I
The ENDAT-7105M System Board
ENDAT-7301M
User's Manual
PCB version: A3 or later
Jan.4.2010
Document version: 0.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENDAT-7301M and is the answer not in the manual?

Questions and answers

Summary of Contents for Unicorn ENDAT-7301M

  • Page 1 The ENDAT-7105M System Board ENDAT-7301M User’s Manual PCB version: A3 or later Jan.4.2010 Document version: 0.4...
  • Page 2: Copyright Notice

    User Manual Copyright Notice The content of this manual has been checked for accuracy. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this manual. The manufacturer reserves the right to make improvements or modification to this document and/or the product at any time without prior notice. No part of this document may be reproduced, transmitted, photocopied or translated into any language, in any form or by any means, electronic, mechanical, magnetic, optical or chemical, without the prior written permission of the manufacturer.
  • Page 3 The ENDAT-7105M System Board Specification: Model ENDAT-7301M VIA CX700M (max power consumption: 3.5Watt) System Chipset VIA V4 EDEN ULV 500MHz (1W) / CPU Supporting VIA V4 EDEN 1.0GHz (5W) One 200Pin DDRII 533/400 SO-DIMM up to 1GB Memory VIA PCI interface Gigabit Ethernet Controller VT6122 Ethernet Integrated VIA UniChrome Pro II 3D / 2D Graphics &...
  • Page 4: Table Of Contents

    1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS ........3 1-4. ENDAT-7301M MOTHERBOARD LAYOUT ..........4 CHAPTER 2. SETTING UP THE MOTHERBOARD....... 5 2-1. ENDAT-7301M CONNECTORS / HEADERS AND JUMPERS....5 2-2. INSTALLING MEMORY ................11 2-3. SHARED VGA MEMORY................. 11 2-4. ASSIGNING IRQs FOR EXPANSION CARDS……………………………. 11 2-5.
  • Page 5 The ENDAT-7105M System Board CHPATER 4. VGA, LCD, FEATURE..........26 4-1. VGA FEATURE..................26 4-2. LVDS PANEL FEATURE ................27 4-3. DRIVER UTILITY INSTALLATION GUIDE..........28 CHPATER 5. LAN ADAPTER ............30 5-1. FEATURES....................31 5-2. REMOTE BOOT ROM FUNCTION............31 APPENDIX A: FLASH MEMORY UTILITY ........
  • Page 7: Chapter 1. Introduction

    ULV (Ultra Low Voltage) on one board. The highly integrate function to fit the various embedded application. ENDAT-7301M is using the single power (+12VDC input) designed to optimal the power consumption for the whole system. ENDAT-7301M supports most popular DDRII memory with 64-bit wide interfaces with non-ECC SO-DIMM (up to 1GB).
  • Page 8: Features

    The ENDAT-7301M System Board 1-1. Features Basic Feature: Board format: SBC 146mm x 104mm   Supports 400/533 MHz FSB by VIA C7®/V4 EDEN®  Digital I/O: 4 bits input and 4 bits output (5V level)  Supports DDRII 400/533 MHz SDRAM up to 1GB Serial ATA connector x 1 ...
  • Page 9: Unpacking

    The ENDAT-7301M System Board 1-2. Unpacking The motherboard comes securely packaged in a sturdy cardboard shipping carton. In addition to the User's Manual, the motherboard package includes the following items: ENDAT-7301M System Board PS2 KB / MS Y Cable (KBMS-L13)
  • Page 10: Endat-7301M Motherboard Layout

    The ENDAT-7301M System Board 1-4. ENDAT-7301M Motherboard Layout...
  • Page 11: Chapter 2. Setting Up The Motherboard

    The ENDAT-7301M System Board Chapter 2. Setting up the Motherboard 2-1. Connectors / Headers and Jumpers Connectors Overview: Function Connectors DC Input connector HDDPWR DC Output connector DVI Connector PS/2 KB/MS Connector COM1 COM1 Connector USB Connector LAN Connector FAN1...
  • Page 12 The ENDAT-7301M System Board Jumpers Overview: JBAT1 Clear CMOS LVDS Power Selector JP2, JP3 RS-232 / 422 / 485 Selector (COM2) Master / Slave Selector for CF Card Case Panel Header JP9: Pin 1(-), Pin 2(+) HDD active LED JP9: Pin 3, Pin 6...
  • Page 13 The ENDAT-7301M System Board Part 2: Onboard Connectors and Headers COM2: COM port Box Header (2x5 with 2.0mm) Pin No. Function Pin No. Function N.C. IDE1 Box Header (2x20 with 2.0mm) Pin No. Description Pin No. Description IDE Reset# IDE data7...
  • Page 14 The ENDAT-7301M System Board LVDS1: LVDS (1.25mm) Dual Channel Pin No. Signal Pin No. Signal VBL (+12V) VBL (+12V) DISP.ON/OFF LCD POWER LCD POWER TxO0+ TxO0- TxO1+ TxO1- TxO2+ TxO2- TxO3+ TxO3- TxOC+ TxOC- TxE0+ TxE0- TxE1+ TxE1- TxE2+ TxE2-...
  • Page 15 The ENDAT-7301M System Board JP4: DIGITAL I/O Pin Header Connector (2 x 7 with 2.0mm) Pin No. Function Pin No. Function DIO-I3 DIO-I2 DIO-O3 DIO-O2 DIO-O1 DIO-O0 DIO-I1 DIO-I0 +3.3V +3.3V JUSB1: Pin Header for USB port (2x5 with 2.0mm) Pin No.
  • Page 16 The ENDAT-7301M System Board JP5: LINE IN & MIC IN Pin Header Connector (2 x 4 with 2.0mm) Pin No. Function Pin No. Function LINE_IN_R MIC_IN_R JACK_DETECT JACK_DETECT GND_AUD GND_AUD LINE_IN_L MIC_IN_L Notice: Please connect the jack detect pin to “GND_AUD” if the actual connector cannot support the jack detect function! JP6: SPEAKER OUT Pin Header Connector (2 x 4 with 2.0mm)
  • Page 17: Installing Memory

    The ENDAT-7301M System Board 2-2. Installing Memory ENDAT-7301M system board offers one 200 pin DDRII SO-DIMM socket supports up to 1GB memory and the speed can be 400 and 533 MHz. Note: For DIMM compatibility, please refer to page 32.
  • Page 18: Watchdog Timer

    The ENDAT-7301M System Board Status Assignment Used Timer Used Keyboard Used Second 8259 Used COM2 Used COM1 Used COM3 Used Floppy Disk Used LPT1 Used Used LPT2 or Audio Used COM4 Used LAN Adapter (on board) Used PS/2 Mouse Used...
  • Page 19 //Set active register is CRF4 outportb(0x2f,tt); //Set time out value of WDT void show_ver() unsigned char tmp0; printf("Designed by ROBERT LIOU of UNICORN computer corp. \n2005/10/07 release version:1.0a\n"); printf("This program is design for test Watch Dog Timer for ENADT-7301M (W83697HF).\n");...
  • Page 20: Digital I/O

    The ENDAT-7301M System Board 2-6. Digital I/O 1) Pin out of digital I/O header (JP4): Pin No. Function Pin No. Function DIO-O0 DIO-I0 DIO-O1 DIO-I1 DIO-O2 DIO-I2 DIO-O3 DIO-I3 +3.3V +3.3V 2) Digital I/O port address: This function is support by onboard super I/O chip; it can be control easily by change the register of super I/O chip via I/O port “2Eh”...
  • Page 21: Chapter 3. Award Bios Setup

    The ENDAT-7301M System Board Chapter 3. AWARD BIOS SETUP Phoenix – Award BIOS CMOS Setup Utility > Standard CMOS Features > Frequency/Voltage Control > Advanced BIOS Features Load Optimized Defaults > Advanced Chipset Features Set Supervisor Password > Integrated Peripherals Set User Password >...
  • Page 22: Standard Cmos Features

    The ENDAT-7301M System Board 3-1. Standard CMOS Features The Standard Setup is used for the basic hardware system configuration. The main function is for Data/Time and Hard Disk Drive settings. Item Available Options: Date (mm:dd:yy) Time (hh:mm:ss) Auto IDE Channel 0 Master:...
  • Page 23: Advanced Bios Features

    The ENDAT-7301M System Board 3-2. Advanced BIOS Features This section allows you configuring your system for basic operation. You have the opportunity to select the system’s default speed, boot-up priority, keyboard operation and security. Item Available Options: Hard Disk Boot Priority...
  • Page 24: Dram Clock

    The ENDAT-7301M System Board DRAM Clock/Drive Control Item Available Options: Current FSB Frequency Current DRAM Frequency DRAM Clock By SPD DRAM Timing Auto By SPD ․ DRAM Clock Allows customer set the DDR frequency. ․ DRAM Timing The value in this field depends on performance parameters of the installed memory chips (DRAM).
  • Page 25: Panel Type

    The ENDAT-7301M System Board ․Panel Type LVDS Panel ID: Resolution & Channel 640x480x18 1CH 1024x768x24 1CH 800x600x18 1CH 1024x600x24 1CH 1024x768x18 1CH 1366x768x24 2CH 1280x768x24 1CH 1440x900x24 1CH 1280x1024x24 2CH 1680x1050x24 2CH 800x480x18 1CH 1920x1080x24 2CH 1600x1200x24 2CH 640x240x18 1CH...
  • Page 26: Integrated Peripherals

    The ENDAT-7301M System Board 3-4. Integrated Peripherals The IDE hard drive controllers support up to two separate hard drives. These drives have a master/slave relationship that is determined by the cabling configuration used to attach them to the controller. Your system supports two IDE controllers--a primary and a secondary--so you can install up to four separate hard disks.
  • Page 27: Ide Hdd Block Mode

    The ENDAT-7301M System Board ․ IDE Primary Master/Slave PIO and IDE Secondary Master/Slave PIO The four IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-4) for each IDE device that the internal PCI IDE interface supports. Modes 0 through 4 provide successively increased performance.
  • Page 28: Power Management Setup

    The ENDAT-7301M System Board SuperIO Device Item Available Options: Onboard Serial Port 1 3F8/IRQ4 Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal RxD, TxD Active Hi,Lo IR Transmission Delay Enabled UR2 Duplex Mode Half Use IR Pins IR-Rx2Tx2 ․UART Mode Select Select an operating mode for the serial port.
  • Page 29: Acpi Suspend Type

    The ENDAT-7301M System Board ․ ACPI Suspend Type This field is used to select the type of Suspend mode. Enables the Power On Suspend function. S1(POS) Enables the Suspend to RAM function. S3(STR) If S3 state is supported by the system, by default [S3] is S1 &...
  • Page 30: Pnp/Pci Configurations

    The ENDAT-7301M System Board 3-6. PnP/PCI Configurations This section describes the configuration of the PCI bus system. PCI is a system that allows I/O device to operate at speeds nearing the speed of the CPU itself, when communicating with its own special components. This section covers some very technical items.
  • Page 31: Pc Health Status

    The ENDAT-7301M System Board 3-7. PC Health Status This screen shows the information of temperature, Fan speed and Vcore etc. It also can set CPU warning temperature to protect CPU. PC Health Status Item Available Options: Current System Temp. Current CPU1 Temperature...
  • Page 32: Chpater 4. Vga, Lcd, Feature

    Flawless Digital Media Playback VIA UniChrome Pro II includes native support for the most popular digital video formats through hardware MPEG-2/MPEG-4/WMV9 playback The controller of ENDAT-7301M supports 3 types of display: CRT, LVDS panel and DVI.  Support CRT resolutions up to 1920x1440 ...
  • Page 33: Lvds Panel Feature

    The VIA CX700M graphic controller supports industry standard LCD panel with LVDS interface only, both of 1 (18 or 24) and 2 (36 or 48bit) channels of LVDS panel are available for ENDAT-7301M. The flat panel interface provides or supports following functions for various panels: Generates LVDS flat panel channels like clock and data channel.
  • Page 34: Driver Utility Installation Guide

    The ENDAT-7301M System Board 4-3. Driver Utility Installation Guide 1. When finishing the installation of Windows platform (2000/XP), please install the relative VIA driver (4in1) utilities for compliance compatibility of hardware environment. 2. Insert the support CD that supplied with motherboard into CD-ROM driver which enable the access with auto-run mode;...
  • Page 35 The ENDAT-7301M System Board 5. The Screen will appear VIA 4in1 driver setup screen, please press “NEXT” to continue. Please follow the steps instructed by each screen for the installation of the VIA 4in1 driver. Restart the system after completed the installation.
  • Page 36: Chpater 5. Lan Adapter

    The ENDAT-7301M System Board Chapter 5. LAN Adapter The on-board VIA Velocity VT6122 Gigabit Ethernet Controller The VIA Velocity™ VT6122 Gigabit Ethernet controller enables leading-edge performance in a small 14x14mm 128-pin LQFP package, optimized for 32-bit PCI applications in space-constrained systems. Integrating a feature laden MAC and Cicada's patented SimpliPHY™...
  • Page 37: Features

    The ENDAT-7301M System Board 5-1. Features  Gigabit Ethernet MAC and PHY supporting full and half duplex 10/100/1000 triple-speed operation.  Leading DSP-based Cicada PHY technology: 10BASE-T, 100BASE-TX, and 1000BASE-T compliant.  Support for PCI v2.2 – (VT6122: 32-bit 33/66MHz).
  • Page 38: Appendix A: Flash Memory Utility

    The ENDAT-7301M System Board Appendix A: FLASH Memory Utility Using this utility to update the system BIOS from a disk file to the on board Flash memory. Be aware the improper change of the system BIOS will cause the system to malfunction.
  • Page 39: Appendix B: Lcd Pin Assignment

    The ENDAT-7301M System Board Appendix B: LCD Pin Assignment LVDS1: LVDS (1.25mm) Dual Channel Pin No. Signal Pin No. Signal VBL (+12V) VBL (+12V) DISP.ON/OFF LCD POWER LCD POWER TxO0+ TxO0- TxO1+ TxO1- TxO2+ TxO2- TxO3+ TxO3- TxOC+ TxOC- TxE0+...
  • Page 40: Appendix C: Limited Warranty

    The ENDAT-7301M System Board Appendix C: DIMM COMPATIBILITY Base on VIA CX700 Data Sheet, ENDAT-7201M supports DIMM type as below: ● Supports DDR2 533/400 memory ● Supports mixed 64 / 128 / 256 / 512Mb SDRAM in x8 or x16 configuration ●...
  • Page 41: Appendix D: Limited Warranty

    The limited warranty applies to normal proper usage of the hardware and does not cover products that have been modified or subjected to unusual electrical or physical stress. Unicorn Computer Corp is not liable to repair or replace defective goods caused by improper using or use of unauthorized parts. The following situations will be charged: 1.
  • Page 42: Rma Service Request Form

    The ENDAT-7301M System Board RMA SERVICE REQUEST FORM When requesting RMA service, please fill out this “RMA Service Request Form”. This form needs to be shipped with your returns. Service cannot begin until we have this information. RMA NO.: Company:...
  • Page 43 The ENDAT-7301M System Board  Issue Code of defect. 01 Second Times R.M.A. 11 Memory Socket Bad 02 No Screen (No Boot) 12 Hang Up Hardware 03 VGA (Display) Fail 13 Hang Up Software 04 CMOS Data Lost 14 PCB Problem...
