTERNAL CENTRAL FRONT-END PCM-BCK SIGNAL PROCESS PARA0-PARA7 PERIPHERALS COMMAND & LINK PCM-DATA0 BLOCK DIAGRAM PARA7 PORTS PORT INTERFACE PCM-SCLK TO AUDIO AUDIO BLOCK PCM-LRCLK... -
Page 31: Audio Block Diagram
Audio Block Diagram DATA(AUDIO) SIGNAL AUDIO SIGNAL DV-P325U only IC1204 FIBER OPTIC TRANS MODULE JK1202 CN701 CN1601 Q1351 SPDIF DIGITAL AUDIO OUT IC801 (AUDIO DAC) IC1201 (AMP) SPDIF CN701 CN1601 4X/8X L-CH PCM-BCK AUDIO-L ENPHANCED LPF+AMP AUDIO-L OVERSAMPLING PCM-DATA0 SERIAL... -
Page 32: Power Supply Block Diagram
Power Supply Block Diagram CAUTION ! CAUTION Switching power supply circuit is used in this unit. FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, NOTE : If Main Fuse (F1001) is blown, check to see that all components in the REPLACE ONLY WITH THE SAME TYPE FUSE. The voltage for parts in hot circuit is measured using power supply circuit are not defective before you connect the AC plug to ATTENTION : POUR UNE PROTECTION CONTINUE LES RISQES... -
Page 33: Test Points
SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS Standard Notes Notes: WARNING 1. Do not use the part number shown on these draw- ings for ordering. The correct part number is Many electrical and mechanical parts in this chassis shown in the parts list, and may be slightly different have special characteristics. - Page 34 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQES D'INCELE N'UTILISER QUE DES FUSIBLE DE MEMO TYPE.
-
Page 35: Dvd Main 1/4 Schematic Diagram
DVD Main 1/4 Schematic Diagram 1-11-3... -
Page 36: Dvd Main 2/4 Schematic Diagram
DVD Main 2/4 Schematic Diagram 1-11-4... -
Page 37: Dvd Main 3/4 Schematic Diagram
DVD Main 3/4 Schematic Diagram 1-11-5... -
Page 38: Dvd Main 4/4 Schematic Diagram
DVD Main 4/4 Schematic Diagram 1-11-6... -
Page 39: Av 1/3 Schematic Diagram
AV 1/3 Schematic Diagram CAUTION FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, CAUTION ! NOTE : REPLACE ONLY WITH THE SAME TYPE FUSE. Fixed voltage power supply circuit is used in this unit. The voltage for parts in hot circuit is measured ATTENTION : POUR UNE PROTECTION CONTINUE LES RISQES If Main Fuse (F1001) is blown, check to see that all components in the power supply circuit using hot GND as a common terminal. -
Page 40: Av 2/3 Schematic Diagram
AV 2/3 Schematic Diagram 1-11-8... - Page 41 WAVEFORMS Pin 5 of CN1601 Pin 15 of CN1601 0.2V 20usec 0.5msec VIDEO-Y AUDIO-R Pin 7 of CN1601 Pin 18 of CN1601 VIDEO-CVBS 0.5V 20usec SPDIF 0.2usec Pin 9 of CN1601 NOTE: Input CD: 1kHz PLAY (WF4~WF6) DVD: POWER ON (STOP) MODE (WF1~WF3) VIDEO-C 0.2V...
-
Page 42: Av 3/3, Function & Switch Schematic Diagram
AV 3/3, Function & Switch Schematic Diagram FL2001 MATRIX CHART STANDBY REPEAT STANDBY TITLE CHP. TRK. REPEAT TITLE CHP. TRK. 1-11-10... -
Page 43: Av Cba Top View
AV CBA Top View CAUTION ! Switching power supply circuit is used in this unit. If Main Fuse (F1001) is blown, check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. -
Page 44: Av Cba Bottom View
AV CBA Bottom View CAUTION ! Switching power supply circuit is used in this unit. If Main Fuse (F1001) is blown, check to see that all components in the PIN 5 OF PIN 7 OF PIN 9 OF PIN 13 OF PIN 15 OF PIN 18 OF power supply circuit are not defective before you connect the AC plug to the... -
Page 45: Function Cba Top View
Function CBA Top View Switch CBA Top View Switch CBA Bottom View Function CBA Bottom View 1-11-13... -
Page 46: Wiring Diagram
WIRING DIAGRAM VIDEO-Y VIDEO-U VIDEO-V VIDEO AUDIO AUDIO DIGITAL S-VIDEO OPTICAL AC CORD OUT(L) OUT(R) AUDIO OUT AUDIO OUT DV-P325U only CN2002 W2201 CN2201 KEY-5 KEY-6 KEY-7 AV CBA KEY-8 FUNCTION CBA KEY-4 KEY-3 CN1001 CN1601 KEY-1 KEY-2 JP1003 WJ1003... -
Page 47: System Control Timing Charts
SYSTEM CONTROL TIMING CHARTS Tray close ~ Play / Play ~ Tray open Eject key on Eject key on Tray close Play Tray open Disc Rotation LSW2 LSW1 4.4s (TL123) 700ms 2.0s 1.2s ( TP122 ) 1.7s ( TL122 ) 1-13-1... -
Page 48: Ic Pin Function Descriptions
IC PIN FUNCTION DESCRIPTIONS IC2001 [ PT6315-S (-TP) ] Signal In/Out Name Function Name Clock Input Serial Interface Strobe Key Data 1 Input Key Data 2 Input Power Supply Segment Output / Key a / Key-1 Souce-1 Segment Output / Key b / Key-2 Souce-2 Segment Output / Key... -
Page 49: Lead Identifications
LEAD IDENTIFICATIONS 2SK3374 2SC2785 (H) 2SA1015-Y (TPE2) KTC3199 (GR) KTA1266 (Y) KRA110M 2SC1815-GR (TPE2) KTA1273 (Y) 2SA966 (Y) KRC110M-AT 2SC2236-Y-TPE6,C BA1L3Z-T BA1L3Z (P) KTC3205 (Y) G D S E C B E C B KIA431-AT NJM4558D PT6315-S PQ018EF01SZ AN1431-(NSC) KIA4558P PT6315-S(-TP) R A K 0C-0805T-002... -
Page 50: Exploded Views
Some Ref. Numbers are not in sequence. 2L021 2L021 2L021 2L031 W1601 JK1401 AV CBA JK1403 JK1201 DVD Main W1001 DV-P325U only CBA Unit 2L031 IC1204 2L051 F1001 2L031 AC1001 Function 2L031 W2201 DV-P325U only 2L023 2L023... -
Page 51: Mechanical Parts List
MECHANICAL PARTS LIST SYMBOL-NO P-NO DESCRIPTION SYMBOL-NO P-NO DESCRIPTION MECHANISM SECTION TJ15672 FRONT ASSEMBLY [P325U] TJ15671 FRONT ASSEMBLY [P323U] TJ15673 TRAY ASSEMBLY TJ15674 JOG SHUTTLE KEY TJ15675 FOOT TS17051 FOOT ASSEMBLY TJ15676 MAIN CHASSIS TJ15677 TOP COVER SILVER TJ15679 REAR PANEL [P325U] TJ15678 REAR PANEL... -
Page 52: Electrical Parts List
ELECTRICAL PARTS LIST Note: Although some parts in the schematic diagrams have different names from those in the parts list, there is no problem in replacing parts. SYMBOL-NO P-NO DESCRIPTION SYMBOL-NO P-NO DESCRIPTION Q1002 TC10778 TRANSISTOR KTC3199(GR) SEMI-CONDUCTORS Q1003 TC10778 TRANSISTOR KTC3199(GR) D1001 TC10752... - Page 53 SYMBOL-NO P-NO DESCRIPTION SYMBOL-NO P-NO DESCRIPTION SW2203 TE11957 TACT SWITCH SW2204 TE11957 TACT SWITCH SW2205 TE11957 TACT SWITCH SW2206 TE11957 TACT SWITCH SW2207 TE11957 TACT SWITCH SW2208 TE11957 TACT SWITCH SW2209 TE11957 TACT SWITCH SW2210 TE11957 TACT SWITCH SW2211 TE11957 TACT SWITCH W1001 TE14841...
- Page 54 DV-P325U No. 9202E Digital Media Products Division, Tokai DV-P323U...
