Lite-Puter CX-2401 User Manual

24ch. modular dimmer console
Hide thumbs
Table of Contents

Advertisement

Quick Links

EXTENSIBLE
MODULE
DESIGN
CX-2401
24CH. Modular Dimmer Console
【User Manual】
Lite-Puter Enterprise Co., Ltd.
Website:
http://www.liteputer.com.tw
E-mail:
litecom@ms2.hinet.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX-2401 and is the answer not in the manual?

Questions and answers

Related Manuals for Lite-Puter CX-2401

Summary of Contents for Lite-Puter CX-2401

  • Page 1 EXTENSIBLE MODULE DESIGN CX-2401 24CH. Modular Dimmer Console 【User Manual】 Lite-Puter Enterprise Co., Ltd. Website: http://www.liteputer.com.tw E-mail: litecom@ms2.hinet.net...

  • Page 2: Table Of Contents

    CX-2401 24ch. ModularDimmer Console INDEX : Chapter 1. CX-2401 introduction..............2 1-1 CX-2401 Features ................3 1-2 CX-2401 Regulation ................3 Chapter 2. CX-2401 module installation 2-1 Standard and extend type..............4 2-2 Master module & Slave module front panel discription....5 2-3 Master module &...

  • Page 3: Chapter 1. Cx-2401 Introduction

    Do you have the experience? We are often asked to operate lighting immediately, but the show has finished before you know how to use the console. CX-2401 will be an ideal dimmer console to change the scene quickly and meet your need.

  • Page 4: Cx-2401 Features

    CX-2401 24ch. ModularDimmer Console CX-2401 features l DMX signal interface：DMX-512 (512 CH.) l Channel control： Standard set: to control 24 ch. Extended set: 7 dimmer modules can be extended at most and control 84 ch. l 120 Scenes l Call out the scene quickly by HOT KEY or VR.

  • Page 5: Chapter 2. Cx-2401 Module Installation

    CX-2401 24ch. ModularDimmer Console Chapter 2. CX-2401 module installation 2-1 Standard and extend type Merit: flexible channel number, easy maintenance and update software. Standard set: to control 24 ch. MASTER x SLAVE x sets SLAVE-24 FADER PANEL SLAVE-24 FADER PANEL...

  • Page 6: Master Module & Slave Module Front Panel Discription

    CX-2401 24ch. ModularDimmer Console MASTER / SLAVE front panel description CX-2401 consists of mater (right photo) and slave (left photo) parts: SLAVE-24 FADER PANEL CX-2401 MASTER CONTROL PANEL (1) Goose neck light switch (2) Goose neck connector (DC+12V 250mA) (3) BLANK switch...

  • Page 7: Master Module & Slave Module Rear Panel Discription

    CX-2401 24ch. ModularDimmer Console 2-3 MASTER/ SLAVE rear panel discription MASTER rear panel SLAVE rear panel (1) Power Switch (2) DMX-512 output (3) DMX-512 output (4) AC power socket:100-240 V AC (5) Midi signal output (6) Midi signal input (7) Rs232 D type socket (9 Pin)

  • Page 8: Chapter 3. Operation

    CX-2401 24ch. ModularDimmer Console Chapter 3. Operation 3-1 A1 & A2 CX-2401 is designed of A1 and A2 modes to change the scene immediately and meet the user’s need. SLAVE-24 FADER PANEL Scenes Channels Channels Channels Top line: the channel dimming level of A scene.

  • Page 9: How To Set And Execute The Scene Under A1 Mode

    CX-2401 24ch. ModularDimmer Console How to set and execute the scene under “A1” mode Please confirm the mode (A1 or A2) before using CX-2401. Under mode A1: A/B scene (24 channels each) can be set dimming level and output the bigger dimming level .

  • Page 10: How To Set And Execute The Scene Under A2 Mode

    CX-2401 24ch. ModularDimmer Console 3-3 How to set and execute the scene under “A2” mode 3-3-1. To enter ” A2” mode STEP-1:Push "MASTER VR" to the top. STEP-2:Press F2 to chooseMODE A2. NOW IS MODE A2 SURE TO MODE A2? STEP-3:Press ENTER to confirm.

  • Page 11: How To Stop All The Output For A While

    CX-2401 24ch. ModularDimmer Console STEP-3:press master module F4 (REC.), and then press slave module HOT KEY under SC#1. RECORD TO : Pressù ü+-1ÿ ÷+- Scene1 setting will be finished when Lcd displays the initial monitor. NOW IS MODE A2 CX-2401 Ver： 1.0 3-3-3.

  • Page 12: Chaser Type

    CX-2401 24ch. ModularDimmer Console 3-6 “CHASER” TYPE 3-6-1. Call out the scenes to choose chasing type Under A1 mode： single channel chasing STEP-1:to confirm A1 mode. (refer to 3-2-1) STEP-2:push master module CHASE VR to the ideal lighting level. STEP-3:push master module SPEED VR to the ideal speed.

  • Page 13: How To Stop Chasing

    CX-2401 24ch. ModularDimmer Console Under A2 mode： STEP-1:to confirm A2 mode. (refer to 3-3-1) STEP-2:push master module CHASE VR to the ideal lighting level. STEP-3:pull master module SPEED VR down to the bottom. STEP-4:push AUDIO VR up to the top.
  • Page 14 CX-2401 24ch. ModularDimmer Console STEP-3:press ÷ 1.XFADE EDIT STEP 1 =SC STEP-4:press ù 1.XFADE EDIT STEP 2 =SC STEP-5:press ÷ two times 1.XFADE EDIT STEP 2 =SC STEP-6:press ù 1.XFADE EDIT STEP 3 =SC STEP-7:press ÷ two times to finish setting.

  • Page 15: Additional Functions To F3 Function Key

    MIDI interface can send out 16 different kinds of musical effect by installing different level on CHANNEL (1-16). As a result of that, the MIDI-CHANNEL level in CX-2401 has to be corresponding to the CHANNEL level of MIDI interface, then CX-2401 can receive the data correctly from MIDI interface.
  • Page 16 CX-2401 24ch. ModularDimmer Console 3-9-3. To set “scene” level corresponding to “ tone” STEP-1:press F3 and then press ù two times 2.MIDI TONE EDIT P r e s s ù ü K E Y S e l TONE 1-TONE 128...
