Page 1: Instruction Manual
99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Instruction Manual LM-1750HDW Multiple Format 17” Color LCD Monitor... -
Page 2: Table Of Contents
Table of Contents Introduction Specifications Package Contents Connecting The Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 3: Introduction
Signal Distribution Amplifiers and Cat.5/6 Transmission Systems. Liability Statement Every effort has been made to ensure that this product is free of errors. tvONE cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. -
Page 4: Specifications
Features The LM-1750HDW has many features that enable it to perform in a superior manner. Among those features you will find: Inputs: HD/SD-SDI, HDMI, Analog RGBHV, Component YUV, Composite and YC (S-Video) Video Resolutions up to 1080p High Brightness, Pro Grade LCD Panel ... - Page 5 Analog RGBHV Input Range 640x350 70, 85Hz 720x350 70, 85Hz 640x400 70, 85Hz 720x400 70, 85Hz 640x480 60, 72, 75, 85Hz 800x600 60, 70, 75Hz 1024x768 60, 70, 72, 75Hz 1152x864 60, 70, 72, 75Hz 1440x900 60, 70, 72, 75Hz Composite &...
-
Page 6: Package Contents
NOTE: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or tvONE immediately. Have the Model Number, Serial Number and Invoice available for reference when you call. - Page 7 Four (4) pre-drilled and threaded attach points are provided in the center to allow mounting of the LM-1750HDW directly to a wall or other structure using VESA 100mm standard mounts available from third party vendors. Please note that the rack ears remain in place, even when a VESA mount is used.
-
Page 8: Operating The Unit
OPERATING THE UNIT After mounting the LM-1750HDW in a rack and connecting the appropriate cables and the AC adapter, press the power button, select the appropriate input and adjust the vertical viewing angle if desired. Input selection is made by pressing the appropriate button on the front panel. The possible selections are HDMI, PC, YPbPr, SDI, AV1 (either Composite Video or S-Video, but not both at the same time) and AV2 (Composite Video). -
Page 9: Menu Item
LM-1750HDW to insure that the problem is not with the source device.) If the signal is present under those conditions, make certain that power is present to the LM-1750HDW. If it is, check all cables for damage. Cables should be undamaged, as short as possible and should be premium quality. -
Page 10: Limited Warranty
In no event shall tvONE be responsible or liable for any damage arising from the use of such defective products whether such damages be direct, indirect, consequential or otherwise, and whether such damages are incurred by the reseller, end-user or any third party.
