Quick Start Guide
RadioLynx Wireless Start System
P 1C: C
ART ONFIGURING
(Vision Camera)
a. With the EtherLynx Vision camera set up and
turned on, start FinishLynx. The Hardware
Control screen appears.
b. Click , the information icon. The Camera
Settings dialog box appears.
c. Click the Inputs tab and select the Start Sensor:
None radio button.
d. Click the RadioLynx tab.
e. Select the Port: RadioLynx Port radio button.
f. From the Setup: Id dropdown list, click to select
000.
N
: The RadioLynx Transmitter defaults to Channel
OTE
0 and Signal Type STA, which corresponds to Id 000
in FinishLynx.
g. Select the Start Sensor radio button.
O :
Type a name into the text box provided. If
PTIONAL
you're using more than one RadioLynx Transmitter, it
is recommended that you name each one something
different.
e.g. "400 Meter Start," "200 Meter Start," etc.
N :
Three (3) beeps means the RadioLynx Transmitter batteries need recharging soon. You have
OTE
approximately 50 start signals remaining after the first triple beep. To view the battery level on the LCD, press
the ON/OFF button once.
P 2B: S
ART ETTING UP THE
(EtherLynx 2000+, Fusion, PRO Cameras)
N :
For the EtherLynx 2000+, Fusion and PRO cameras, the Receiver connects to the back of the camera.
OTE
a. Power Connection: use Red connector only to Red (DC) 12v 0.1A Output.
b. DB9 Serial Data
to port labeled
located on camera
RadioLynx Wireless Start
support@finishlynx.com
F L
INISH YNX
R L W
ADIO YNX
a
2 of 4
h. Click Ok.
i. Turn on the RadioLynx Transmitter and confirm
that a start signal is transmitted to FinishLynx by
listening for a beep.
R
IRELESS ECEIVER
Connector
SERIAL
back.
b
