- Page 1 ZMR - 243 ZONER - MIXER TECHNICAL MANUAL...
-
Page 2: Introduction & Operation
ZMR – 243 ZONER MIXER INTRODUCTION & OPERATION The ZMR-243 is a zoner mixer which is intended for use in clubs, bars, hotels, retail establishments etc. It is a high quality unit with excellent technical performance. Its features include the ability to operate as a stand alone unit, or by the addition of inexpensive passive remote panels, which are available as optional extras, allows remote control of the music source and volume on any or all its outputs (zones). -
Page 3: Installation
INSTALLATION Installation of the ZM-243 should be carried out by experienced engineers wherever possible. Good wiring practice should be observed when connecting any audio equipment. Good quality connectors and screened cable should be used for all audio connections . Twin screened cable should be used for all balanced lines particularly microphone connections. THIS UNIT MUST BE EARTHED Several internally selectable options are provided:- See Drg947-8 PRIORITY INPUT Stereo music input 1 may be selected to be a priority input by internal jumper... -
Page 7: Technical Specification
TECHNICAL SPECIFICATION Frequency Response (EQ. set flat) 20Hz - 20KHz +/- 0.5dB THD + noise @ 1KHz MAX O/P <.02% THD + noise @ 1KHz @ operating level 0dBu <.01% Typically .005% Microphone Inputs 1-2 Connector type XLR Internally selectable phantom power (15V) Gain selection by 6 position rotary switch Gain Min 10dB...
