- Page 1 Version Translation of the original instruction manual Instruction manual Tablet PCs ITC8113 / TabX® Updated 2017-06-23...
-
Page 2: Table Of Contents
Damage due to improper use Warranty / repairs Intended use Improper use Treatment and disposal of lithium batteries 3.6.1 BIOS battery 3.6.2 Stick-style battery Cleaning the device Commissioning ........................20 Procedure © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 3 Drives ............................ 39 Hard disk / Flash SSD External drives Software ..........................40 Configuration Center Technical details ........................41 10.1 Technical details of the ITC8113 10.2 Technical details of the stick-type batteries © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 4 Component replacement ..................... 62 12.1 Opening the service slot 12.2 Changing the mass storage device 12.3 Replacing the lithium battery Service & support ........................ 66 13.1 ADS-TEC support 13.2 Company address © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 5: Notes
German instruction manual. 1.2 Limitation of liability ADS-TEC GmbH shall not be liable for personal injury, property damage or damage caused to the device as well as consequential damage that is/was the result of non-compliance with this... -
Page 6: Relevant Device Documentation
Contains information for installation, commissioning and operation of the device along with technical data of the device hardware. Website You can download drivers, software, user manuals, leaflets and flyers from the Download section of our website www.ads-tec.de. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 7: Safety Instructions
WARNING Indicates a possible danger. If not avoided, death or severe injury could result. CAUTION Indicates a possible danger. If not avoided, light or minor injuries could result. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 8: Symbols
StoraXe®, TabX® and Big-LinX® are registered trademarks of ADS-TEC. All other third-party trademarks used are hereby acknowledged. In the case of infringement of trademark rights, ADS-TEC reserves the right to exercise all rights. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 9: Copyright
ADS-TEC. In the case of copyright infringement, ADS-TEC reserves the right to exercise all rights. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 10: Environmental Conditions
2.8 Environmental conditions The device can be put into operation and used under the following conditions. Failure to observe any one of these conditions will invalidate the warranty. ADS-TEC cannot be held liable for any damages arising from improper use and handling. -
Page 11: Standards
It is therefore necessary to employ BUS and LAN cables with shielded connectors and these must be installed as per the instructions contained in the instruction manual. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 12: Scope Of Delivery
Ensure that they are secured against being started up accidentally. 1 x device 1 x power adapter 20VDC 2 x stick-style battery QuickStartGuide Optional scope of delivery: ITC8113 accessories acc. to delivery note © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 13: Features Of The Itc8113
ITC8113 / TabX® 2.11 Features of the ITC8113 The industrial tablet computer from ADS-TEC has been consistently further developed for professional and mobile use. High performance, brilliant Full HD display and optimised for applications in service environments – the new TabX - ITC8113 scores high marks both for indoor and outdoor use. -
Page 14: Rear Side
ITC8113 / TabX® Rear side Fig. 2: Description Battery ejector Set-up mechanism Service slot Docking connector © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 15: External Dimensions Itc8113
ITC8113 / TabX® 2.12 External dimensions ITC8113 Fig. 3: © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 16: Operating And Safety Instructions
(e.g. Sidolin) with low alcohol content. ATTENTION To prevent damage to the device, all cable lines (power supply, interface cables) must be only be connected while the device is switched off. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 17: Operating Location
The device is used for diagnostics, visualisation and control of a wide range of processes in a service environment, among other places. The device is designed for indoor and outdoor applications. The device is only to be assembled, installed and operated within the permissible specifications. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 18: Improper Use
In the case of improper use, ADS-TEC shall not accept responsibility or liability for injury or damage that is directly or indirectly attributable to the handling of the device. -
Page 19: Stick-Style Battery
For cleaning we recommend applying a cleaning agent for household use. Additionally, we have tested the following disinfectant: Meliseptol® produced by B. Braun Melsungen AG. It can be used following the recommendations for use and dosage indicated by the manufacturer. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 20: Commissioning
Insert battery into the device and snap into place (see chapter Battery operation) Connect power adapter (if necessary) Start the device (ON/OFF pushbutton) and activate in the operating system by entering the licence information © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 21: Operation
ITC8113 / TabX® 5 Operation 5.1 Full HD display The device is equipped with a full-HD display with multifunction touch-screen. The non-reflective display offers a maximum resolution of 1920 x 1080 pixels. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 22: 10-Finger Multifunction Touch-Screen
Pos : 23 /D atentec hni k/Bedienung/Status-Anzeig en/SYS- LED/SYS- LED für VMT 60xx- Serie @ 2\mod_1260525540269_6.doc @ 6876 @ Recommendation for use: With older operating systems, a driver is required for the touch-screen functionality. The appropriate driver can be downloaded from http://www.ads-tec.de/industrial-it/download/ for the respective device series. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 23: Front Status Leds
Power LED Device is not connected to a voltage source Static Device is supplied with charged battery Static Device is supplied with external voltage Flashin Stick-style batteries are being © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 24 Device is connected to a WLAN network and has data traffic Bluetooth Static Bluetooth module is deactivated. Static Bluetooth module is activated. Flashin Device is connected to a Bluetooth subscriber and has data traffic © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 25: Front Panel Operation Keys
After activating the operating system, the soft keyboard can be opened using the corresponding front key. If the soft keyboard is not installed, it can be added. Details can be found in the instruction manual for the Configuration Center. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 26 Level 1: Right mouse-key function Level 2: Increase display brightness Level 1: Activate and deactivate the soft keyboard for letter/character input by using the touch screen Level 2: Decrease display brightness © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 27 Recommendation for use: If the soft keyboard is not installed, level 1 of the ABC key has no function. Furthermore, no graphical feedback is provided when changing the display brightness. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 28: Landscape/Portrait Function
To protect the device from overheating, make certain that the air outlet slots are not covered or that the air outlet is not impeded. 1246361069977 ouc h Scr een/T ouchs creen für VMT 60xx @ 1\mod_ _6.doc @ 5853 @ © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 29: Interfaces
Pos : 26 /D atentec hni k/Schnitts tell en/Spannungs versorgung/Spannungs versorg ung für VMT60xx- Seri e @ 2\mod_1260450284020_6.doc @ 6853 @ Fig. 6: Variant 1 Recommendation for use: Only use the accessories and replacement parts released by ADS- TEC. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 30: Power Supply Via The Power Adapter
20 VDC 47…63 Hz Grid frequency: Current consumption: 3.5A (230 VAC) Recommendation for use: The typical power consumption of the device can be found in the chapter Technical details. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 31: Power Supply Via Stick-Type Batteries
If changing just one battery, it can be changed without an external power supply. Pos : 29 /D atentec hni k/Schnitts tell en/USB-Ansc hlus s/U SB-Ansc hl uss für VMT 60xx @ 2\mod_1260457598122_6.doc @ 6860 @ © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 32 Red, yellow and orange LEDs on 66 … 94% All the LEDs on 95 … 100% Recommendation for use: If the device is in operation, the battery state can be queried via the operating system. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 33: Usb Interfaces
The recessed USB interface enables the use of a USB dongle. This can be operated in the device. Recommendation for use: The two side USB interfaces are designed for 1A. Exception: the recessed USB interface, which is designed for 1.8A. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 34: Network Connection (Rj45)
Ethernet network supporting the 10/100/1000Mbit standard by using the Ethernet 10/100/1000 BaseT network connector. The specifications of this network topology must be observed. If the drivers necessary for the function are not installed, they can be downloaded from the website www.ads-tec.de. 10/100Mbit PIN number... -
Page 35: Microphone
ITC8113 / TabX® 6.5 Microphone The device is also equipped with an internal microphone on the front side. The microphone can be configured via the integrated volume control in the operating system. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 36: Speakers
Pos: 2 9 /Datente chnik/S chnittstellen /USB-Ans chluss/ USB-A nschlus s für VMT 6 0xx @ 2\ mod_12 6045 75981 22_6. doc @ 68 60 @ Button combination - reduce volume © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 37: Wireless
The device is equipped with a wireless LAN card and can be integrated wirelessly in any IT infrastructure. Recommendation for use: The wireless card supports the following standards: Wireless LAN 802.11 a / g / n © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 38: Bluetooth
Further information is available from your mobile provider. The SIM card is to be inserted while the device is in the off state. The mobile communications module supports the following standards: UMTS (3G) / LTE (4G) © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 39: Drives
Data loss might result in the event of non- compliance! os: 36 /D atentechni k/Software / Tr eiber Installation/Installation des Betri ebs s ystems/Ins tall ati on des Be © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 40: Software
9.1 Configuration Center If there is a preinstalled operating system on your device ex works, ADS-TEC provides software modules. These software modules are specially matched to the respective device and can be called up in the Configuration Center. -
Page 41: Technical Details
Approx. 1.8 kg without batteries Vibration DIN EN 60068-2-6 Shock resistance DIN EN 60068-2-27 Humidity 10 to 85% non-condensing k/Ser vice und Support/Servic e & Support @ 2\mod_1254312498746_6.doc @ 6472 @ © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 42: Technical Details Of The Stick-Type Batteries
If the device is not used for a longer period of time, remove the stick-style batteries from the ITC. Regularly check the charge state. The battery must be charged at the latest if the red LED of the charge state display blinks. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 43: Accessories
The optionally available transport case allows the device to be transported safely. In addition, the transport case offers the possibility to store accessory parts such as batteries, power adapters and software. Exterior view of sample case © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 44: Battery Charging Station (Optional)
Connect the power adapter on the rear side of the battery charging station. Recommendation for use: The power adapter for the device can be used to supply power to the battery charging station (20 VDC). © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 45 ITC8113 / TabX® Recommendation for use: Make certain that the system LED illuminates green. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 46 Recommendation for use: If the battery was correctly inserted in the battery charging station, an audible signal sounds and the charging process begins. An audible signal also sounds when a battery is removed. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 47 Device is not connected to any voltage source (power supply/battery) Static Device is connected to a power source (power supply/battery) and switched on. Static Device not ready for operation / defective power supply © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 48 ITC8113 / TabX® ICTOGRAPHIC REPRESENTATION Battery is charging Battery fully charged Device is not ready for operation / defective power source Battery is faulty © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 49: Replacement Power Adapter (Optional)
This can be used to conveniently supply the device with power in vehicles. Technical data of the power adapter Power consumption: 90 watts Input voltage: 11-15 VDC Output voltage: 20 VDC © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 50: Replacement Battery (Optional)
ITC8113 / TabX® 11.5 Replacement battery (optional) A replacement battery is optionally available for operating the device (Article no.: DV-ITCOPT-003 001-AA). © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 51: Rotatable And Tiltable Wall Table Adapter (Optional)
The docking station is available in two versions. The first version is used strictly to hold the device. The second version (pictured) has a docking connector that transfers data to the interfaces of the docking station. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 52 EMOVING THE DEVICE FROM THE DOCKING STATION 1) Push the turquoise release downward and hold down 2) Tilt the device forward slightly 3) Lift the device upward to disconnect and remove it from the docking station © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 53: Set-Up Mechanism
ITC8113 / TabX® The docking solution shown here illustrates the mechanical release. A lockable docking solution is also available. 11.7 Set-up mechanism The set-up mechanism enables comfortable operation anywhere. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 54: 3-Point Strap (Optional)
1 x DZ-MECH-33255-1 (A) M5x16 flat-head screw, galvanised DIN 921 2 x DZ-MECH-33255-2 flat head screw. M5x20, galvanised DIN 921 (B) 3 x DZ-MECH-31033-0 Strap eyelets 1 x DZ-MECH-31039-0 3-point strap © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 55 1) First attach the strap eyelets to the device. In doing so, the appropriate mounting option must be selected for left- or right-handed users. Left-handed users: white marking Right-handed users: red marking © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 56 2) Screw down the strap eyelets at the marked positions as shown in the figure. Recommendation for use: Tighten the screws to max. 120 Ncm. The strap eyelets should still move without loosening the screw. Mounted state for right-handed users © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 57 3) The shoulder strap can be attached to the strap eyelets via the carabiners. The device is ready for mobile use. Recommendation for use: The tilt adjustment of the shoulder strap (upper right) should always be attached to the upper side of the device. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
- Page 58 ITC8113 / TabX® © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 59: Hand Strap (Optional)
2 x supplied screws 1 x hand strap OUNTING THE HAND STRAP ON THE DEVICE 1) The hand strap is to be mounted at the marked bore holes. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 60 ITC8113 / TabX® 2) Screw down the hand strap at the marked positions as shown in the figure. Recommendation for use: Tighten the screws to max. 120 Ncm. 2) Mounted hand strap © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 61: Protection Cover (Optional)
ITC8113 / TabX® 11.10 Protection cover (optional) The optionally available protection cover offers protection against transport damages. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 62: Component Replacement
Remove the six screws for the service slot on the rear of the device. The screws can be removed with a size Tx 8 screwdriver. The rear cover can be removed via the groove in the service slot on the bottom side. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... - Page 63 ITC8113 / TabX® By removing the service slot cover, it is possible to replace the following components. HDD / SSD Lithium battery © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen...
-
Page 64: Changing The Mass Storage Device
The extraction aid on the mass storage device should be used for removing. Pull out the storage medium. Installation The mass storage device must be carefully inserted into the slot and should noticeably engage. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 65: Replacing The Lithium Battery
ATTENTION There is a risk of explosion if the battery is replaced with the wrong type or with the wrong polarity. Observe the regulations for environmentally sound disposal of used batteries. © ads-tec GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen... -
Page 66: Service & Support
ADS-TEC will not be able to answer such questions. ADS-TEC does not provide support services for any device that was not purchased directly from ADS-TEC. In this case, maintenance and support is provided by the partner company.
