Explanation of icons

Symbol Description
Special technical points which users must observe.
Correct
Wrong
Press
Do not press
Press and keep pressed
Turn
Switch
0
Switch off machine
l
0 Switch on machine
l
enter the menu
ENTER
Navigating in the menu
NAVIGATION
Exit the menu
EXIT
Time display (example: wait 4s/press)
Interruption in the menu display (other setting options possible)
Tool not required/do not use
Tool required/use
