- Page 1 Network Camera V4.1.0 ES-HNG200I-EI Installer/User Guide...
-
Page 2: Table Of Contents
1.2 Camera Wiring Diagram ......................2 2.0 Installation ......................2 3.0 Setting the Network Camera over the LAN ..........7 3. 1 Modify device info ........................8 4.0 Accessing via Web Browser ................ 10 Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... -
Page 3: Save These Instructions
This manual contains important instructions that should be followed during installation and maintenance of the Network Bullet Camera V4. 1 .0 ES-HNG200I-EI. Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. -
Page 4: Physical Description Of Camera
NOTE: Two types of interfaces of cameras as shown in Figure 1-1 and Figure 1-2. Please choose the right figure according to the appearance of your camera. Figure 1-1 Overview Figure 1-2 Overview Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... -
Page 5: Camera Wiring Diagram
1A, 1B: Alarm output interface D+, D-: RS-485 interface AUDIO IN, G: Audio input interface AUDIO OUT, G: Audio output interface 1.2 Camera Wiring Diagram Figure 1-3 Wiring Diagram Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... -
Page 6: Installation
Use the screws to fix the mounting base to the ceiling; rotate the back box counterclockwise to secure it to the mounting base; use the lock screw to secure the dome camera. Lock screw Figure 2-1 Fix the Mounting Base Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... - Page 7 Fix the mounting bracket with the camera to the mounting base. NOTE: The “bottom” mark on the mounting base should align with the “bottom” mark on the mounting bracket. Figure 2-2 Fix the Camera Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02...
- Page 8 Figure 2-3 Adjust Monitoring Angle Loosen the lock screw on the sun shield and move the sun shield until you can remove it. Remove the sun shield. Figure 2-4 Remove the Sun Shield Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02...
-
Page 9: Adjust The Lens
Fix the lens; reinstall the front cover and the sun shield to finish the installation. NOTE: Reinstall the front cover until aligning the mark on the front cover with the mark on the camera. Figure 2-6 Reinstall the Camera Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... -
Page 10: Setting The Network Camera Over The Lan
It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device type, IP address, port number, gateway, etc. will be displayed. Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... -
Page 11: Modify Device Info
2.) Edit the modifiable network parameters, e.g. IP address and port number. Enter the password of the admin account of the device in the Password field and click to save the changes. Figure 3-3 Select a device Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... - Page 12 Please refer to the user manual of client software for detailed information. • For accessing the network camera from different subnets, please set the gateway for the network camera after you log in. Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02...
-
Page 13: Accessing Via Web Browser
2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3. Input the user name and password. 4. Click Figure 4-1 Login Interface Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02... - Page 14 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. NOTE: You may have to close the web browser to finish the installation of the plug-in Figure 4-2 Download Plug-in Figure 4-3 Download Plug-in Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02...
- Page 15 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. NOTE: For detailed instructions of further configuration, please refer to the user manual of network camera. Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02...
- Page 16 © 2017 Vertiv Co. All rights reserved. Vertiv, the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners.
