lynx System Developers RadioLynx Quick Start Manual

Q S
UICK TART
R L W
ADIO YNX IRELESS
Lynx System Developers, Inc.
Follow the figures and steps in this guide to connect the RadioLynx components and to configure FinishLynx
If you need additional support, please contact us at:
N
: Parts 1B and 1C: EtherLynx Vision connections and configurations
OTE
Parts 2B and 2C: EtherLynx 2000+, Fusion, and PRO connections and configurations
Parts 3B and 3C: EtherLynx 2000 connections and configurations
P 1A: S
ART ETTING UP THE
a. ON/OFF button
b. Banana Plug connection: use Green and Black
connectors.
c. Connection to Start Signal Generator: use the
special Normally Open Start Sensor (tipped with
red shrink wrap)
P 1B: S
ART ETTING UP THE
(Vision Camera)
N :
For the Vision camera, the Receiver plugs into the RadioLynx Port.
OTE
a. Separate the Receiver wire at the black plastic junction.
b. Plug the Radio wire into the RadioLynx Port on the back of the camera.
RadioLynx Wireless Start
support@finishlynx.com
G
UIDE
S S
TART YSTEM
USA (978) 556-9780
R L W
ADIO YNX IRELESS
R L W
ADIO YNX IRELESS
1 of 4
or email support@finishlynx.com.
T
RANSMITTER (Starter)
R
ECEIVER
®
.
www.finishlynx.com
05/2016
