  • Page 1 User’s Manual ENDAT-3203M/3220M User’s Manual Rev. 3A For 3203M PCB ver. 2C or later 3220M PCB ver. 2C or later 11/02/2005...

  • Page 2: Copyright Notice

    The Mini-ITX system board Copyright Notice The content of this manual has been checked for accuracy. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this manual. The manufacturer reserves the right to make improvements or modification to this document and/or the product at any time without prior notice.
  • Page 3 This manual covers two different layout models, and the respective board layouts are shown in chapter 1-4. Please refer to the following description to make sure which model on hand before using. ENDAT-3203M ENDAT-3220M System Chipset VIA VT8601A + VIA VT82C686B (APOLLO PLE-133)

  • Page 4: Table Of Contents

    1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS ..........4 1-4. MOTHERBOARD LAYOUT (ENDAT-3203M)..........5 1-5. MOTHERBOARD LAYOUT (ENDAT-3220M) ..........6 CHAPTER 2. SETTING UP THE CPU MOTHERBOARD ....7 2-1. JUMPERS AND CONNECTORS (ENDAT-3203M) ..........7 2-2. JUMPERS AND CONNECTORS (ENDAT-3220M) ..........12 2-3. INSTALLING MEMORY ..................16 2-4. SHARED VGA MEMORY ..................16 2-5.
  • Page 5 User’s Manual `CHPATER 4. VGA, LCD, FEATURE..........32 4-1. AGP-BUS VGA FEATURE..................32 4-2. LCD FLAT PANEL FEATURE (ENDAT-3203M Only) ........33 4-3. PCI BUS AUDIO ADAPTER FEATURES ............34 4-4. DRIVER UTILITY INSTALLATION GUIDE ............35 CHPATER 5. LAN ADAPTER............... 37 5-1. FEATURES......................37 5-2.

  • Page 7: Chapter 1. Introduction

    ENDAT-3203M/3220M system board provides the ultimate solution by integrating with VIA’s technology low power consumption VIA C3 series CPU and VIA EDEN fanless ESP series CPU. ENDAT-3203M/3220M series provides the assorted functions for various applications such as high-end POS systems, kiosks, networking systems, controlling terminals and other embedded systems.

  • Page 8: Features

    CRT Power Management (VESA™ DPMS) Optional for Flat Panel Interface (TTL or LVDS) The ENDAT-3203M ITX board is designed to support industry standard TFT panel via 44pin connector or LVDS transmitters (via LVDS kit). The interface supports both 18-bit and 24-bit display modes.

  • Page 9: Ordering Information

    ENDAT-3220M-1R-8: Support 1 Realtek LAN, C3 800MHz ENDAT-3220M-1R-10: Support 1 Realtek LAN, C3 1GHz ENDAT-3220M-1R-5: Support 1 Realtek LAN, EDEN 533MHz Note: The standard version of ENDAT-3203M/3220M is embedded with VIA C3 800 MHz and Realtek LAN chip other option will be provided upon request.

  • Page 10: Unpacking

    The ENDAT-3203M/3220M System Board 1-2. Unpacking The motherboard comes securely packaged in a sturdy cardboard shipping carton. In addition to the User's Manual, the motherboard package includes the following items:  ENDAT-3203M/3220M System Board  HDD/FDD Cables  TV-Out adapter / cable (Optional) ...

  • Page 11: Motherboard Layout (Endat-3203M)

    User’s Manual 1-4. ENDAT-3203M...

  • Page 12: Motherboard Layout (Endat-3220M)

    The ENDAT-3203M/3220M System Board 1-5. ENDAT-3220M...

  • Page 13: Chapter 2. Setting Up The Cpu Motherboard

    User’s Manual Chapter 2. Setting up the CPU Motherboard 2.1 Jumpers and Connectors (ENDAT-3203M) Function Jumpers/Connectors Cooling Fan Connector JFAN1, JFAN2 AC97 Audio Connector CD_IN, JP1, CN1, CN2 AC97 CODEC Disable/Enable LAN Adapter Disable/Enable COM1 Port (DB9) COM2 Port (BOXHEADER)
  • Page 14 The ENDAT-3203M/3220M System Board Function Jumpers/Connectors Buzzer On/Off JP7: Pin 4, Pin 5 Hardware Reset Switch JP7: Pin 7, Pin 8 External Power Good JP7: Pin 9, Pin 10 Internal Power Good JP7: Pin 10, Pin 11 ATX Power Supply On/Off Switch...
  • Page 15 User’s Manual J3: IR Pin Header. Pin No. Function +5V(DC) N.C. IRRX GND. IRTX Printer (LPT1) Port Pin No. Description Pin No. Description STB# ACK# BUSY SLCT AFD# ERR# INIT# SLIN# 18-25 JP12: Voltage Selector for LCD PANEL Pin No. LCD Power Signal +5V(DC)Type 2-3 *...
  • Page 16 The ENDAT-3203M/3220M System Board CN6 (USB) Header Pin No. Description Pin No. Description USB_VCC USB_VCC USB_DATA0– USB_DATA1– USB_DATA0+ USB_DATA1+ USB_GND USB_GND USB_GND USB_GND CN4: Pin Header for PS2 KB / MS Pin No. Signal (KB) Pin No. Signal(MS) KB Data...
  • Page 17 User’s Manual J5, J6 FOR UC-COM34 I/O (UC-COM 34) JP1 (COM 3, 4) Voltage Selector: Voltage COM3 (JP1) COM4 (JP1) +12V (DC) R.I. * 9-10 +5V (DC) 11-12 LCD_CON1: TFT LCD Panel Port Pin No. Signal Pin No. Signal +12VCD +12VCD VDDLCD VDDLCD...

  • Page 18: Jumpers And Connectors (Endat-3220M)

    The ENDAT-3203M/3220M System Board 2-2. Jumpers and Connectors (ENDAT-3220M) Jumpers/Connectors Overview: Function Jumpers/Connectors Cooling Fan Connector JFAN1, JFAN2 LAN Adapter Disable/Enable COM1 Port (DB9) COM2 Port (BOXHEADER) I/O Connector (for UC-COM34) J5, J6 COM Ports Power Selector (COM1, COM2) I/O (UC-COM34) COM Ports Power Selector...
  • Page 19 User’s Manual JP2 (COM1, 2) Voltage Selector: Voltage COM1(JP2) COM2(JP2) +12V(DC) R.I. * 9-10 +5V(DC) 11-12 JP3, JP5: RS232 / 422 / 485 Selector for COM2 TYPE RS-232 * 1-2, 4-5, 7-8, 10-11 RS-422 (4 wire) 2-3, 5-6, 8-9, 11-12 3-4, 7-8 RS-485 (2 wire) 2-3, 5-6, 8-9, 11-12...
  • Page 20 The ENDAT-3203M/3220M System Board Printer Port (LPT1 / LPT2) Pin No. Description Pin No. Description STB# ACK# BUSY SLCT AFD# ERR# INIT# SLIN# 18-25 COM2, COM3 & COM4 Box Header: Pin No. Description Pin No. Description RI / PWR N.C.
  • Page 21 User’s Manual JKBMS2: Jumper for PS2 KB/MS Pin No. Signal (KB) Pin No. Signal(MS) KB_JDT MS_JDT KB_DT MS_DT KB_JCK MS_JCK KB_CK MS_CK +5V (DC) +5V (DC) CN6 (USB Port 0/1) Header Pin No. Description Pin No. Description USB_VCC USB_VCC USB_DATA0– USB_DATA1–...

  • Page 22: Installing Memory

    The ENDAT-3203M/3220M System Board 2-3. Installing Memory The ENDAT-3203M/3220M CPU board offers one 168pin DIMM sockets supporting up to 512MB of memory. The DIMM memory can be 100MHz (PC-100) or 133 MHz (PC-133). 2-4. Shared VGA Memory The ENDAT-3203M/3220M is using built-in AGP VGA controller with share memory architecture (SMA) - AGP mode with 2MB to 8MB of system memory.

  • Page 23: Assigning Irqs For Expansion Cards

    User’s Manual 2-6. Assigning IRQs for Expansion Cards Some expansion cards require an IRQ (Interrupt request vector) to operate. Generally, each IRQ must be exclusively assigned to specific use. In a standard design, there are 16 IRQ available with 11 of them already in used by other part of the system. Microsoft's Diagnostic (MSD.EXE) utility included in the Windows directory can be used to see their map.

  • Page 24: Chapter 3. Ami Bios Setup

    The ENDAT-3203M/3220M System Board Chapter 3. AMI BIOS SETUP AMI BIOS Setup Main Menu Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup Power Management Setup PCI / Plug and Play Setup Peripheral Setup Hardware Monitor Setup Auto-Detect Hard Disks...

  • Page 25: Quick Setup

    User’s Manual 3-1. Quick Setup In most cases, you can quickly configure the system by using the following procedure. The manufacturer highly recommends that you use “Quick Setup” for setting CMOS to avoid any unpredictable results. 1. Choose “Standard CMOS Setup” from the main menu, to configure the date and time, hard disk type, floppy disk drive type etc.

  • Page 26: Advanced Cmos Setup

    The ENDAT-3203M/3220M System Board 3-3. Advanced CMOS Setup Advanced CMOS Setup Quick Boot Enabled 1st Boot Device Floppy 2st Boot Device IDE-0 3st Boot Device CD/DVD-0 4st Boot Device Disabled Try Other Boot Devices S.M.A.R.T. for Hard Disks Disabled BootUp CPU Speed...

  • Page 27: Password Check

    User’s Manual Password Check This option enables password checking every time the system boots or when you run AMIBIOS Setup. If Always is chosen, a user password prompt appears every time the computer is turned on. If Setup is chosen, the password prompt appears if AMIBIOS is executed.

  • Page 28: Details Of The Advanced Chipset Setup

    The ENDAT-3203M/3220M System Board 3-4. Details of the Advanced Chipset Setup Advanced Chipset Setup ******** DRAM Timing ******** Configure SDRAM Timing by SPD Enabled DRAM Frequency 133MHz SDRAM CAS# Latency DRAM Bank Interleave Disabled DRAM Page Mode Disabled Memory Hole...
  • Page 29 User’s Manual SDRAM Bank Interleave This function is to enable / disable SDRAM Bank Interleave function. <Choices: Disabled / Enabled> Memory Hole To enabled / disabled (default) the support of Memory Hole which is reserved for ISA card. AGP Read Synchronization To enabled / disabled the AGP Read Synchronization function.

  • Page 30: Power Management Setup

    The ENDAT-3203M/3220M System Board 3-5. Power Management Setup Power Management Setup Power Management/APM Enabled Video Power Down Mode Stand By Hard Disk Power Down Mode Suspend Standby Time Out (Minute) Disabled Suspend Time Out (Minute) Disabled Display Activity Ignore IRQ3...
  • Page 31 User’s Manual Power Management/APM Set this option to Enabled to enable the chipset power management and APM (Advanced Power Management) features. The settings are Enabled or Disabled. For detail information, please kindly refer to the Appendix C for “Operation guide for enable APM function with WIN2000 / WIN XP”...

  • Page 32: Pci/ Plug And Play Setup

    The ENDAT-3203M/3220M System Board 3-6. PCI / Plug and Play Setup This section describes the configuration of the PCI bus system. PCI is a system that allows I/O device to operate at speeds nearing the speed of the CPU itself, when communicating with its own special components.
  • Page 33 User’s Manual Display Device (Note 1: For ENDAT-3203M only) Select the display device for system. The available options are CRT Only, CRT + LCD. ** Please note that the text form in the CRT+LCD mode will be shown as the format of LCD mode, not CRT mode;...

  • Page 34: Peripheral Setup

    The ENDAT-3203M/3220M System Board Peripheral Setup 3-7. Peripheral Setup OnBoard FDC Enable OnBoard Serial Port1 3F8/COM1 OnBoard Serial Port2 2F8/COM2 IR Function Serial Port 2 Mode Normal IR Pins Duplex Mode Receiver Polarity Transmitter Polsrity OnBoard Parallel Port Parallel Port Mode...
  • Page 35 User’s Manual Onboard Serial Port 1/2/3/4 This option specifies the base I/O port address of serial port. The settings are Auto (AMIBIOS automatically determines the correct base I/O port address), Disabled, 3F8h, 2F8h, 3E8h, or 2E8h. Onboard Parallel Port This option specifies the base I/O port address of the parallel port on the motherboard.
  • Page 36 The ENDAT-3203M/3220M System Board Parallel Port DMA Channel This option is only available if the setting for the Parallel Port Mode option is ECP. This option sets the DMA channel used by the parallel port. The settings are DMA Channel 0, 1, or 3.

  • Page 37: Hardware Monitor Setup

    User’s Manual 3-8. Hardware Monitor Setup System Hardware Monitor CPU Thermal Temperature System Thermal Temperature Chassis Fan Speed CPU Fan Speed Vcore + 2.500V + 3.300V + 5.000V +12.000V Provide some information such as CPU temperature, speed of cooling fan and usage voltage of CPU for user.

  • Page 38: Chpater 4. Vga, Lcd, Feature

    Chapter 4. VGA, LCD Feature 4-1. AGP-BUS VGA Feature The ENDAT-3203M/3220M built-in Graphics Controller is a fully integrated 64-bit 2D/3D Accelerator. The high performance graphics engine offers high speed 3D image processing in full compliance and compatibility with IBM® VGA and VESA™...

  • Page 39: Lcd Flat Panel Feature (Endat-3203M Only)

    User’s Manual 4-2. LCD Flat Panel Feature (ENDAT-3203M only) Flat Panel Monitor Interface The on-board graphic controller also support industry standard TFT LCD panel, the interface supports both 18-bit and 24-bit display modes. LVDS interface provides a low voltage, high speed, and low EMI serial DC-balanced differential data via LVDS kits: UC-LT1815 (18bit or 24bit), UC-LT1824 (18bit or 24bit).

  • Page 40: Pci Bus Audio Adapter Features

    The ENDAT-3203M/3220M System Board 4-3. PCI Bus Audio Adapter Features The Chipset built-in SoundBlaster Pro Hardware and Direct Sound Ready AC97’ Digital Audio Controller  Dual full-duplex direct sound channels between system memory and AC97’ link  PCI Master interface with scatter / gather and bursting capability ...

  • Page 41: Driver Utility Installation Guide

    User’s Manual 4-4. Driver Utility Installation Guide When finishing the installation of Windows platform (95/98/2000/NT), please install the relative VIA driver (4in1) utilities for compliance compatibility of hardware environment. Insert the support CD that supplied with motherboard into CD-ROM driver which enable the access with auto-run mode;...
  • Page 42 The ENDAT-3203M/3220M System Board The Screen will appear VIA 4in1 driver setup screen, please press “NEXT” to continue. Please follow the steps instructed by each screen for the installation of the VIA 4in1 driver. Restart the system after the completion of the installation.

  • Page 43: Chpater 5. Lan Adapter

    User’s Manual Chapter 5. LAN Adapter The on-board LAN adapter is using Single Chip Fast Ethernet Controller that is highly integrated and requires no “glue” logic external memory on board. It runs in the bus master mode and directly sending/receiving Ethernet packet to/from memory. The On-board LAN adapter can directly fetch the system CPU.

  • Page 44: Utp Cable/Rj-45 Jack Definition

    The ENDAT-3203M/3220M System Board 5-2. UTP Cable / RJ-45 Jack Definition Straight through twisted pair cable is typically used to connect a hub to a server or workstation. In a straight through connection, Pin 1 at the server, Pin 2 at the hub connects to Pin 2 at the server, and so on.

  • Page 45: Connecting 100Base-Tx Fast Ethernet Network

    User’s Manual 5-3. Connecting 100Base-TX Fast Ethernet Network The system board provides an RJ-45 port for connection to 100Base-TX Fast Ethernet or 10Base-T Ethernet Network with a single connection over unshielded twisted-pair (UTP). The adapter automatically operates at 10Mbps or 100Mbps when the appropriate 10/100Base hub be connected.

  • Page 46: Led Indicators

    The ENDAT-3203M/3220M System Board 2. Nominal capacitance: less than 16pF/ft 3. Nominal impedance: 100 ohms 4. Nominal attenuation: less than 11.5db Automatic Selection of the Media Type While the driver installs, it automatically detects the media type based on the type of cable connected.

  • Page 47: The Setup Program

    User’s Manual 5-7. The Setup Program The package includes a diskette containing the setup program. This program allows you to verify the configuration and isolation of faults. The adapter’s I/O port address and interrupt request levels (IRQ) are set by the BIOS. Other default settings can be changed for situations as shown below.

  • Page 48: Software Installation

    The ENDAT-3203M/3220M System Board The option settings can be changed, the table shown as below: Option Default Setting Other Available Settings Disabled  Auto Selection Full-duplex Enable – Forces to full duplex operation Flow Control TX Enable, RX Enable TX Disable, RX Disable...
  • Page 49 User’s Manual Software Installation Examples Before installing the driver programs, please refer to each directory that contains a README file, which provides detailed installation instructions, or to execute the HELP8139.EXE help file viewer in DOS. The utility will then present with a screen showing the information about how to install the network driver.

  • Page 50: Appendix A: Flash Memory Utility

    The ENDAT-3203M/3220M System Board Appendix A: FLASH Memory Utility Using this utility to update the system BIOS from a disk file to the on board Flash memory. Be aware the improper change of the system BIOS will cause the system to malfunction.

  • Page 51: Appendix B: Connector Pin Assignment

    User’s Manual Appendix B: Connector Pin Assignment PS/2 Keyboard / Mouse Pin Header Connector (CN7) Pin No. Signal (KB) Pin No. Signal(MS) KB Data MS Data +5V(DC) +5V(DC) KB_CLK MS_CLK JKBMS2: Jumper for PS/2 KB/MS Pin No. Signal (KB) Pin No. Signal(MS) KB_JDT MS_JDT...
  • Page 52 The ENDAT-3203M/3220M System Board D-SUB Type Connector for COM2 port (RS-422 4 Wire) Pin No. Description Pin No. Description –TXD +RXD +TXD –RXD D-SUB Type Connector for COM2 port (RS-485 2 Wire) Pin No. Description Pin No. Description Data –...
  • Page 53 User’s Manual VGA Connector Pin No. Description Pin No. Description N.C / +5V GREEN BLUE DDC DAT H.Sync V.Sync DDC CLK USB Header Pin No. Description Pin No. Description USB_VCC USB_VCC USB_DATA0– USB_DATA1– USB_DATA0+ USB_DATA1+ USB_GND USB_GND USB_GND USB_GND FDD Connector Pin No.
  • Page 54 The ENDAT-3203M/3220M System Board TFT LCD Panel Port Connector (LCD-CON1) Pin No. Signal Pin No. Signal +12VCD +12VCD VDDLCD VDDLCD DISP ON/OFF BLUE 0 BLUE 1 BLUE 2 BLUE 3 BLUE 4 BLUE 5 BLUE 6 BLUE 7 GREEN 0...
  • Page 55 User’s Manual IDE1, IDE2 Connector Pin No. Description Pin No. Description 2,19,22 IDE data2 24.26.30 IDE data13 IDE data1 20,21,28 IDE data14 29,32,34 IDE data0 IDE reset IDE data15 IDE data7 IDE Write IDE data8 IDE Read IDE data6 IDE Ready IDE data9 IDE IRQ IDE data5...

  • Page 56: Appendix C: Apm Function

    The ENDAT-3203M/3220M System Board Appendix C: APM function Operation guide for enable APM function with WIN2000 / WINXP Step1: Click the “Power…” button in “Display Properties” as the picture of below: Step2: Select the “APM” tab in “Power Options Properties” as the picture of below:...
  • Page 57 User’s Manual Step3: Click the check block to enable AMP function as follows:...

  • Page 58: Appendix D: Limited Warranty

    The limited warranty applies to normal proper usage of the hardware and does not cover products that have been modified or subjected to unusual electrical or physical stress. Unicorn Computer Corp is not liable to repair or replace defective goods caused by improper using or use of unauthorized parts. The following situations will be charged: 1.
  • Page 59 User’s Manual RMA SERVICE REQUEST FORM When requesting RMA service, please fill out this “RMA Service Request Form”. This form needs to be shipped with your returns. Service cannot begin until we have this information. RMA NO.: Company: Person to Contact: Phone No: Purchase Date : Fax No.
  • Page 60 The ENDAT-3203M/3220M System Board  Issue Code of defect. 01 Second Times R.M.A. 11 Memory Socket Bad 02 No Screen (No Boot) 12 Hang Up Hardware 03 VGA (Display) Fail 13 Hang Up Software 04 CMOS Data Lost 14 PCB Problem...
