- Page 1 DIGIWAY PTY LTD SW50 V2.X Dual Swing Gate Motor INSTRUCTION MANUAL - 1 -...
-
Page 2: Important Safety Warning
IMPORTANT SAFETY WARNING Electricity and power motors associated accessories could be fatal or at least cause seriously injury. Digiway suggested some safety device to be used so as to prevent personnel from being injured by motorized device being controlled. All main voltage wiring must be installed by a licensed electrician. -
Page 3: Main Features
1.2 General features SW50 is designed for most of domestic swing gate. It can be mounted on brick wall/pier or steel post. The arm supplied can be met most of application situations. If special need, customer can modified arm or ask supplier/dealer to contact manufacturer for different arm. - Page 4 GATE MOTOR MOUNTING Fig. 2 A385, A415 arms swing in vertical mounting Fig. 3 A385, A415 arms swing in parallel mounting - 4 -...
- Page 5 GATE MOTOR MOUNTING Fig. 4 A385, A585 arms swing out vertical mounting Fig. 5 A385, A585 C800 arms swing in vertical mounting small side room - 5 -...
- Page 6 GATE MOTOR MOUNTING Fig. 6 A585, A585 arms swing in vertical mounting Fig. 7 SW50 motor side view - 6 -...
- Page 7 GATE MOTOR MOUNTING Fig. 8 SW50 clutch/manual release Manual operation: Disengage motor by undo manual release bolt several turns, so that motor basis can move on chassis, hold motor move away from output shaft. To re-engage motor by move motor towards to output shaft and then tight manual release bolt.
-
Page 8: Control Board
GATE MOTOR CONTROLLER 3. Control board The SW50 swing gate motor controlled by DC2 control board, which has following features: • Control one or two 12 or 24V DC motors. For Swing gates, Sliding Gates, Roller shutter doors etc. •... -
Page 9: Control Inputs
GATE MOTOR CONTROLLER 3.1 Control inputs Fig.10. DC2 PCB dimensions and mounting holes Control Terminals OPN ----- N/O open input. PED ------ N/O pedestrian open push button, only open motor-1 CLS-------N/O Close Gate OSC------ N/O pedestrian open push button, only open motor-1 STP-------N/C Stop motor PEB ------ N/C photo electrical beams OL1 ------ Motor 1 open limit switch, N/C or N/O selected by DIP4... -
Page 10: Controller Settings
CONTROLLER SETTINGS 3.3 Motor Force In N/C limit switch mode, if any motor current over current setting, both motors will stop in opening cycle or reopen in closing. In N/O limit switch mode (this model also called no limit switch, current detect mode), if M1 over current settings, only stop M1, while M2 current over current setting, only stop M2. -
Page 11: Motor Connection
MOTOR CONNECTION 4 Motor Connections 4.1 Two wires motor To controller Fig.11. Two wires system with limit switch - 11 -... - Page 12 MOTOR CONNECTION 4.2. Five Wires motors (SW50 config to 2 wires system) Five wires motor drawing as the drawing. Fig.12. Five wires system with limit switch 4.3. Two wires motors without limit switch DC2 controller can also control linear drive motor without limit switch. Set pot/motor force according to the motor.
-
Page 13: Troubleshooting Guide
TROUBLE SHOOTING GUIDE 5 Trouble shooting guide 5.1 General checking Normally if installation is done properly, there would be trouble free. If in case of malfunction, please checking as following steps. 1) Check the DIP setting limit switch selection is right. 2) Gate status LED green (open) and red (close), one or both should be flashing depending on the gate position.
