- Page 1 Network Camera V4.1.0 ES-HND200I-EI Installer/User Guide...
-
Page 2: Table Of Contents
2. 1 Ceiling Moungting ............................2 2.2 In-Ceiling Moungting ..........................5 3.0 Setting the Network Camera over the LAN ..........9 3. 1 Modify device info ........................10 4.0 Accessing via Web Browser .................12 Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... -
Page 3: Save These Instructions
ABOUT THIS DOCUMENT This manual applies to ES-HND200I-EI series cameras. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual. -
Page 4: Appearance Description
Note: After the powering on of the camera, pressing and holding the INITIAL SET button for about 10 seconds can reset all the parameters to the default 1.1.1 Overview settings. 1.1.2 Camera Wiring Diagram Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... -
Page 5: Installation
NOTE: If required, you can use a plier to remove one clip or both two clips (marked in dotted line in Figure 2-1) on the side of the back box and then route cables through the opening to secure the cables on the ceiling. Figure 2-1 Side Clips Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... - Page 6 Figure 2-2 Mounting Loosen the set screws with the hex key (supplied) to remove the lower dome. Figure 2-3 Disassembling Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
- Page 7 Adjust the lens focus to obtain a perfect image. Fasten the lens set screw. Figure 2-4 Image Adjusting Figure 2-5 Image Adjusting Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
-
Page 8: In-Ceiling Moungting
Reinstall the lower dome and tighten the screws. Figure 2-6 Reinstall 2.2 In-ceiling mounting: Steps: Secure the mounting base to the in-ceiling mounting base with screws. Figure 2-7 Mounting Base Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... - Page 9 NOTE: If required, you can use a plier to remove one clip or both two clips (marked in dotted line in Figure 2-1) on the side of the back box and then route cables through the opening to secure the cables on the ceiling. Figure 2-9 Installing Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
- Page 10 It is strongly recommended that you use a safety rope to secure the in-ceiling mounting base to the roof. Lock screw Figure 2-10 Safety Rope Fasten the lock screws to secure the dome camera. Lock screw Figure 2-11 Fasten Screws Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
- Page 11 Fasten the lens set screw. Reinstall the lower dome. Figure 2-12 Image Adjusting Install the trim plate with screws to finish the installation. Figure 2-13 Trim Plate Installing Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
-
Page 12: Setting The Network Camera Over The Lan
It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device type, IP address, port number, gateway, etc. will be displayed. Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... -
Page 13: Modify Device Info
2.) Edit the modifiable network parameters, e.g. IP address and port number. Enter the password of the admin account of the device in the Password field and click to save the changes. Figure 3-3 Select a device Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... - Page 14 Please refer to the user manual of client software for detailed information. • For accessing the network camera from different subnets, please set the gateway for the network camera after you log in. Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
-
Page 15: Accessing Via Web Browser
2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3. Input the user name and password. 4. Click Figure 4-1 Login Interface Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02... - Page 16 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. NOTE: You may have to close the web browser to finish the installation of the plug-in Figure 4-2 Download Plug-in Figure 4-3 Download Plug-in Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
- Page 17 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. NOTE: For detailed instructions of further configuration, please refer to the user manual of network camera. Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0140A02...
- Page 18 © 2017 Vertiv Co. All rights reserved. Vertiv, the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners.
