- Page 1 P750LV2.1 industrial gate motor manual INSTRUCTION MANUAL P750L Sliding Gate Motor Version –V2.x IMPORTANT SAFETY WARNING...
-
Page 2: Table Of Contents
P750LV2.1 industrial gate motor manual ATTENTION To prevent electrical shock, disconnect from power source before installing or service ATTENTION Electricity and power motors associated accessories could be fatal or at least cause seriously injury. All main voltage wiring must be installed by a licensed electrician. ATTENTION Additional safety device MUST be fitted such as Photo Electric Beam, Loop Detectors. - Page 3 P750LV2.1 industrial gate motor manual GENERAL LAYOUT Fig -1 1) AC6 Control Board 2) Mounting Plate 3) Terminals 4) Limit switch 5) Manual Release 6) Transformer 7) Inverter (VSD) 8) EMC filter 9) Electric motor 10) Gearbox...
-
Page 4: General Description
CONTROL INPUIT AND BUTTON 1. General Descriptions The P750L sliding gate motors was designed for heavy duty industry track gate or cantilever gate. Heavy duty three phase industry motor driven by VSD (variable speed drive), gate can run at different speeds. - Page 5 P750LV2.1 industrial gate motor manual CONTROL INPUIT AND BUTTON 1.OPN open push button 2. CLS close push button 3. PED pedestrian open push button 4. STP stop push button 5. OSC open/stop/close push button 6. PEB photo electrical beams 7. Gate status display, open green, close red 8.
- Page 6 P750LV2.1 industrial gate motor manual 2.4 Model Select Switch (8) 2.4.1 SYNC Delay (DIP1) ON= Delay OFF= No Delay DIP1 is on: Motor 2 delay open and motor 1 delay close. DIP1 is off, there is no delay. Not apply to Torque motor.
- Page 7 P750LV2.1 industrial gate motor manual 2.5 Timers setting Push Buttons functions Button SET1---ON SET2 --- ON Set1 and Set2 both off---Running Open cycle time set Warning time set Open gate Close cycle time set Lock time set Close gate PED cycle time set LGT time set Partial open gate Sync motor time set...
-
Page 8: Inverter Setting
P750LV2.1 industrial gate motor manual Factory setting Timer F/Setting Step Setting Method Range Open Cycle Time 60sec. 0.1sec SET1 on + OPN Button 0-6550sec. Close Cycle Time 60sec. 0.1sec. SET1 on + CLS Button 0-6550sec. Ped Cycle Time 10sec. 0.1sec. SET1 on + PED Button 0-6550sec. - Page 9 P750LV2.1 industrial gate motor manual b) TECO L510s inverter. 24V, PNP output. Location Function Discerptions Setting Setting Gate Open High Speed Keypad 00-03 Alt Run Source 00-05 Main Freq Source 00-06 Alt Freq. Source Select 00-07 Mina & Alt Com 00-12 Max.
- Page 10 P750LV2.1 industrial gate motor manual 6. Set up limit switch...
-
Page 11: Chain Drive
P750LV2.1 industrial gate motor manual 7. Set up limit switch Chain drive system is basically standard motor set on the chain drive base. How to mounting chain drive motor a) Set the motor height. The chain base is adjustable. Chain slave/idle sprocket bottom line is about 10 to 20mm above the bottom line of gate bottom rail. - Page 12 P750LV2.1 industrial gate motor manual MANUAL RELEASE 9. Manual release A: What to do during a power failure: The gate can be manually pushed open and close if there is no power. To do this, you need to release the release bolt. (1) Open the front door and turn the switch (circuit breaker) OFF (even though there is no power) (2) Fit spanner (provided) onto the manual release bolt nicely.
-
Page 13: Condition Of Sales
(b) Digiway control boards can be up to two years warranty. subject the application conditions. (c) In lieu of all other warranties expressed or implied. Digiway shall not be liable for any special indirect, incidental or consequent damages of any kind or nature.
