31.5” LCD TV with DVD Player Operating Instructions Model No. FPE3206DV For assistance, please call: 18006454994 Or visit us at WWW.AUDIOVOX.COM Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference 1287728...
Important Safety Instructions Product Features Disc Information Front Panel Rear Panel Remote Control Special Features of the DVD Module System Connections Connecting to External AV Signal Source (AV1) Connecting to External AV Signal Source (AV2) Connecting to External AV Signal Source (AV3 / AV4) Connecting to HDMI Output Device Connecting to External AV Device (AV Out) Connecting to Digital Amplifier 18 Connecting to PC Connecting to TV Signal Connecting to Power Supply Connecting ...
Important Safety Instructions The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. POWER SUPPLY: ...
Page 4
Important Safety Instructions Note: 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Maintain well ventilated conditions around the product. Do not put product on bed, sofa or anything that blocks ventilation. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than the other. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. ...
Product Features This product is designed with movable Disc Tray. The Disc Tray can be installed in three different positions. The movable Disc Tray offers you the flexibility to choose which direction to insert your DVD in order to maximize your space. The unit incorporates highresolution LCD display, DVD player and TV receiver in one system. ...
Disc Information Discs Formats Supported By This Player DISC LOGO DVD CD JPEG The operating method of some DVD discs is specified by the software maker. Please refer to l the instruction manual of the disc. The DVD Player will play most recordable (CDR) or erasable (CDRW) CDs, but playback of l CDR or CDRW discs created on a computer requires proper formatting and finalization of the disc for audio playback. Some computers and/or software programs may not be capable of creating compatible discs. About Disc Terms Title Generally, pictures or music compressed on a DVD are divided into several sections, “title”. Chapter The smaller section unit of picture or music in a DVD under the title, usually one title is comprised of one or more chapters and each of them is numbered for easy searching. But some discs may not have a recording chapter. Track A segment of picture or music on a CD. Each track is numbered for searching. CONTENTS SIZE Audio+Video 12cm (active picture) ...
Front Panel Front and Right View 31.5" Color TFT screen 1. 31.5" color TFT screen clearly shows your picture. SOURCE button 2. Press to enter the sourceselecting menu and then use the ▲▼ buttons to select mode: TV, AV1 (Composite1), AV2 (Composite 2), AV3 (Component1), AV4 (Component2), VGA, HDMI or DVD, then press the Enter button to enter the selected mode. MENU button 3. Press to enter or exit system setup menu. CH ▲/▼button 4. In TV mode, press to select channels. In setup menu, the same function as ▲/▼ direction buttons. VOL ▲/▼ button 5. Press to decrease or increase the volume, the same function as ◄/► direction buttons in setup menu. 6 ...
Page 8
Front Panel(Continued) STOP button 6. Press to stop playback in DVD mode. PLAY button 7. Press to start playback in DVD mode. EJECT button 8. Press to eject the disc out from the disc tray. POWER button 9. Press to enter or exit the standby mode. Disc Tray Slot 10. Insert disc into this slot. SD/MS/MMC card port 11. Insert SD/MS/MMC card into this slot. USB Port 12. Connecting to the USB device. Remote Sensor 13. Remote sensor window for the remote control. Power Indicator 14. In standby mode, it turns red; when operation it is blue. Speakers 15. Provides high quality sound. 7 ...
Rear Panel Rear View Open the back cover on the right side of the unit’s rear panel, all the jacks will appear, as shown on the figure below: 1. Y/Pr(Cr)/Pb(Cb) and L/R audio Input Jacks Connecting for the Y/Pr(Cr)/Pb(Cb) input in AV3 (Component) mode. 2. Y/Pr(Cr)/Pb(Cb) and L/R audio Input Jacks Connecting for the Y/Pr(Cr)/Pb(Cb) input in AV4 (Component) mode. 3. Video and L/R audio Input Jacks Connecting for the audio and video signal input in AV1 (Composite) mode. 4. Video/SVIDEO and L/R audio Input Jacks ...
Remote Control Remote Control Buttons Functions For TV Operation POWER button 1. Press to enter or exit the standby mode. 0~9 Number buttons 2. Press to select numbers. MTS button 3. In TV mode, press to shift mode among SAP, Mono and Stereo. VOL +/ button 4. Press to increase or decrease the volume. MUTE button 5. Press to turn on or off the speaker output. SOURCE button 6. Press to enter the sourceselecting menu, then use the ▲▼ button to select mode: TV, AV1 (Composite1), AV2 (Composite2), ...
Page 11
Remote Control(Continued) Remote Control Drawing For DVD Operation PLAY button 1. Press to play the disc. ; PAUSE button 2. In DVD mode, press to pause the playback or start step frame by frame playback. Press the 4 PLAY button to resume normal playback. 7 Fast Backward button 3. Press to search backward fast. 8 Fast Forward button 4. Press to search forward fast. 0~9 Number buttons 5. Press to select numbers. Direction buttons(▲▼◄►) 6. In the setup menu, press the ▲▼ button to select the desired items; press the ◄► button to adjust. ...
Page 12
Remote Control(Continued) Preparation of Remote Control Softly push the back cover to open the battery compartment. Insert two batteries (1.5V, size AAA), please make sure the polarity matches the marks inside the compartment. Softly press the back cover to close it. Under normal use the battery will last for l six months. Take out batteries when the remote is not l in use for a long time. Using Remote control Point the remote control unit from no more than ...
Special Features of the DVD Module NOTE: before removing or installing the DVD module, make sure unplug the power supply cord. The unit supports to install the extended functional modules in three different positions and supports to install two functional modules at the same time. Please follow the below steps to remove or install the function module. Remove the DVD module: Refer to the below figure and follow the below steps to remove the DVD module from the unit: Step 1: Open the back cover on the left rear panel of the unit. Step 2: remove the DVD module. 1. Loose the screw on the DVD module. 2. ...
System Connections Do not connect the power cord until all other connections have been made. · Ensure that you observe the color cables when connecting audio and video cables. · Before connecting, open the cover on the right side of the unit’s rear panel. · Connecting To External AV Signal Source (AV1) Use the audio and video cable to connect the input jacks on the right side of the unit’s rear panel to the external AV signal source. After connection, turn on the power of the unit and the external AV signal source, press the SOURCE button to enter the Input menu, then select AV1 (Composite) and press the ENTER button to enter the selected mode.
System Connections Connecting To External AV Signal Source (AV2) Use the audio and video cable to connect the input jacks on the right side of the unit’s rear panel to the external AV signal source. Also use the SVideo cable to connect the SVideo input jacks on the right side of the unit’s rear panel to the external AV signal source. NOTE: SVIDEO cable will produce good image quality. After connection, turn on the power of the unit and the external AV signal source, press the SOURCE button to enter the Input menu, then select AV2 (Composite) and press the ENTER button to enter the selected mode. If connected to the two group AV and SVideo signal sources at the same time, the SVideo is the ...
System Connections Connecting to External AV Signal Source(AV3/ AV4) Use the audio and video cables to connect the Y/Pb (C b) /Pr (Cr) input Jacks on the right side of the unit’s rear panel to the external AV signal source. After connection, turn on the power of the unit and the external AV signal source, press the SOURCE button to enter the Input menu, then select AV3 (Component) or AV4 (Component) and press the ENTER button to enter the selected mode. NOTE: The Component cable will produce better image quality. 15 ...
System Connections Connecting to HDMI Output Device This unit can be connected to the AV device with HDMI output. See the below figure for details: After connection, turn on the power of the unit and the external HDMI output device, press the SOURCE button to enter the Input menu, then select HDMI and press the ENTER button to enter the HDMI mode. 16 ...
System Connections Connecting to External AV Device (AV Out) Use the audio/video cables to connect the audio and video output Jacks on the right side of the rear panel to the external AV device. NOTE: The features of this A/V equipment allows you to connect to other A/V equipment. Care should be taken when connecting the A/V outputs of this device to the A/V inputs of the other device. For example, composite output of this device needs to be connected to composite inputs of the other device. 17 ...
System Connections Connecting to Digital Amplifier The unit is designed with an optical digital audio jack, can be connected to the digital amplifier, see the below figure: NOTE: The optical digital audio can only output ATSC, NTSC and HDMI signals. 18 ...
System Connections Connecting to PC The unit can be connected to PC (personal computer) via the VGA cable. Follow the figure below to connect: 1. Connect one end of the VGA cable to the VGA input jack on the right side of the unit’s rear panel. 2. Connect the other end to the PC. 3. Connect one end of the audio cables to the PC audio input jack on the right side of the unit’s rear panel. 4. Connect the other end to the PC audio output jack. 5. You had better set the PC’s resolution at 1024×768; and the refresh frequency must at 60Hz. After connection, press the SOURCE button and select VGA mode. 19 ...
System Connections(Continued) Connecting to TV Signal Input This unit can be connected to the TV signal input source via the 75Ω antenna jack on the rear panel. After connection, turn on the power of the unit and press the SOURCE button and select TV mode. Connecting to Power Supply One end is connected to the jack on the rear panel of the unit, the other end to the AC110~220V wall outlet. 20 ...
System Connections(Continued) Connecting to Earphone This unit can be connected to an earphone for listening music privately. See the below figure for details: When the headphone is connected, the speakers will turn off automatically. NOTE: Excessively loud volume could damage your hearing. So turn down the volume before you connect the headphones, and then raise the volume to comfortable level. 21 ...
Input Source Selecting The player incorporates multiple video modes, you can select the video mode according to the input signal. Press the SOURCE button to enter the Input menu, the screen will display as below: In the menu, press the 56 direction button to select the video mode, press the ENTER button to enter the selected mode. NOTE: If connected to external AV and SVideo signal input source at the same time, the AV1(Composite) is for video1 input, the AV2(Composite) is for SVideo input, the video2 input can not be selected. If installed with extended functional module DVD or PVR, DVD or RECORDER will be displayed on the screen for selecting. 22 ...
System Setup and Operation Preparations 1. After connection, press the POWER button to turn on the power. 2. Press the SOUECE button to display the Input menu, then press the 56 button to select TV and press the ENTER button to enter TV mode. You can go on with the following setups: Setup Setting Press the MENU button to enter the main setup menu, as shown on the right: In the menu, press the ▲▼ button to select the SETUP, and then press the ◄ or ► button to enter the setup menu, press the ▲▼ button to select items. Press the ◄ or ► button again to return to the previous menu. ...
System Setup and Operation(Continued) Manual Ch Search Press the ▲▼ button to select the Manual Ch Search, press the ENTER button to enter the Manual Channel Set Menu, see the right figure: In the menu, press the 3456direction buttons to select items, press the ENTER button to confirm or set, press the EXIT button to exit. Channel Labels ...
Page 26
System Setup and Operation(Continued) Brightness Press the ▲▼ button to select the Brightness, press the ENTER button to enter the adjusting mode, press the ◄ ► button to adjust the value. Press the ENTER button again to confirm and return. Sharpness Press the ▲▼ button to select the Sharpness, press the ENTER button to enter the adjusting mode, press the ◄ ► button to adjust the value. Press the ENTER button again to confirm and return. Color Press the ▲▼ button to select the Color, press the ENTER button to enter the adjusting mode, press the ◄ ...
System Setup and Operation(Continued) Audio Setting Press the MENU button to enter the main setup menu, as shown on the right: In the menu, press the ▲▼ button to select the Audio, and then press the ◄ or ► button to enter the setup menu, press the ▲▼ button to select items. Press the ◄ or ► button again to return to the previous menu. Press the EXIT button to exit the setup menu.
System Setup and Operation(Continued) Feature Setting Press the MENU button to enter the main setup menu, as shown on the right: In the menu, press the ▲▼ button to select the Feature, and then press the ◄ or ► button to enter the setup menu, press the ▲▼ button to select items. Press the ◄ or ► button again to return to the previous menu. Press the EXIT button to exit the setup menu. ...
Page 29
System Setup and Operation(Continued) Advanced Video Menu Press the ▲▼ button to select the Advanced Video Menu, press the ENTER button, the screen is shown as right figure: In the menu, press the 56direction buttons to select items, press the ENTER button to set, press the EXIT button to exit. Password Set Press the ▲▼ button to select the Password Set, press the ENTER button, the screen is shown as right figure: Use ...
Page 30
System Setup and Operation(Continued) Fantasy violence [FV], adult languages [L], sexual situations [S], violent scenes [V] and suggestive dialogues [D] In the menu, press the 3456direction buttons to select MPAA or TV rating, press the ENTER button to set or cancel the rating. Press the EXIT button to exit the setup menu. Closed Caption Options Press the ▲▼ button to select the Closed Caption Options, press the ENTER button, the screen is shown as right figure: In the menu, press the 56direction buttons ...
DVD Player Operation Disc Loading Steps: 1. Press the POWER button to turn on the power. Press the SOURCE button and select DVD mode, press the ENTER button confirm and shift to DVD mode. 2. Handing the disc with its printed side outward vertically to the disc tray. (Referring to the below picture.) 3. Gently put the disc into the disc tray. 4. Disc will automatically be pulled into the disc player. While the disc is loading, “Loading” will appear on the liquid crystal display and playback will begin. Warning: ...
Page 32
DVD Player Operation(Continued) Pause Press the ; Pause button once to pause the playback, press it repeatedly to start stepbystep playback, press the4 PLAY button to resume normal playback. Previous and Next Press the : button to go to the next chapter. Press the 9 button once to return to the beginning of the current chapter, press it twice to go to the previous chapter. Fast Playback Press the 8 or 7 button on the remote control to activate fast forward or backward playback. Repeat Use the REPEAT button repeatedly to repeat a chapter, title or all. Menu Normally there is a selecting menu for DVD discs. You can press the red DVDMENU button to enter the menu, and use the direction buttons to highlight an item. Then press the ENTER button to confirm. ...
Page 33
DVD Player Operation(Continued) CD Playback The player will play all tracks on a CD disc by default. You can use the 9 and : (PREV/NEXT skip) buttons, or number buttons to select a track. Stop Press the ■ STOP button once to stop playback and then press 4 PLAY button to resume. Press this button twice to stop playback completely. Pause Press the ; PAUSE button to pause the playback and then press the4 PLAY button to resume normal playback. Previous and Next Press the 9 button once to go the beginning of this track. Press twice repeatedly to go the previous track. Press the : button to play from the beginning of the next track. Fast Playback Press the 8 or 7 button on the remote control to activate fast forward or backward playback. Repeat Use the REPEAT button repeatedly to repeat Single, All or to cancel repeat. ◆ Some discs do not support the repeat function. Audio During CD playback, press the AUDIO button on the remote control to select the audio output mode: Mono Left, Mono Right, MixMono and Stereo. 32 ...
Page 34
DVD Player Operation(Continued) JPEG Playback JPEG is a common picture format that requires small amounts of storage per image and has low loss in resolution. Hundreds of pictures can be stored on a disc in this format. In order to view JPEG photo albums, you can ask your film development company to make a ”PICTURE CD” when they develop your film. Normal Playback Load a JPEG disc in. For JPEG disc, there will be a root menu displayed on the screen. Use the ENTER button and the direction button to select a submenu, and then use the ▲▼ direction button to select the contents. Many discs have other contents besides pictures. For Picture CD disc, it will display the pictures automatically. During playback, press the 9 or : button to select picture. ◆ Many discs have other content besides pictures. Stop Press the < STOP button once to stop playback and return to the preview menu. Press the 4 PLAY button to resume normal playback. Pause Press the ; PAUSE button to pause playback, press the 4PLAY button to resume playback. Repeat During playback, press the REPEAT button repeatedly, and the repeat modes are Shuffle, Random, Single, Repeat One, Repeat All and Repeat Off. Previous and Next During playback, press the 9 or : button to select picture. ...
USB and SD/MS/MMC Card Function USB and SD/MS/MMC Card Function Preparation: 1. Install the DVD module onto the LCD TV. 2. Connect the unit to the power supply. 3. Press the POWER to turn on the unit. 4. Press the SOURCE button and select DVD, press the ENTER button to shift to DVD mode. 5. Insert the USB into the unit’s USB slot, or insert the SD/MS/MMC card into the SD/MS/MMC card slot on the right side of the unit. Please see the below figure: Ø Make sure that files are stored in the USB and the SD/MS/MMC card before the connection. 6. Press the CARD button to shift among disc playback, USB playback and the SD/MS/MMC playback. The default state is disk playback. Please see the below figure: 7. Press the 56 button to select the folder, and press the ENTER button to enter. 8. Press the 56 button to select the desired track. Then press PLAY4 button to start playback. 9. Press the STOP < button to stop playback: if the STOP< button is pressed, the playback will start from the beginning of the current track. Press the 3button to return to the folder menu. NOTE: ...
DVD System Setup Preparations 1. Install the DVD module onto the LCD TV. 2. Connect to the power supply and turn on the unit. 3. Press the SOURCE button and select DVD, press the ENTER button to shift to DVD mode. 4. Press the SETUP button on the remote control to display the settings menu. 5. Press the 34 direction buttons on the remote control to select a category. All the items in the category will appear on the screen. 6. Press the SETUP button again to exit the setup. General Setup Page Press the SETUP button to enter the General setup menu. The screen will display as the following: TV Display Angle Mark In the menu, Use the 56 direction buttons to select the desired item. Press the ENTER button to enter the item. Press the 3 button to return. 1. Press the 56 direction buttons to select TV Display. 2. Press the ENTER button to enter the setup. 3. Use the 56 direction buttons to select items. 4. Press the ENTER button again to confirm selection and return. ...
Page 37
DVD System Setup(Continued) OSD Lang Screen Saver Last Memory Media Center The item is used to select the OSD language. 1. Press the 56 direction buttons to select OSD Lang. 2. Press the ENTER button to enter the setup. 3. Use the 56 direction buttons to select items. 4. Press the ENTER button again to confirm selection and return. 1. Press the 56 direction buttons to select Screen Saver. 2. Press the ENTER button to enter the setup. 3. Use the 56 direction buttons to select On or Off. ...
Page 38
DVD System Setup(Continued) Audio Setup Page Press the SETUP button to enter the General setup menu. Then use the 34 direction buttons to select Audio Setup Page, the screen will display as the following: Dolby Digital Setup Dual Mono Dynamic In the menu, Use the 56 direction buttons to select the desired item. Press the ENTER button to enter the item. Press the 3 button to return. 1. Press the 56 direction buttons to select Dolby Digital. 2. Press the ENTER button to enter the setup, the screen will display as left: 3. In the menu, use the 56 direction buttons to select items. 4. Press the ENTER button to enter the setup. Press the 3 button to return. ...
Page 39
DVD System Setup(Continued) Hdcd Setup In the Audio Setup Page, use the 56 direction buttons to select Hdcd Setup, press the ENTER button to enter the setup, the screen will display as the following: Video Setup Press the SETUP button to enter the General setup menu. Then use the 34direction buttons to select Video Setup Page, the screen will display as the following: HD Mode Use the 56 direction buttons to select HD Mode, press the ENTER button to enter the menu as the following: 1. In the menu, press the ENTER button to enter the setup. 2. Use the 56 direction buttons to select items. 3. Press the ENTER button again to confirm selection and return. 4. Press the 3 button to return. In the menu, Use the 56 direction buttons to select the desired item. Press the ENTER button to enter the item. Press the 3 button to return. 1. In the menu, press the ENTER button to enter the setup. 2. ...
Page 40
DVD System Setup(Continued) Video Quality Setup Select Quality, press the ENTER button to enter the menu as the following: Sharpness Brightness Contrast 1. In the menu, Use the 56 direction buttons to select the desired item. 2. Press the ENTER button to enter the item. 3. Press the 3 button to return. 1. Press the 56 direction buttons to select Sharpness. 2. Press the ENTER button to enter the setup. 3. Use the 56 direction buttons to select High, Medium or Low. 4. Press the ENTER button again to confirm selection and return. ...
Page 41
DVD System Setup(Continued) Preference Setup Press the SETUP button to enter the General setup menu. Then use the 34 direction buttons to select Preference Page, the screen will display as the following: Audio Subtitle Disc Menu In the menu, Use the 56 direction buttons to select the desired item. Press the ENTER button to enter the item. Press the 3 button to return. 1. Press the 56 direction buttons to select Audio. 2. Press the ENTER button to enter the setup, see the left figure: 3. Press the 56 direction buttons to select audio language. 4. ...
Page 42
DVD System Setup(Continued) Parental Default DVD discs equipped with the child lock function are rated according to their contents and settings vary from disc to disc. Depending on the disc, you can lock out playback of the disc altogether. 1. Press the 56 direction buttons to select Parental. 2. Press the ENTER button to enter the setup, see the left figure: 3. Press the 56 direction buttons to select item. 4. Press the ENTER button to confirm. And use the number buttons to enter the password.
Page 43
DVD System Setup Password Setup Press the SETUP button to enter the setup menu. Then use the 34direction buttons to select Password Setup Page, the screen will display as the below: Password Mode Password Change In the menu, use the 56 direction buttons to select the desired item. Press the ENTER button to enter the item. Press the 3button to return. 1. Press the 56 direction buttons to select Password Mode. ...
Troubleshooting SYMPTOM The player does not play. There is no sound. LCD is no display DVD does not continue to play or plays the same section repeatedly. There is no picture or picture moves up and down. The remote control does not work. Other Notes: Static or other external interference may cause the player to behave abnormally. In this occurrence, unplug the powersupply cord from the outlet and plug it in again to reset the player. If the problem persists, then please disconnect the power and consult a qualified technician. CHECK ITEM Make sure disc is loaded in. Make sure disc is loaded upside down. Make sure disc is not dirty or warped. Make sure the player’s region code is the same as region code of DVD disc. ...
Specifications TFTLCD Resolution TFTLCD Screen Size Laser Wavelength Video System Frequency Response Audio Signaltonoise Rate Audio distortion+noise Channel Separation Dynamic Range Audio Out Video Out Power Power Consumption Dimension Ambient Temperature Weight DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Manufactured under license from Dolby Laboratories. “Dolby” and the doubleD symbol are trademarks of Dolby Laboratories. Confidential unpublished works. All rights reserved. is a trademark of SRS Labs, Inc. TruSurroundXT technology is incorporated under license from SRS Labs, Inc. 1366x768 31.5 inches 780/650 nm NTSC 20Hz~20kHz ≥85dB ≤-70dB (1kHz) ≥70dB (1kHz) ≥80dB (1kHz) Analog Audio Out Out Level: 1.5V± Out Level: 1V Video Out Unbalanced Negative AC110~220V,50/60Hz <210W 803mm × 630mm × 280mm(LXWXD) ...
