Summary of Contents for Audiovox PVS21090
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS AVIS WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install accordance manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (Including amplifiers) that produce heat. -
Page 4: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ... 1 IMPORTANT INSTRUCTIONS ... 2 MAINTENANCE ... 2 CONTENTS ... 3 DISC FORMATS ... 4 ACCESSORIES ... 5 USING OF REMOTE CONTROL ... 5 CONTROL REFERENCE GUIDE . 6-7 CONNECTIONS ... 8-9 Connecting a TV Antenna ... 8 Connecting to other Equipment with Video Output (VCR, Camcorder, Video Game System, Cable, Satellite system,... -
Page 5: Disc Formats
DISC FORMATS NOTES ON COPYRIGHT It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public or rent copyrighted material without permission. Apparatus Claims of U.S. Patent Nos. 4,907,093; 5,315,448 and 6,516,132 licensed for limited viewing uses only. DVD video discs are copy protected, and any recordings made from these discs will be distorted. -
Page 6: Accessories
ACCESSORIES Please check and identify the supplied accessories. AC Power Cord ... x 1 AC Adapter ... x 1 Remote Control (with batteries) ... x 1 USING OF REMOTE CONTROL USING THE REMOTE CONTROL • This remote control is magnetic and can be attached to most refrigerators. -
Page 7: Control Reference Guide
CONTROL REFERENCE GUIDE REMOTE CONTROL FUNCTION button Switch between TV / AV IN / DVD. Number (0 - 9) buttons MEMORY button Set predetermined playback. • [dot] button Digital TV channels (i.e. 11.3 or 12.7) EXIT button Press to exit the TV menu and return directly to normal viewing. -
Page 8: Front & Back Views
CONTROL REFERENCE GUIDE FRONT & BACK VIEWS Color LCD screen Remote sensor Point the remote control here. Standby indicator Right speaker Removable stand MENU button Enters the on-screen TV menu. / ON button Turns the unit on and off. DVD DOOR OPEN button Open the disc door. -
Page 9: Connections
CONNECTIONS CONNECTING A TV ANTENNA To view television channels correctly, a signal must be received from one of the following sources: - An indoor or outdoor aerial antenna - A cable system - A satellite system To TV Antenna terminal NOTE For receiving over-the-air TV broadcasts, we recommend that you use an external fixed antenna. -
Page 10: Connecting To Another Tv With A/V Input
CONNECTIONS CONNECTING TO ANOTHER TV WITH A/V INPUT Connecting to another TV Connects the AUDIO / VIDEO cable (not included) as shown: Make sure you connect the cable from another TV (AUDIO/VIDEO IN) to this unit (AUDIO/VIDEO OUT). NOTE • Please refer to your another TV user manual for more information. -
Page 11: Installation
INSTALLATION REMOVING THE BASE STAND WARNING: The LCD display is very fragile, and must be protected at all times when removing the base stand. Be sure that no hard or sharp objects, or anything that could scratch or damage the LCD display, come in contact with it. -
Page 12: Screen Viewing Angle Adjustment
SCREEN VIEWING ANGLE ADJUSTMENT The unit is designed to allow users to have a comfortable viewing angle. 1. Hold the stand firmly. 2. Gently adjust the TV. CAUTION Do not force the LCD screen over the maximum viewing angle settings as stated above. Attempting this will result in damage to the unit. -
Page 13: Using The Tv
USING THE TV Connect an antenna or CATV cable or Satellite system to the TV antenna terminal before searching TV channels. Searching for TV channels automatically (Only appears to the first time Power ON) 1. Connect the TV antenna. 2. Connect the AC adapter and AC cord. 3. -
Page 14: Tv Setup
TV SETUP PICTURE SETTING 1. Press the TV MENU button. 2. Use the button to select the options (Picture Mode / Contrast / Brightness / Sharpness / Tint / Color). 3. Use button to make adjustment. The screen will change to your selected mode immediately. -
Page 15: Timer Setting
TV SETUP TIMER SETTING 1. Press the TV MENU button. 2. Use the button to select TIMER SETTING. 3. Use the button to select the options (OSD Duration / Sleep Timer / Time Zone / Day Saving Time). 4. Use the button to make adjustment. -
Page 16: Tv Channel Setting
TV SETUP TV CHANNEL SETTING 1. Press the TV MENU button. 2. Use the button to select TV CHANNEL SETTING. 3. Use the button to select the options (Antenna / Auto Scan / Auto Scan Add CH / Channel Skip / Channel No. / Channel Label). -
Page 17: Playing A Disc
PLAYING A DISC This owner’s manual explains the basic instructions of this unit. Some DVDs are produced with limited operation during playback. For example, many DVDs do not allow users to skip government warnings, or in some cases previews or other features. This is not a defect in the unit. Refer to the instruction notes of discs. -
Page 18: Fast Forward / Fast Reverse
PLAYING A DISC FAST FORWARD / FAST REVERSE 1. Press the SEARCH • The disc begins a fast scan at two times normal (x2) speed. • Four speeds are available. Each time the SEARCH button is pressed, the speed of the fast scan changes 2. -
Page 19: Special Function
SPECIAL FUNCTION DISPLAY While the disc is playing, press the DISPLAY button repeatedly to display information on operation status. LOCATING A SPECIFIC TITLE (DVD) If a DVD disc contains title numbers, you can locate a specific title by directly selecting its title number. -
Page 20: Repeat Playback
REPEAT PLAYBACK You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat) REPEATING A CHAPTER (DVD) When you play the same chapter repeatedly. 1. While the DVD disc is playing, press the REPEAT button until the “REP : CHAPTER” indicator displays on the screen. -
Page 21: Dvd/Cd Programmable Playback
DVD / CD PROGRAMMABLE PLAYBACK PROGRAMMABLE MEMORY The two types of programmed playback provided by this unit are title/chapter programmed playback and track programmed playback. Title / chapter programmed playback (DVD) 1. In STOP mode, press the MEMORY button. 2. Enter the title numbers in move the highlight to chapter and enter the chapter numbers 3. -
Page 22: System Setup
CUSTOMIZING THE FUNCTION SETTINGS SYSTEM SETUP 1. Press the SETUP button in STOP mode. 2. Use the button to select LANGUAGE SETUP, then press button repeatedly until SYSTEM SETUP appears. 3. Use the button to select the option (TV TYPE or DEFAULT), then press the make adjustments, then press the ENTER button. -
Page 23: Troubleshooting Guide
TROUBLESHOOTING GUIDE SYMPTOM No power. • Check that the AC adapter and AC power cord are connected. • The unit is not turned on. The remote does not • Remove any obstacles between the remote and the unit. function. • Use the remote near the unit. •... - Page 24 Unit : INCH 2 3/4 OPEN VIDEO AUDIO 3 15/16 14 3/4 5 11/16 8 5/8 Printed in China 811-210991W011...
