- Page 1 OPERATION MANUAL DWA-9100...
-
Page 2: Table Of Contents
Thank you for purchasing the Legacy Massage Lounger (DWA-9100). Before using this chair for the first time, please read through all sections of this User Manual carefully. Pay special attention to the Important Safety Instructions. CONTENTS SAFETY PRECAUTIONS PARTS Exterior Parts Interior Parts Fuse Box Controller... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Improper operation may cause injury to users or permanent damage to the chair. This massage chair is NOT suitable for individuals who are: • Suffering from skin disease or injuries to the skin • Running a fever of over 100ºF Individuals currently undergoing the following conditions should consult a doctor before using this chair: •... - Page 4 SAFETY PRECAUTIONS • Do not twist or pull on the power cord, nor crush it with any heavy object. • If the power cord becomes damaged, shut off power immediately and disconnect the plug. Discontinue use and contact the manufacturer for repair or replacement. •...
-
Page 5: Parts
PARTS External Structure Pillow Speakers Back Cover Back cushion Armrest Seat cushion Legrest Caster Internal Structure Massage mechanism Shoulder airbags Arm airbags Back heating pad Seat airbags Seat heating pad Calf airbags Foot airbags Foot roller massage nodes... -
Page 6: Fuse Box
PARTS Fuse Box Controller port Power supply socket Safety fuse Power on/off • To prevent possible electric shock, do not let children play on the chair. • After finishing each massage session, and whenever the chair is not in use, shut off power and remove the power plug from the wall outlet. -
Page 7: Controller
PARTS Controller Display screen Shoulder Power button adjustment keys Menu button Auto mode button Up key Left key Right key Okay button Down key Airbag button Heat button Footrest up Backrest up Backrest Footrest down down Zero Gravity button... -
Page 8: Massage Chair Operation
MASSAGE CHAIR OPERATION Controller Operation Power Button • Press to turn on the unit. The display screen will light up. Press the Up or Down key to highlight your preferred massage mode and preference.Press ] to select. • Press [Power button] again to turn off all functions. The default running time is 15 minutes for each Menu Button •... -
Page 9: Display Screen Operation
MASSAGE CHAIR OPERATION Footrest Up button • Press and hold to raise the footrest. Release the button when it reaches your desired position. Footrest Down button • Press and hold to lower the footrest. Release the button when it reaches your desired position. Backrest Up button •... - Page 10 MASSAGE CHAIR OPERATION Manual Options Press [ ] and scroll down to the Manual option. {diagram A} Press [ ] to select. Press [Up or Down arrow keys] to highlight your desired massage option. {diagram B} Press [Right arrow key] to select and move on to the next menu. Press [Up or Down arrow keys] to highlight the specific part of the body you wish to massage.
- Page 11 MASSAGE CHAIR OPERATION Airbag Massage Press [ ] and scroll down to the Airbag option. {diagram G} Press [ ] to select. Upon highlighting PART, press [Up or Down arrow keys] to select one of the following options: Full Arms & Shoulders Legs and Feet Buttocks Press [Right arrow key] to lock in your selection.
- Page 12 MASSAGE CHAIR OPERATION Roller Massage Option Press [ ] and scroll down to the Roller option. {diagram M} Press [ ] to select. Press [Up or Down arrow keys] to select one of the following speeds: 1, 2, 3, or OFF. {diagram N} Note: the Roller Speed cannot be adjusted while the Full Body Airbag massage is running.
- Page 13 MASSAGE CHAIR OPERATION With BLUETOOTH highlighted, press [Up or Down keys] to begin or end Bluetooth functions. Notes: After making any selections within the Automatic Mode or Manual Mode menus, pressing [ ] twice in a row will being the screen back to the initial screens for the Automatic Mode and Manual Mode.
-
Page 14: Setup Instructions
SETUP INSTRUCTIONS Setting Up the Chair Carefully lift the chair and all its parts from their packaging. Remove any protective wrapping. Locate the packing list. Check to make sure that all parts are present. Install the Legrest. Locate the coupling shafts on the right and left sides of the massage chair’s seat. - Page 15 SETUP INSTRUCTIONS Fasten both sides by pushing the lock down onto the connecting axis. (See figure below.) Lock Connecting axis Lock Lift up the legrest to connect the airtube and air valve plug with their corresponding ports on the base of the seat.
- Page 16 SETUP INSTRUCTIONS Connect the back cushion to the backrest. Place the back cushion onto backrest of the chair. Fasten with the zipper on each side. Then draw the zipper on top of the backrest and back cushion closed. Likewise, use the zipper to connect the PU on the calf massage unit with the seat.
- Page 17 SETUP INSTRUCTIONS Install the armrest Align the hook on the armrest with the corresponding connecting rod on the backrest (diagram 1). Push down to lock it into place. Fasten the armrest to the seat frame with one screw on the corresponding side of the chair. Hook Connecting Armrest frame...
- Page 18 SETUP INSTRUCTIONS Install miscellaneous parts Insert the end of the cord from the controller into its corresponding port on the fuse box. Connect one end of the power cord with its corresponding port on the fuse box. Controller Power cord Power cord port Power switch Power cord connector...
-
Page 19: Moving The Chair
SETUP INSTRUCTIONS Moving the Chair • Make sure that the backrest is in its highest upright position. • Shut off power and remove the power plug from the wall outlet. • Standing behind the back of the chair, grasp its backrest and tilt it downward, so that the front of the chair rises off of the floor. -
Page 20: Massage Chair Placement
SETUP INSTRUCTIONS Massage Chair Placement When looking for a location to place your massage chair, keep following in mind: 1. The chair takes up significantly more space when stretched out than when in an upright position. With the chair upright, allow at least 20 inches of open space behind the backrest, and at least 16 inches of space in front of the footrest. -
Page 21: Before Using The Chair For The First Time
Make sure that your audio device is compatible with the audio system on this chair. Then play the music of your choice while enjoying a luxurious massage. Pairing your audio device: Make sure that your bluetooth is turned on in your audio device. Search for device named “DAIWA-9100”... -
Page 22: After Each Use
SETUP INSTRUCTIONS After Each Use After each use, turn off the power and disconnect the power plug from the wall outlet. If you do not plan to use the product for a prolonged period of time, cover it to keep it clean, then store the entire chair in a clean, cool, and dry environment. - Page 23 MAINTENANCE AND STORAGE Cleaning: • Before each cleaning, switch off power and detach the power plug from the wall outlet. • Dip a soft, clean cloth in some neutral detergent and use it to wipe the armrests, legrest, and other plastic parts. Then use a clean, dry cloth to rewipe all areas.
-
Page 24: Troubleshooting
TROUBLESHOOTING Problem Check the Following: Explanation/Remedies These noises are Noises are heard normal and arise from during operation friction between the massage rollers and the leather cover. Operation fails Has the power plug Connect the power to start slipped out of the wall plug securely to the outlet? wall outlet. - Page 25 LIMITED WARRANTY This warranty guarantees that the product purchased is to be free from defects in material and workmanship under normal usage and local voltage for a period of one year. This warranty expires in TWO (2) years on parts, and ONE (1) year on labor after the date of purchase.
