7104 Features
The TEKTRONIX 7104 Oscilloscope is a solid-state, wide-bandwidth instrument designed for general-purpose
applications .
The 7104 can also be used to observe or photograph very fast repetitive or single shot
waveforms .
The 7104 accepts Tektronix 7000-series plug-in units ; the flexibility of the plug-in feature and variety of
plug-in units
available allows the system to be used for many measurement applications . The
left pair of plug-in compartments are for
vertical deflection and the right pair are for horizontal deflection . Electronic
switching between each pair will produce
multitrace vertical and/or horizontal displays .
