Technical Data - GE Interlogix ATS1151 Manual

LED
INDICATIONS
Fig. 9 LED position and colour
LED 1 Dual-colour LED red or
green
This LED stays off when no
areas are assigned to its
alarm group.
LED 2 Yellow LED
LED 3 Red LED

Technical Data

Supply Voltage
Current consumption
Dimensions in mm (H x W x D) (ATS1156)
Dimensions in mm (H x W x D) (ATS1151)
Operating temperature
Humidity Non condensing
Weight (ATS1156)
Weight (ATS1151)
Function
Green when an area is disarmed (area assigned
to the RAS alarm group).
Red when an area is armed (area assigned to
the RAS alarm group).
Yellow is the "ready" LED. When the area is
ready to be secured, the yellow LED switches
on.
Red and flashing when an alarm occurs in any
of the areas assigned to the RAS
2
12V
12V 45 mA
96 x 96 x 40
96 x 67 x 28
-25°C to +70°C
93%
458 g
226 g
Extra Comments
If area is disarmed and the door is
opened, it will flash green for the
access time.
If area is armed, and the door is
opened, it will flash red for the
access time
All the inputs in the area assigned
to the RAS alarm group should be
sealed.
